Thank you for selecting and buying V-TAC Product. V-TAC will serve you the best. Please
read these instructions carefully & keep this user manual handy for future reference. If you
have any another query, please contact our dealer or local vendor from whom you have
purchased the product. They are trained and ready to serve you at the best.
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
INSTRUCTION MANUAL
100AH RECHARGEABLE
LI-ION BATTERY MODULE
MODEL
DESCRIPTION
OHS-HV100
HIGH VOLTAGE BATTERY CLUSTER CONTROL BOX
OH-5K
51.2V 100AH RECHARGEABLE LI-ION BATTERY MODULE
OH-BASE
BATTERY MODULE BASE
INTRODUCTION
WEEE Number: 80133970
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for V-TAC OHS-HV100
Summary of Contents for V-TAC OHS-HV100
- Page 1 BATTERY MODULE BASE INTRODUCTION Thank you for selecting and buying V-TAC Product. V-TAC will serve you the best. Please read these instructions carefully & keep this user manual handy for future reference. If you have any another query, please contact our dealer or local vendor from whom you have purchased the product.
-
Page 2: Table Of Contents
___________________________________________ Content 1. Introduction ............................3 1.1 Important Safety Instructions ....................3 1.2 Symbols ...........................4 1.3 Brief Introduction ........................5 1.4 Product Properties ........................5 2. Product Specification ........................6 2.1 Size and Weight ........................6 2.2 Performance Parameter ......................7 2.3 Equipment Interface Instruction .................... 8 3. - Page 3 ___________________________________________ 5.1.3 Tools and data ......................37 5.1.4 Technical preparation ....................37 5.1.5 Unpacking inspection ....................37 5.2 Equipment installation ......................39 5.2.1 Installation Steps ....................... 39 5.2.2 Battery parameter settings on the inverter .............. 41 6. Installation and Configuration ......................41 6.1 Battery system usage and operation instructions ...............
-
Page 4: Introduction
___________________________________________ 1. Introduction 1.1 Important Safety Instructions Danger! Please do not put the battery into water or fire, in case of explosion or any other situation that might endanger your life. Please connect wires properly while installation, do not reverse connect. ... -
Page 5: Symbols
___________________________________________ 1.2 Symbols Description Symbols Warning electric shock. Caution! Warning! Reminding. Safety related information. Risk of battery system failure or life cycle reduces. Warning Fire. Do not place near flammable material Do not place near open flame. Read the product and operation manual before operating the battery system! Grounding. -
Page 6: Brief Introduction
___________________________________________ 1.3 Brief Introduction 51.2V100AH lithium iron phosphate battery system is a standard battery system unit, customers can choose a certain number of 51.2V100AH according to their needs, by connecting series to form a larger capacity battery pack, to meet the user's long-term power supply needs. The product is especially suitable for energy storage applications with high operating temperatures, limited installation space, long power backup time and long service life. -
Page 7: Product Specification
___________________________________________ 2. Product Specification 2.1 Size and Weight Table 2-1 Device size Nominal Voltage Nominal Capacity Dimension Weight Product （V） （Ah） （mm） （Kg） OHS15K-100 153.6 590*420*698 173.9 OHS20K-100 204.8 590*420*849 222.4 OHS25K-100 590*420*1000 270.9 OHS30K-100 307.2 590*420*1151 319.4 OHS35K-100 358.4 590*420*1302 367.9 OHS40K-100... -
Page 8: Performance Parameter
___________________________________________ 2.2 Performance Parameter Table 2-2 performance parameter Technical specification 15KWH 20KWH 25KWH 30KWH 35KWH 40KWH Installation Mode Stackable Battery Type LifePO4(LFP) Module Energy(kWh) 5.12 Module Nominal Voltage(V) 51.2 Module Capacity(Ah) System Model OHS15K-100 OHS20K-100 OHS25K-100 OHS30K-100 OHS35K-100 OHS40K-100 Battery Module Qty InSeries(Optional) System Nominal Voltage(V) 153.6... -
Page 9: Equipment Interface Instruction
___________________________________________ 2.3 Equipment Interface Instruction 2.3.1 This section details the front and back interface functions of the battery pack Product Front Interface Control Box Module Front Interface 10 11... - Page 10 ___________________________________________ Table 2-3 Interface Definition Item Name Definition Power Connector For battery pack connect in series Screen Show battery information Air Switch Current Protection BMS ON/OFF Start BMS Ground Point Ground Point WiFi WiFi Positive Output DC + To Inverter Negative Output DC - To Inverter Communication Port...
