USE AND CARE GUIDE
LAZY SUSAN CABINET
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this Cabinet. We strive to continually create quality
products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for
choosing Hampton Bay!
INTERNAL USE
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY LAZY SUSAN CABINET
Summary of Contents for HAMPTON BAY LAZY SUSAN CABINET
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this Cabinet. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for...
-
Page 2: Table Of Contents
Table of Contents Table of Contents ............2 Cabinet Assembly ............6 Safety Information ............2 Cabinet Assembly (Continued) ........8 CALIFORNIA RESIDENTS ............2 Cabinet Assembly (Continued) ........10 Cabinet Assembly (Continued) ........12 MINNESOTA RESIDENTS ............2 Cabinet Assembly (Continued) ........13 Warranty ................. -
Page 3: Introduction To Clickready Technology
Introduction to CLICKREADY Technology Powered by This cabinet uses PERMANENT Ready to Assemble (RTA) technology that CANNOT be disassembled. You must carefully review instructions and ensure proper alignment during assembly. All connectors and dowels must line up when assembling cabinet. Quantity of connectors/dowels depends on the cabinet type and size. -
Page 4: Pre-Assembly
Assemble the cabinet on a soft surface such as carpet or the cardboard container of this product. PEOPLE REQUIRED BASE CABINETS with a width greater than or equal to 27" , CORNER WALL CABINET, LAZY SUSAN CABINET, PANTRY, OVEN CABINET require two people to assemble. -
Page 5: Pre-Assembly
Pre-Assembly PACKAGE CONTENTS D (smaller than E) E (bigger than D) Part Description Quantity Back Panel (A1+A2) Side Panel (B1+B2) Face Frame (C1+C2) Middle Shelf Bottom panel Door Support bar Toe Kick (H1+H2) HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance. INTERNAL USE... -
Page 6: Cabinet Assembly
Cabinet Assembly Attaching the side panels into the face frame NOTE : Identification • B1 has one more female connector as shown. • C1 is wider than C2 . • C1 has the cut-out at the end. Start by placing the face frame (C1-C2) flat on a smooth surface that will not scratch or damage the face of the cabinet, such as a towel or piece of cardboard (1) from the packaging. - Page 7 Cabinet Assembly Assemble the back panels Install the back panel (A1) into the back panel (A2) by: aligning the male connectors on back panel (A1) to the female connectors on back panel (A2). Use both hands to firmly press the panel (A1) down at all locations with connectors to ensure they lock together tightly. IMPORTANT There will be a “clicking”...
-
Page 8: Cabinet Assembly (Continued)
Cabinet Assembly (Continued) Attaching the bottom panel. Place bottom panel (E) into grooves in the back panels (A1-A2). Use both hands to firmly press Bottom panel (E) at all locations with connectors to ensure (E) lock together with (A2) tightly. ... - Page 9 Attaching the Subassemblies (B1-C1). Install the SUBASSEMBLIES (B1-C1) which have been assembled in step #1 to the SUBASSEMBLIES (A1-A2-E) which have been assembled in step #3 by: aligning the wooden dowels & female connectors on back panel (A1) to the holes & male connectors on side panel (B1).
-
Page 10: Cabinet Assembly (Continued)
Cabinet Assembly (Continued) Installing the support bar. Install the Support bar (G) into the back panel (A2) by: aligning the male connectors on Support bar (G) to the female connectors on back panel (A2). Use both hands to firmly press the support bar (G) down at all locations with connectors to ensure they lock together tightly. - Page 11 Attaching the shelf pins. Insert 8 shelf pins (EE) into pre-drilled holes on the panels (A1-A2-B1) and (B2) on SUBASSEMBLIES (B2-C2) as shown. SUBASSEMBLIES (B2-C2) HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance. INTERNAL USE...
-
Page 12: Cabinet Assembly (Continued)
Cabinet Assembly (Continued) Attaching the middle shelf. CAUTION: 2 people are required. One person holds the shelf to prevent it from falling backwards Rotate the cabinet as shown below. Place the top of the cabinet about 20cm-30cm high with 2 assembly blocks (II) which are provided with package. ... -
Page 13: Cabinet Assembly (Continued)
Cabinet Assembly (Continued) Attaching the Subassemblies (B2-C2). Install the SUBASSEMBLIES (B2-C2) which have been assembled in step #1 to the cabinet. Use both hands to firmly press the side panels (B2) down at all locations with connectors to ensure it locks together with (A2) tightly. - Page 14 Attaching the toe kicks Slide part (H1) into the groove in the part (H2) to complete the toe-kick (H). Slide toe kick (H) into the grooves of the side panels (B1-B2), make sure the male connector on toe kick (H) is aligned with female connector on the bottom panel (E).
-
Page 15: Door Assembly
Door Assembly Attaching the Hinges Place the door (F) face down on a smooth surface that will not scratch or damage the face of the drawer, such as a towel or piece of cardboard (1) from the packaging. Install two hinges (HH) to the door (F). Secure each hinge in place with 2 screws (BB) Separate Hinge Into 2 Parts ... - Page 16 Door Assembly Installing the mounting plates to the cabinet Install the mounting plate of the hinges HH into the pre-drilled hole on the side panels (B1) and secure with 4 screws (BB) for each mounting plate. HH (Mounting plate) Installing the door to the cabinet ...
- Page 17 Door Assembly Attaching silicone pads Peel and stick four silicone pads (DD) onto the inside corners of each door. (OPTIONAL) Adjusting the door Door hinges are 6-way adjustable. Up or down adjustment – Loosen screw 1, align the door, and tighten screw 1. NOTE: It is critical that you do NOT overtighten screw 1.
-
Page 18: Before Putting In Use
Before Putting in Use Check before putting in use IMPORTANT: - Before putting in to use, use a rubber mallet and wooden pad to tap all locations with connectors to ensure they lock together tightly. - The wooden pad helps avoid damaging the product. CONNECTION CHECK □... -
Page 19: Handle Installation
Handle Installation HANDLE/KNOB INSTALLATION Countersink or counterbore screws when installing Handles/knobs to avoid scratching other cabinets when opening the Doors. RIGHT WRONG Care and Cleaning □ For normal spills, a damp cloth is sufficient. Dry the surface immediately. □... - Page 20 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use. INTERNAL USE...
