- Page 1 Automatic spiral mixer with lifter for table MSPB...
-
Page 2: Table Of Contents
General Idex Chapter 1 General information ..................3 1.1 Documentation supplied ................... 3 1.2 This manual....................... 3 1.3 Information property rights..................3 1.4 Conventions ......................4 1.5 Manufacturer identification details ................5 1.6 Machine identification details................... 5 1.7 EC declaration of conformity "CE” ................6 1.8 Guarantee ........................ - Page 3 Chapter 8 Spare parts ....................27 8.1 How to place an order for spare................27 8.2 Machine components ....................28 8.3 Protection components.................... 29 8.4 Dough working components ................... 30 8.5 Spiral motor components ..................31 8.6 Bowl thrust block roller components..............32 8.7 Bowl motor components ..................
-
Page 4: Chapter 1 General Information
No part of this manual can be reproduced or photocopied without the prior written permission of MAC.PAN s.r.l. Permission to use this documentation has only be given to the customer to whom the manual has been supplied as part of the machine's equipment and only for the... -
Page 5: Conventions
Chapter 1 - General information refers. MAC.PAN s.r.l. declares that all the information contained herein is in accordance with the technical and safety specifications of the machine to which the manual refers. The manufacturer will not held be responsible for direct or indirect damage or injury to persons, objects or animals resulting from the use of this documentation or the machine in non- standard conditions. -
Page 6: Manufacturer Identification Details
MAC.PAN s.r.l. Machine identification details Type: AUTOMATIC SPIRAL MIXER WITH LIFTER FOR TABLE Model: MSPB 100 - 130 - 160 200 - 250 Serial no.: Year of manufacture: Fig. 1.1 Position of name plate Fig. 1.2 Name plate Automatical spiral mixer RBM... -
Page 7: Ec Declaration Of Conformity "Ce
Use of non-original spare parts or parts not specified by MAC.PAN s.r.l Claiming under guarantee Method Requests for spare parts or service visits under guarantee must be made to MAC.PAN s.r.l. Automatical spiral mixer RBM Automatic spiral mixer with lifter for table... -
Page 8: Use Of The Manual
This information can be found on the name plate of the machine. NOTE Failure to comply with the instructions contained herein will release MAC.PAN s.r.l. from any liability in the event of accidents to persons and/or objects, or machine malfunctioning. Requests for spare parts When requesting spare parts please state the following information: •... -
Page 9: Description Of The Machine
Chapter 1 - General information 1.10 Description of the machine Intended use Intended operations The machine has been built and designed for the cake and bread mixing stage to obtain shorter working times. The working cycle can be manual or automatic and features two-speed operation, both with timing;... -
Page 10: Chapter 2 Safety Information
Do not wear loose clothing, ties, chains, or watches that could get caught in the moving parts of the machine. NOTE MAC.PAN s.r.l. will not be liable for any damage or injury to persons, animals or things caused by non-observance of the safety rules and/ or recommendations given in the documentation supplied. - Page 11 Chapter 2 - Safety information Fixed and moveable guards • All power transmission components are shielded by screw-fastened guards, in compliance , with the EN 953 standard • Safety grille which prevents access to the bowl during the work process. Fig.
- Page 12 Chapter 2 - Safety information Passive safety devices DEFINITION Passive safety devices are those devices or safeguarding techniques which eliminate or reduce potential hazards for the operator without the operator having to actively intervene. Limit switch devices The machine is equipped with a limit switch microswitch (Fig. 2.2). This limit switch microswitch, triggered by a cam, halts the stroke of the hydraulic cylinder within safe limits.