-
Page 11: Ohs's User Interface
___________________________________________ 3. OHS’S User Interface 3.1 Main Interface Description Function Display real-time SOC value of energy storage system Voltage Display real-time voltage Temperature Displays the maximum and minimum battery temperatures Voltage Displays real-time maximum and minimum cell voltages Current Display battery real-time current System status Display battery fault name (For details, see Table 6-1) -
Page 12: Cell Voltage
___________________________________________ 3.2 Cell Voltage 3.3 Cell Temperature... -
Page 13: Heating Temperature
___________________________________________ 3.4 Heating Temperature 3.5 Relay Status... -
Page 14: Other
___________________________________________ 3.6 Other 3.6.1 Heating Information... -
Page 15: Insulation Resistense
___________________________________________ 3.6.2 Insulation Resistense 3.6.3 Diagnostic Information... -
Page 16: Cumulative Time Information
___________________________________________ 3.6.4 Cumulative Time Information 3.7 Set Up... -
Page 17: Xiaodan Energy Storage App
___________________________________________ 4. Xiaodan Energy Storage App 4.1 App download 4.1.1 Android version Enter the official website of Youdan Technology https://www.udantech.com/#/ , click on the "SAAS Application" column in the top navigation bar, pull down to the mobile app application module, and you can see the mobile WeChat Mini Program and App application download. -
Page 18: Ios Version
___________________________________________ 4.1.2 iOS version Enter the mobile App Store, search for "Xiaodan Energy Storage", and you can download and install it. 4.2. Log in and register 4.2.1 Log in After opening the APP, enter the login interface to log in with your account. •... -
Page 19: Register
___________________________________________ 4.2.2 Register At the bottom of the login page, click the "Account Registration" button to enter the • registration process. -
Page 20: Experience Login
___________________________________________ Currently, you can register with an email account. After registration, you need to go • through the device verification process and enter the device SN code or device QR code for identification. 4.2.3 Experience login At the bottom of the login page, click the "Experience Login" button to experience •... -
Page 21: Equipment Distribution Network
___________________________________________ 4.3. Equipment distribution network 4.3.1 Overview Device distribution network refers to connecting devices to the Cloud Computing Platform to help users obtain real-time device data information. 4.3.2 Distribution process Preparation before distribution: Ensure that the device is on , turn on the mobile phone Bluetooth and wireless LAN functions. - Page 22 ___________________________________________ Connected devices: The current App supports Bluetooth search, device scanning, and manual input of SN code .
- Page 23 ___________________________________________...
- Page 24 ___________________________________________ Connect to WiFi: After the device is connected, enter the WiFi connection process. Select the WiFi you want to use and click the "Connect" button. Enter the WiFi • password and click the "Finish" button to distribute the network.
- Page 25 ___________________________________________...
-
Page 26: App Page
___________________________________________ 4.4. App page 4.4.1 Equipment The device homepage is used to display the currently managed device information. - Page 27 ___________________________________________ The top area displays the device name, battery energy, and message entry. •...
- Page 28 ___________________________________________ Middle area: Displays the current battery charging and discharging status, battery • percentage, current power, and estimated full time. The bottom area: Displays the device battery, charging time, and health check • overview data of the day in the form of a card. You can click the corresponding card to view the details.
-
Page 29: Data Details
___________________________________________ 4.4.2 Data details Display the data details of the current device, and view the battery, charging and discharging power, and charging and discharging time data separately, and support time filtering. 4.4.3 Mine My page allows users to view my devices, add devices, configure WiFi, software updates, after-sales services, problem feedback, app settings . - Page 30 ___________________________________________ Click "My Devices" to enter Facility Management. You can view all devices • managed under the current account, switch devices displayed on the homepage, unbind devices, and other operations.
- Page 31 ___________________________________________ Click "Add Device" to enter the code scanning page. • Click "Equipment Distribution Network" to enter the equipment distribution network •...
