- Page 1 FIELD CULTIVATOR / CHISEL PLOW OWNER’S MANUAL With Assembly Instructions For Model: 543T & 760T KUNZ ENGINEERING, INC. / MENDOTA, IL 61342 / PH (815) 539-6954 2/25...
-
Page 3: Table Of Contents
TABLE OF CONTENTS SAFETY INTRODUCTION……………………………………………………………………………… 2 Safety Alert Symbol …………………………………………………………………………………… 2 Safety Information ……………………………………………………………………………………… 3 ASSEMBLY INSTRUCTIONS ………………………………………………………………………..4 Items Included ………………………………………………………………………………………….. 4 Unpacking Crate ……………………………………………………………………………….….. …...4 Configuring for Quick Hitch 3-Point Systems……………..…………………………………….……5 OPERATION AND ADJUSTMENTS ………………………………………………………………….. 5 Intended Use …………………………………………………………………………………………… 6 Leveling the Tool …………………………….…………………………………………………………... -
Page 4: Safety Introduction
It may also be used to alert against unsafe practices. This entire manual is filled with important safety information. Please read it carefully. If you have any questions or concerns regarding the information in this owner’s manual please contact Kunz Engineering at 815-539-6954. -
Page 5: Safety Information
Follow all safety precautions outlined by the manufacturer of the tractor/tow vehicle being used to pull this product. This entire manual is filled with important safety information. Please read it carefully. FOR QUESTIONS, COMMENTS OR TROUBLESHOOTING PLEASE CONTACT KUNZ ENGINEERING INC. AT (815) 539-6954... -
Page 6: Assembly Instructions
ASSEMBLY INSTRUCTIONS Read the complete assembly instructions before starting the assembly. You should have: - one tillage tool assembly - five (Model 543T) or seven (Model 760T) 9” cultivator sweeps with bevel washer spacers The models 543T and 760T are fully assembled and ready to use on a standard Category 1 3-point system after uncrating. -
Page 7: Configuring For Quick Hitch 3-Point Systems
Upper Top Link Hole for Standard 3-Point Top Link Pin in Lower Hole for Quick Hitch Lift Arm Pins Figure 2. – Configuring for Quick Hitch B. CONFIGURING FOR QUICK HITCH 3-POINT SYSTEMS 1. There is an upper and lower top link hole on the 3-point system. (See Figure 2.) The top link pin will be positioned in the top hole from the factory. -
Page 8: Intended Use
Never carry children or passengers. Lower implement, stop engine, set brake and remove key before servicing, adjusting, repairing or unplugging. Safely support and secure implement before making repairs. Do not stand or climb on equipment. Follow all safety precautions outlined by the manufacturer of the tractor/tow vehicle being used to pull this product. -
Page 9: Adjusting The Shanks And Coulter Shanks
The reversible chisel point sweeps are a good choice in hard ground conditions. These sweeps have the ability to easily penetrate and shatter hard ground conditions. Bevel Washer Spacers – Mount on upper hole and only use on cultivator sweeps or turning shovels. 9”... -
Page 10: Suggestions For Proper Operation
Maximum Coulter Depths Maximum Sweep Depths Position High Position in High Upper Receiver Hole, Low Position in Lower Receiver Hole Shank Receiver Figure 4. – Shank Adjustment F. SUGGESTIONS FOR PROPER OPERATION Proper tool adjustment can increase functionality and efficiency. Hard Ground In hard ground conditions, the reversible point chisel sweeps should be installed. - Page 11 Remove Middle Model 543T Two Shanks. Remove Middle Three Shanks. Remove Middle Two Coulter Shanks. Remove Middle Model 760T Three Coulter Shanks. Figure 5. – Suggested Heavy Debris Configuration Sod Covered Ground It is recommended that these conditions be mowed and sprayed with a grass killer. A grass killer will not only kill the green growth but will help to break up the root structure as well.
- Page 12 Rock Covered Ground In most cases reversible point chisel sweeps will have the best chance of working in heavily rock covered ground on the initial pass. These sweeps will provide the least resistance. It may be necessary to raise or remove the coulters. If the coulters are being forced out of the ground due to rocks, it may be difficult to get adequate sweep penetration.
- Page 13 Soft Ground Conditions or Previously Tilled Ground Soft ground conditions can be performed with any of the sweeps. The 9” field cultivator sweeps tend to work the best in these cases. These sweeps will help to fully shear the ground off and create a true seedbed.
-
Page 14: Service Parts
259004 Reversible Chisel Point Sweep 259005 Turning Shovel Optional Optional 259006 Coulter Blade, 13.5" 275018 Till-Ease Name Decal 275019 Kunz Decal 500007 Shank 500008 Coulter Shank 800008 Weight Rack 800010 Tool Frame (Model 543T) 800024 Tool Frame (Model 760T) 800029... -
Page 15: Parts Drawing
MODEL 543T & 760T PARTS... -
Page 16: Warranty Statement
Till-Ease Tillage Equipment Warranty Policy Kunz Engineering, Inc., warrants to the owner that each new product is free of defects in workmanship and material for the length of 12 months from the date of purchase. Kunz Engineering, Inc., agrees to provide replacement parts for any defective parts at no charge to the owner.
