5. SET THE COM LOOP ADDRESS

5.1.

AUTO ADDRESSING

The 4585 supports automatic addressing via EBLWin.
For more information, see the Planning Instructions for the system.
The unit connected to power supply output 0 will get the 4466 technical address plus one. The unit connected to power supply
output 1 will get the 4466 technical address plus two.
The 4585 unit will automatically be addressed via the External power supply 4466 unit.
5.2.

WHEN POWER SUPPLY 4466 IS MANUALLY ADDRESSED

The 4585 units can only be addressed by the CIE via the 4466 (auto addressing). If manual addressing is used for the 4466, the
4585 unit will get it´s address automatically when the loop is connected / re-enabled to the CIE.
Add the configuration for 4585 manually in EBLWin. The unit connected to power supply output 0 must have the 4466 technical
address plus one. The unit connected to power supply output 1 must have the 4466 technical address plus two.
5.2.1.

CHECK LOOP

If a 4585 unit without address is found during check loop, the CIE will report it to EBLWin with the correct address, i.e. the address
of the 4466 unit plus one or two. This way, a correct SSD can be created after the check loop procedure is finished.
Once the SSD is download to the CIE the CIE will automatically address the 4585 unit.