-
Page 13: Hydraulic Unit
Chapter 2 - Safety information Hydraulic unit The automatic spiral auto-overturning mixer is equipped with an hydraulic system so to ease and make the operations of overtuning to be done safely. Description of the hydraulic system It is made up of: 1. -
Page 14: Hydraulic Unit
Chapter 2 - Safety information Hydraulic unit Controls Simbol Description Motor of the hydraulic pump. Pressure gauge. Pressure regulator. Oil tank. Filler cap. Drain plug. High-pressure valve Fig. 2.2 Filter unit Automatical spiral mixer RBM Automatic spiral mixer with lifter for table... -
Page 15: Chapter 3 Machine Specifications
Chapter 3 Technical specifications Dimensions and weight of the machine Dough/Mixt Motor of the capacity hydraulic pump. Model Flour cap. Motor bowl Motore spirale MSPB 100 0.75 MSPB 130 0.75 3/5.8 MSPB 160 3.6/5.8 MSPB 200 5/7.3 MSPB 250 5.8/10.2... -
Page 16: Chapter 4 Operator Interface
Chapter 4 - Operator interface Operator interface Chapter 4 Controls Fig. 4.1 Controls CONTROLS Simb. Description Functions controlled Three positioning selector Working mode selector: automatic / manual. Double positioning selector It enables the selection of the bowl direction rotation . First speed selector. -
Page 17: Controls
Chapter 4 - Operator interface Controls Controls Symb Description Functions controlled Red mushroom button on a yellow EMERGENCY button. When pressed, this background. stops the machine completely by cutting off the voltage to the electric circuits. Upstroke button When the two buttons are pressed simultaneously, the bowl upstroke is activated. -
Page 18: Chapter 5 Utilisation
Chapter 5 - Utilisation Utilisation Chapter 5 NOTE When reading this chapter refer to the pictures of the control panels given in Chapter 4 Operator interface. Qualifications of operator The machine should be operated only by trained, qualified and authorised personnel who have read and understood the information contained in this manual. -
Page 19: Machine Switching On
Chapter 5 - Utilisation Machine switching on To switch the machine on proceed as follows: 1. Turn the knife-switch situated upstream from the outside power supply cable to position I. Tooling, adjustments and setting up Adjustment warnings 1. adjustment, checking or cleaning operations must be carried out with the machine at a standstill and the electric control box off. -
Page 20: Emergency Stop
Chapter 5 - Utilisation 2. Turn the main on-off switch to position "O". Emergency stop To stop the machine in an emergency, press the EMERGENCY button (Fig. 4.1 Controls on page 15) : • The machine stops. • The mushroom-head button will remain blocked. Starting the machine again after a manual emergency stop 1. -
Page 21: Chapter 6 Use Of The Machine
Chapter 6 - Use of the machine Use of the machine Chapter 6 Using for the first time Loading the mixer: after lifting the protection grid, put the ingredients into the bowl to the maximum dough capacity. No particular indication is given regarding the order in which to introduce the ingredients. -
Page 22: Chapter 7 Maintenance
Chapter 7 - Maintenance Maintenance Chapter 7 DANGER Risk of electric shock and unexpected movements during maintenance. Isolate the machine from electric and hydraulic power sources. Dissipate and/or limit residual energy Generalities Due to the construction characteristics, the machine does not need many maintenance operations. -
Page 23: Scheduled Servicing
Chapter 7 - Maintenance • Clean the machine at the end of each shift. • The cleaning of the machine keeps the most delicate parts in good working order and helps to spot any loosening of parts and any abnormal wear and tear. BEWARE Do not use jets of water to clean the control panels and the electric control box. -
Page 24: Regular Inspections
Chapter 7 - Maintenance Regular inspections Regular checks and adjustments Name of parts to be checked and adjusted Frequency Method Emergency stop button Every 40 working hours Check the correct operation Spiral motion driving belts The first one must be Check the tensioning of the spiral effected after 15 hours of motion driving belts , (see Fig. - Page 25 Chapter 7 - Maintenance Regular checks and lubrification Name of parts to be inspected Frequency Inspection procedure Bearings Monthly Oil with grease Hydraulic unit tank. monthly Add oil up to the marked level which is described in the hydraulic unit operating manual.
- Page 26 Chapter 7 - Maintenance SPIRAL MOVEMENT BELT TENSION The belt adjustment must be carried out if the spiral is slowing down. 1. Take the head cover off (pos. 2 Fig. 8.1 Machine components on page 28) 2. Loosen the four screws (pos. A) of the motor support without unscrewing them completely, then unscrew the nut ( pos.B).
