- Page 1 Quick Guide UTS3000A Series Quick Guide UTS3000A Series Signal Analyzer V1.0 July 15 , 2024 Instruments.uni-trend.com 1 / 26...
- Page 3 Foreword Dear Users, Hello! Thank you for choosing this brand-new UNI-T instrument. To use this instrument safely and correctly, please read this manual thoroughly, especially the Safety Requirements part. After reading this manual, it is recommended to keep the manual at an easily accessible place, preferably close to the device, for future reference.
- Page 4 Trademark UNI-T is the registered trademark of Uni-Trend Technology (China) Co., Ltd. Statement UNI-T products are protected by patent rights in China and foreign countries, including issued and pending patents. UNI-T reserves the rights to any product specification and pricing changes.
-
Page 5: Warranty Service
This warranty is written by UNI-T for this product, and it is used to substitute any other express or implied warranties. UNI-T and its distributors do not offer any implied warranties for merchant ability or applicability purposes. -
Page 6: Front Panel
Quick Guide UTS3000A Series Front Panel Figure 1-1 Front Panel Display Screen: Display area supports touch control Measurement: The main functions to active the signal analyzer, including: FREQ (Frequency): Press this key to enable the center frequency function and enter the ... - Page 7 Quick Guide UTS3000A Series marker to perform its functions. Advanced Functional Key: Press this key to active the advanced measurement functions, including: Meas/Setup (Measurement Setup): Press this key to set average/hold time, average type, display line, and limit value.
- Page 8 Quick Guide UTS3000A Series equipment damage or abnormal function. The RF IN port can only tolerate an input signal power of up to +30 dBm or a DC voltage of 50 V. TG SOURCE (Gen Output 50 Ω): This N-Female connector serves as the source output for the built-in tracking generator, with an input resistance of 50 Ω.
-
Page 9: User Interface
Quick Guide UTS3000A Series User Interface Figure1-2 User’s Interface Operating Mode: Signal analysis, vector signal analysis, EMI, and analog demodulation. Sweep/Measurement: Tap switch icon to quickly step through the sweep mode, either single or continuous. Measurement Bar: Displays measurement settings (input impedance, input attenuation, preset, correction, trigger type, reference frequency, average type, and average/hold). - Page 10 Quick Guide UTS3000A Series Letter in grey: Indicates the trace is not being updated. Letter in grey with strikethrough: Indicates the trace will not be updated and displayed. Letter in highlighted white with strikethrough: Indicates the trace is being updated but not ...
-
Page 11: Rear Panel
Quick Guide UTS3000A Series Rear Panel Figure 1-3 Rear Panel 10 MHz Reference Input: The signal analyzer can use either an internal reference source or an external reference source. If the instrument detects that the [REF IN 10 MHz] connector is receiving a 10 MHz ... - Page 12 Quick Guide UTS3000A Series Loading input signals on the output port is prohibited to prevent damage or abnormal function. Trigger IN: If the signal analyzer uses an external trigger, the connector receives the rising or falling edge of an external trigger signal. The external trigger signal is fed into the signal analyzer via a BNC cable.
-
Page 13: Safety Instruction
Users must follow the following conventional safety precautions in the operation, service and maintenance of this device. UNI-T will not be liable for any personal safety Warning and property loss caused by the user's failure to follow the following safety precautions. - Page 14 Quick Guide UTS3000A Series "Caution" indicates the presence of a hazard. It reminds users to pay attention to a certain operation process, operation method or similar. Product damage or loss of Caution important data may occur if the rules in the "Caution" statement are not properly executed or observed.
- Page 15 Quick Guide UTS3000A Series Primary electrical circuit of the electrical equipment connected to the indoor socket via the power cord, such as mobile tools, home CAT II appliances, etc. Household appliances, portable tools (e.g. electric drill), household sockets, sockets more than 10 meters away from CAT III circuit or sockets more than 20 meters away from CAT IV circuit.
- Page 16 Power fuse specifications (Class T, rated current 5A, rated voltage 250V) by the maintenance personnel authorized by UNI-T. There are no components available to operators inside. Do not remove the Disassembly protective cover.
-
Page 17: Environmental Requirements
If this device may be faulty, please contact the authorized maintenance Abnormity personnel of UNI-T for testing. Any maintenance, adjustment or parts replacement must be done by the relevant personnel of UNI-T. Do not block the ventilation holes at the side and back of this device. -
Page 18: Connecting Power Supply
Quick Guide UTS3000A Series Operating: Humidity at temperatures below +35℃, ≤ 90％ RH.; non-operating: Humidity at temperatures from +35 ℃ to 40 ℃, ≤ 60％ RH. Note There are ventilation openings on the rear and side panels of the instrument. Please ensure that air can flow through these vents. -
Page 19: Preparation Work
Activate the Option If you want to activate an option, you need to input the secret key for the option. Please contact the UNI-T office to purchase it. Refer to the following steps to activate the option you have purchased: 1. -
Page 20: Remote Control
Troubleshooting This chapter lists potential faults and their corresponding troubleshooting methods for the signal analyzer. Follow these steps to resolve issues. If the methods do not work, please contact UNI-T and provide your machine's information (acquisition method: [System] > Information). - Page 21 Calibrate the instrument regularly to compensate for any measurement errors caused by instrument aging. If calibration is required after the warranty calibration period, please contact UNI-T or obtain paid services from authorized measurement institutions. Instruments.uni-trend.com 20 / 22...
-
Page 22: Maintenance And Cleaning
Quick Guide UTS3000A Series Appendix Maintenance and Cleaning (1) General Maintenance Keep the instrument away from the direct sunlight. Caution Keep sprays, liquids and solvents away from the instrument or probe to avoid damaging the instrument or probe. (2) Cleaning Check the instrument frequently according to the operating condition. - Page 23 For product support outside mainland China, please contact your local UNI - T distributor or sales center. Many UNI-T products offer options to extend the warranty and calibration period. Please contact your local UNI-T dealer or sales center for more information.
- Page 24 PN:110401112646X...
