Page 1: Instruction Manual
MP186 MP3 & VIDEO PLAYER with FM radio Instruction manual please read this manual carefully before operation... - Page 2 Read Before USE (1) Do not use this player in extremely hot, cold, dusty environment. (2) Do not rub or impact this player with hard things. (3) Please charge MP4 timely. (4) Do not use this player in extremely dry environment in case of electrostatic shock. (5) Do not use the player while driving.
- Page 3 Key Operation PLAY: Play/Pause /On/Off MENU: Return to the menu/Enter to the menu VOL+: Increase Volume VOL-: Decrease Volume NEXT: Next. Fast backward PREV: Last. Fast forward A/B: A/B Repeat Power: Power On/ Power Off Key definition Key press includes: short press/long press /press/press once. (NO definition, belongs to short press) Short press: Will be valid when press Long press: Will be valid if pressing after 2 seconds.
- Page 4 Use player first step Player connects with the PC USB connection Note: It applies to WIN 98 and WIN98 SE users. If connect with PC and cannot find moveable CD for other windows users, you can fix the random USB drive. Player connects with computer Through USB cable, the player can connect with the PC USB port.
- Page 5 When system prompts safely detachment of the hardware, only then you can pull out the player from the USB connection. If above steps not completed, pull out the player may cause great error or the data of the player will get lost. Display and operation explanation Power on Power off...
- Page 6 Music In main menu state, select the MUSIC option, you will get into the stop state of the music pattern as default. Waiting status playing status Pause status Under music play or pause state, short press the MENU key to enter the submenu: Repeat Mode, Equalizer, and 3D, Play Rate, File Browse, Classification, Playlist, Slide Show, and ACL.
- Page 7 A/B Repeat function Under play condition, press the A/B key one time, choose the start point of the repetition; press A/B key two times, then choose repetition end point, and start to duplicate broadcasts the paragraph which has been selected; press A/B key for the third time, then cancels the repeat paragraph.
- Page 8 Press the play key again, you can adjust the FM frequency by hand through the NEXT/PRVE key. Press the MENU key then get into FM Submenu, through the NEXT/PREV key, you can select: Save Station, Auto Scan (as picture 2) If you select the “Save Station”...
- Page 9 1. Long press the MENU key to enter the main menu, through pressing NEXT/PREV key and select the Photo interface, then through PLAY key to confirm. When entering from the main menu, the condition is the selection of the file. (As picture 1) If there is no document, the directory is empty.
-
Page 10: File Browse
MPMANAGER manual is included in your CD-ROM. FILE BROWSE 1. Long press the MENU key to enter the main menu, through pressing NEXT/PREV key and select the FILE BROWSE interface, then through PLAY key to confirm. When entering from the main menu, the condition is the selection of the file, press the play key to confirm your selection. - Page 11 VOL key to start record. After completing recording, long press the mode key for confirmed, there will be a LINE_REC folder for storage of Line-in recording files in your player, you are able to choose the recorded file you wanted. The details operation, please refer to the record.
- Page 12 You could download the music (mp3 or wma) files through USB port of your PC to your player and following show the downloading status: Store digital audio files on your computer; Transfer files to your Network Walkman; Enjoy music with your Net work Walkman. Transform tool for use Open the folder of “MTVConverter_V2.12.0.”...
- Page 13 (4) Click “Next>” to enter into next step. (5) Close the Driver (G:) window, then clicks “OK” to finish setup process and restart your computer now, then you can use the MP4 player. 2. Format the MP4 player The MP4 player is “FAT 32” format. If you wish to format it, right click removable disk and choose “Format”...
- Page 14 Technical Specification Dimension 90*40*7.7mm Display TFT (1.8 inches) Memory 64M/128/256/512MB; 1/2/4/8/16 GB(It is normal that the sys file hold same place) USB2.0 Power Polymer lithium battery Playback time 5 hours Record Format Time 8Hours128M Flash >= 80dB Output Max 5mw*1(32ohm) earphone Natural, PoP, Rock, Classial, Jazz, Bass, CUSTOM EQ...
- Page 15 Picture format Jpg,Bmp Windows98/SE/ME/2000/XP/2003/LINUX2.42 Bit rate MP3:8-320kbps Wma:32-192kbps Notice: Attention should be drawn to the environmental aspects of battery disposal. Can’t identify the sixth and above sixth level of directory. The user guide is only for reference. It is standard by the sample.
