USA office: Fontana
AUS office: Truganina
GBR office: FDS Corporation Limited,Unit 4, Blackacre Road, Great Blakenham,Ipswich, Ip6 0FL,United Kingdom
Electric Barbecue Grill
EP25435GB
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Costway EP25435GB
Summary of Contents for Costway EP25435GB
- Page 1 Electric Barbecue Grill EP25435GB THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. USA office: Fontana AUS office: Truganina GBR office: FDS Corporation Limited,Unit 4, Blackacre Road, Great Blakenham,Ipswich, Ip6 0FL,United Kingdom...
-
Page 2: Before You Start
Electric Barbecue Grill Parts 1) IMPORTANT: Your Electric Barbecue Grill has been shipped with the components shown below. Check everything carefully before assembly or use. If any part is missing or damaged, do not use this product and ask qualified technician for help. 2) PRODUCT DIAGRAM 1. - Page 3 Assembly Instructions 3) SCREWS AND WASHER COMPONENTS NOTE: Tighten all connections by hand first. Once assembly is complete, tighten all connections fully. 16. Small Screw M5X12 (7 pcs) Step 1 – Attach Pillar to Base Hardware: M6X20 Medium Screw – 4pcs Lock Washer –...
- Page 4 Assembly Instructions 3) SCREWS AND WASHER COMPONENTS NOTE: Tighten all connections by hand first. Once assembly is complete, tighten all connections fully. 16. Small Screw M5X12 (7 pcs) Step 1 – Attach Pillar to Base Hardware: M6X20 Medium Screw – 4pcs Lock Washer –...
- Page 5 Step 2 - Connection Part Step 3 – Attach the Bowl Hardware: M6X20 Medium Screw – 4pcs Hardware: M6X20 Medium Screw – 5pcs Lock Washer – 4pcs M6 Large Wing Nut – 5pcs Flat Washer – 4pcs Lock Washer – 5pcs Flat Washer –...
- Page 6 Step 4 - Bowl Handles Step 5 – Bowl Hinge Bracket Hardware: M6 Large Wing Nut – 4pcs Hardware: M5X12 Small Screw – 2pcs Lock Washer – 4pcs Flange Nut – 2pcs Flat Washer – 4pcs Lock Washer – 2pcs Long Screw M6 x 45-4pcs Flat Washer –...
- Page 7 Step 6 – Lid Hinge Bracket Step 7 – Locking Pin Hardware: M5X12 Small Screw – 2pcs Hardware: Locking Pin M5*123 – 1pc M5 Small Wing Nut – 2pcs M5 Small Wing Nut – 1pc Lock Washer – 2pcs Lock Washer – 1pc Flat Washer –...
- Page 8 Step 8 – Air Vent Step 9 – Lid Handle Hardware: M5X12 Small Screw – 1pc Hardware: M6 Large Wing Nut – 2pcs M5 Small Wing Nut – 1pc Lock Washer – 2pcs Lock Washer – 1pc Flat Washer – 2pcs Flat Washer –...
- Page 9 Step 10 – Heating Components Step 11 – Cooking Grill Hardware: M5X12 Small Screw – 2pcs Place the cooking grill in the bowl. M5 Small Wing Nut – 2pcs Lock Washer – 2pcs Flat Washer – 2pcs Place the heat reflector plate in the bowl, then place the heating element in the bowl.
-
Page 10: Using The Temperature Control
Using the Temperature Control Step 12 – Oil Pan Place the oil pan into the connection part (part 11). Powering Up the Barbecue 1. Make sure the temperature control knob is fully turned to the “OFF” position.( Fig.1 part 7) Step 12 2. - Page 11 3. Plug the other end of the temperature control knob into a dry ground-fault circuit-interrupter (GFCI) power outlet. WARNING: DO NOT use an extension cord. ( see IMPORTANT SAFEGUARD again ) 4. Then adjust the setting on the control knob to the desired temperature level.
