Page 9
Safely INstruction · Please read this manual carefully, also with related manual for the machine head before use. · For perfect operation and safety, installing and operating this product by trained personnel is required. · To avoid the abnormal running, please keep the product away from the high electromagnetic machine or electro pulse generator.
Page 10
2 Operation Panel Instructions 2.1 Operation Panel Display Instruction STOP Fig.2-1 Operation Panel Fig.2-2 LCD Display Icon Description Index Icon Description Index Automatic Trimming Free Sewing ① Soft start W Sewing ② Multi-section Start back tacking ③ Constant-Stitch Sewing End back tacking One-shot Sewing ④...
Page 11
Name Description Automatic Automatic trimming mode is enabled(icon on) or disabled. trimming After a half step After a half step function is enabled(icon on) or disabled. Thread sweeping Thread sweeping function is enabled(icon on) or disabled. Start sewing Start sewing function is enabled(icon on) or disabled. STOP 3 System Parameters Setting List 3.1 Technician Mode...
Page 12
The last sectionsupplement or reduced mode; 0 reduce, 1 supplement. Default 0 (W seam) Constant-stitch sewing of section count on and off: 1 2 E 0: ON 1:OFF range 0-1, default 0 Speed curve adjustments:0:ramp curve 1:polygonal curve. 1 3 0 0/1/2/3 2:quadric curve3:S-type curve 1 3 1...
Page 13
0: 203 parameter setting angle [TS] Department to conduct a tangent, until up needle stop after /4/5/6 the delay time set by 206 parameter [T2] so far. 1: 203 parameter setting angle [TS] Department to conduct a tangent, until No. 204 parameter setting angle [TE] so far.
Page 14
Then press the needle lifting locking button, can eliminate the needle lifting Lift needle locking locking state Power is off Please wait for 30 seconds, thenturn on the power switch Safety switch alarm Adjust the machine to the correct position. 3.4 Error mode If the error code appears, please check the following items first: 1.Make sure the machine has been connected correctly;...
Page 16
由於對產品的改良及更新 , 本產品使用說明書中與零件圖之產品及外觀的修改恕不事先通知 ! The specification and/or the equipment described in the instruction book and parts list are subject to change because of modification with out previous notice S007KD.AUG.2020...