-
Page 27: Extraordinary Maintenance
Chapter 7 - Maintenance BOWL MOVEMENT BELT TENSION Fig. 7.3 Bowl movement belt tension Extraordinary maintenance Any operation of parts replacement is considered extraordinary maintenance. These operations must be accomplished only by specialised staff. For such an intervention contact your retailer. Automatical spiral mixer RBM Automatic spiral mixer with lifter for table... -
Page 28: Chapter 8 Spare Parts
Chapter 8 - Spare parts Spare parts Chapter 8 How to place an order for spare • Model and serial number of the machine (see plate) • Motor voltage • Reference number of the spare part required • Name of the spare part •... -
Page 29: Machine Components
Chapter 8 - Spare parts Machine components Fig. 8.1 Machine components REF. DESCRIPTION Bearing structure Head cover Bowl Bowl thrust block roller Fixed protection Protection Base covering Panel control Adjustable feet Automatical spiral mixer RBM Automatic spiral mixer with lifter for table... -
Page 30: Protection Components
Chapter 8 - Spare parts Protection components Fig. 8.1 Protection components REF. DESCRIPTION Protection rotating shaft Cam control Sprig Screw Washer Microswitch Microswitch support Eccentric stop Screw Automatical spiral mixer RBM Automatic spiral mixer with lifter for table... -
Page 31: Dough Working Components
Chapter 8 - Spare parts Dough working components Fig. 8.1 Dough working components REF. DESCRIPTION Spiral support Screw Washer Shaft Retaining ring Couple Spacer Driven pulley Bearing Bearing Flange Screw Washer Screw Spiral Support boot Contrast column Screw Washer Automatical spiral mixer RBM Automatic spiral mixer with lifter for table... -
Page 32: Spiral Motor Components
Chapter 8 - Spare parts Spiral motor components Fig. 8.1 Spiral motor components REF. DESCRIPTION Motor Support plate Adjustment screw Washer Screw Washer Screw Washer Motor pulley Spring Counternut Belt Type Automatical spiral mixer RBM Automatic spiral mixer with lifter for table... -
Page 33: Bowl Thrust Block Roller Components
Chapter 8 - Spare parts Bowl thrust block roller components Fig. 8.1 Bowl thrust block roller components REF. DESCRIPTION Roller Bearing Washer Washer Screw Support (right and left) Screw Washer Automatical spiral mixer RBM Automatic spiral mixer with lifter for table... -
Page 34: Bowl Motor Components
Chapter 8 - Spare parts Bowl motor components Fig. 8.1 Bowl motor components Automatical spiral mixer RBM Automatic spiral mixer with lifter for table... - Page 35 Chapter 8 - Spare parts BOWL MOTOR COMPONENTS DESCRIPTION Q.TA’ TYPE Screw Motor Motor support Fixed wheel Screw peg Spacer Countershaft with pulley Couple Return pulley Transmission support Bearing Couple Rotating wheel Bowl rotating pulley Bearing Bowl support Bowl shaft Bearing Screw Washer...
-
Page 36: Chapter 9 List Of Enclosures
Chapter 9 - List of enclosures Enclosure 2Wire diagrams Automatical spiral mixer RBM Automatic spiral mixer with lifter for table... - Page 37 Chapter 9 - List of enclosures Automatical spiral mixer RBM Automatic spiral mixer with lifter for table...
- Page 38 Chapter 9 - List of enclosures Automatical spiral mixer RBM Automatic spiral mixer with lifter for table...
- Page 39 Chapter 9 - List of enclosures Automatical spiral mixer RBM Automatic spiral mixer with lifter for table...
- Page 40 Chapter 9 - List of enclosures Automatical spiral mixer RBM Automatic spiral mixer with lifter for table...
- Page 41 Chapter 9 - List of enclosures Enclosure 3Machine dimensions Automatical spiral mixer RBM Automatic spiral mixer with lifter for table...
- Page 42 Chapter 9 - List of enclosures Enclosure 4Hydraulic diagrams Automatical spiral mixer RBM Automatic spiral mixer with lifter for table...
- Page 44 www.macpan.com...
