Page 1: Table Of Contents
…………..14-16 3.2 free (510XXX) on viveroo MountingSet …………………18 3.3 Installation Wallbox PoE (310400) …………..19-20 3.4 free PoE (510XXXPD) on viveroo Wallbox PoE ……………21-22 3.5 free direct mounting on the wall (mounting without flush-mounted box) …………………23 3.6 Locking system (Accessories) REV20240708...
Page 2: Safety Instructions
(mechanics, ﬁre protection, etc.). If it can be assumed that safe operation is no longer possible, the free must be taken out of service immediately and secured against unintentional operation.
Page 3: Warranty
ﬁrst. Claims for defects If your free does not work as desired, please contact your dealer with the original invoice, stating the serial number and a description defect validation of the malfunction.
Page 4: Technical Data
Electrical power consumption 12.5 watts - 25 watts depending on iPad and power supply unit Disconnect from You can disconnect the free from the mains voltage via the corresponding circuit breaker in the the mains respective room. Technical changes and errors excepted.
Page 5: Product Dimensions
  2.2 Product dimensions free iPad mini (6.Gen) Compatible iPad model numbers: A2567, A2568, A2569 iPad 10,2 (9.Gen) Compatible iPad model numbers: A2197, A2200, A2198, A2428, A2429, A2430, A2602, A2603, A2604, A2605 iPad 10,9“ (10.Gen) Compatible iPad model numbers: A2696, A2757, A2777 iPad Pro 11“...
Page 6   2.2 Product dimensions free iPad Pro 11“ (2024 M4) Compatible iPad model numbers: A2836, A2837, A3006 iPad Pro 12,9“ / iPad Air 13“ (2024 M2) Compatible iPad model numbers: A1876, A2014, A1895,A1983, A2229, A2069, A2232, A2233, A2378, A2379, A2461, A2462, A2436, A2437, A2764, A2767, A2898, A2899, A2900 iPad Pro 13“...
Page 7: Operation
The charging symbol in the display guarantees that the iPad is securely in place. For free in portrait format: Place the iPad in the top left of the vertical free guide rail. Push it downwards towards the connector by applying light pressure against the guide rail.
Page 8: Scope Of Delivery
- PoE adapter Scope of delivery - Installation instructions Inwall MountingSet Inwall - free flush-mounted cavity wall box with installation support plate incl. (310202) until 08/2024 spirit level - Power supply unit (IN: 100-240 Vac, 50/60 Hz 0.8A OUT: 5.2 Vdc)
Page 9: Further Information
The image shown on the left always refers to the adjacent text on the right. The orange numbers Charts (from page indicate an action in the image on the left. For example: Slide the iPad into the free mount. 11): Seite von...
Page 10: Installation Mountingset (310202/310205)
3. Mounting the viveroo free wall mount 3.1 Installation MountingSet (310202/310205) 3.2 free (510XXX) on viveroo MountingSet 3.3 Installation Wallbox PoE (310400) 3.4 free PoE (510XXXPD) on viveroo Wallbox PoE 3.5 free direct mounting on the wall (mounting without flush-mounted box) 3.6 Locking system (Accessories)
Page 11 3.1 Installation Installation MountingSet (310202/310205) For installation in landscape format, drill two adjacent holes in the wall with a centre- to-centre distance of 71 mm, ensuring an installation depth of 75 mm. ! Note: These instructions show installation in a cavity wall (1).
Page 12 3.1 Installation Installation MountingSet (310202/310205) Installation with flush-mounted boxes: Fasten the flush-mounted box to the wall using the four cross-head lag screws (7). For other installation situations such as concrete or masonry, please read the notes in these instructions on page 9. Loosen the four screws of the mounting plate...
Page 13 Finally, check that the flush-mounted cavity wall box is securely seated in the wall. You have now successfully completed all the steps in section 3.1. If you have any further questions, please do not hesitate to contact our sales team: sales@viveroo.com Seite...
Page 14 (12) on the outer left-hand side. This sits outside the box directly on the wall and gives the free additional stability if required. Depending on the nature of the wall, please select the appropriate fastener (dowel + screw, wood screw or similar).
Page 15 (13) coming from the free (14) to the corresponding socket in the flush-mounted cavity wall box. Attach the free to the spacer plate using the enclosed screws (16) (countersunk screw 8 mm). Finally, tape over the screw points with the felt buttons (17).
Page 16 3.2 Installation free (510XXX) on viveroo MountingSet Now slide your iPad (18) from left to right into our free mount. You have now successfully completed all the steps in section 3.2. If you have any further questions, please do not hesitate to contact our sales team: sales@viveroo.com...
Page 17 DeepBlack viveroo SuperSilver Be impressed by our colour variations!
Page 18: Installation Wallbox Poe (310400)
Fasten the flush-mounted cavity wall box to the wall using the four cross-head lag screws (3). You have now successfully completed all the steps in section 3.3. If you have any further questions, please do not hesitate to contact our sales team: sales@viveroo.com Seite...
Page 19: Free Poe (510Xxxpd) On Viveroo Wallbox Poe
  3.4 Installation free PoE (510XXXPD) on viveroo Wallbox PoE Loosen the four screws of the mounting plate of the flush-mounted box and remove it. Connect our PoE adapter to your CAT cable and place the adapter in the flush- mounted box so that the USB-C opening of the adapter is facing to the right.
Page 20   3.4 Installation free PoE (510XXXPD) on viveroo Wallbox PoE Take the cable (10) that is attached to the free bracket (11) and connect it to the PoE adapter in the flush-mounted box. Attach the free (11) to the spacer plate using the enclosed screws (12 ) (countersunk screw 10 mm).
Page 21: Free Direct Mounting On The Wall (Mounting Without Flush-Mounted Box)
3.5 Installation   free direct mounting on the wall (mounting without flush-mounted box) These instructions show installation in front of a wall without a flush-mounted box. The free is mounted here as an example in landscape format. You can ﬁnd a suitable template in the download area on our website.
Page 22   3.5 Installation free direct mounting on the wall (mounting without flush-mounted box) Attach the free to the spacer plate using the enclosed screws (countersunk screw 10 mm). Finally, stick the felt buttons over the screw points. Now slide your iPad from left to right into our free holder.
Page 23: Locking System (Accessories)
(350102/350104) These instructions describe the installation of the locking system for the viveroo free. The locking system can be offered as an add-on and retroﬁtted at a later date. However, you will need our viveroo free spacer plate for this.
Page 24 Operating instructions Wall mount viveroo free Our sales team will be happy to answer any further questions you may have sales@viveroo.com REV20240708...