- Page 32 ___________________________________________ process. After clicking "software update", it will enter the version detection. If there is a new • version, it will be updated. Click "after-sales services" and enter the after-sales services page to display the • after-sales services declaration of the current supplier.
- Page 33 ___________________________________________ Click "Feedback" to enter the feedback page. You can enter the current problem • that needs feedback and submit it.
-
Page 34: Message
___________________________________________ 4.4.4 Message Click on the device or my page, the message icon above, you can enter the inbox page... -
Page 35: App Settings
___________________________________________ to view the current notification or chat history. 4.4.5 App settings Click My Pages - Settings icon in the upper-right corner to enter the App Settings •... - Page 36 ___________________________________________ page. Settings page support: language switching, Privacy Policy, cache cleaning, • personal information, account and security.
-
Page 37: Installation And Configuration
___________________________________________ 5. Installation and Configuration 5.1 Preparation for installation 5.1.1 Safety Requirement This system can only be installed by personnel who have been trained in the power supply system and have sufficient knowledge of the power system. The safety regulations and local safety regulations listed below should always be followed during the installation. -
Page 38: Tools And Data
___________________________________________ 5.1.3 Tools and data Tools and meters that may be used are shown in table 5-1. Table 5-1 Tool instrument NAME Screwdriver（Slotted、Phillips） Multimeter Torque wrench Clamp current meter Diagonal pliers Insulation tape Pointed nose pliers Temperature meter Pliers to hold the wire Anti-static bracelet Stripping pliers Cable tie... - Page 39 ___________________________________________ Packing list is as follows: Item Specification Quantity Figure 51.2V/100AH Battery module 5.12Kwh High voltage battery cluster control box Battery module base Positive Cable to Red/8 AWG inverter /L2000mm Negative Cable to Black/8 AWG inverter /L2000mm Communication Cable L2000mm to inverter Communication Cable L1000mm...
-
Page 40: Equipment Installation
___________________________________________ 5.2 Equipment installation 5.2.1 Installation Steps Step 1 Mechanical Installation (1) Installation step: Step 4: Install side fastening screws Step 3: Install the High voltage battery cluster control box Step 2: Install the Battery module Step 1: Install the Battery module base... - Page 41 ___________________________________________ Step 2 Electrical installation (1) Connect with inverter...
-
Page 42: Battery Parameter Settings On The Inverter
___________________________________________ 5.2.2 Battery parameter settings on the inverter If your inverter do not have communication function with OHS-100 battery pack, please set inverter follow next data. Max Charging(module) Voltage: 56.0V*N Shut Down(cut off) Voltage: 49.0V*N（SOC20%） Shut Down(cut off) SOC: 20% Restart Voltage: 51.2V*N Max Charge Current: 50A... -
Page 43: Alarm Description And Processing
___________________________________________ 6.2 Alarm description and processing When protection mode is activated or system failure occurred, the alarm signal will be given through the system status on the LCD. The network management can query the specific alarm categories. If the fault such as single cell over voltage, charging over-current, under-voltage protection, high-temp protection and other abnormalities which affects the output, please deal with it according to Table 6-1. -
Page 44: Battery Module Storage
___________________________________________ Communication fault The battery type of the Check these possible causes one by one inverter is wrong/ Communication cable used incorrectly/The communication cable is incorrectly connected at the battery communication port or the inverter communication port/The battery firmware version is too low to support the inverter If you need any technical help or have any question, please contact the dealer in time. -
Page 45: Maintenance
___________________________________________ 8 Maintenance Warning! Improper decommissioning may cause damage to the equipment and/or battery inverter. Before maintenance, ensure that OHS-100 is decommissioned according to relevant provisions. Note: All maintenance work shall comply with local applicable regulations and standards. The USB-CAN port of OHS has the functions of upgrading firmware and recording battery data, which can be used as an auxiliary tool. -
Page 46: Legal Statement
Please use the link below to view the online directory of the collection and return points:https://www.ear-system.de/ear-verzeichnis/sammel-und-ruecknahmestellen Legal Statement The information contained in the document is the property of V-TAC Europe Ltd. All information shall not be published in whole or in part without the written permission of V-TAC Europe Ltd.
