Summary of Contents for BassBoss KRAKATOA-MK3
- Page 1 User Manual Krakatoa-MK3 Quintuple 18” 4-Way Co-Axial Point Source Powered Loudspeaker...
-
Page 2: Table Of Contents
Combining Speakers Outboard Processing Specifications Warning Warranty Setup Procedure Safety Information Operation & Controls Important Notes Indicator LEDs FCC Compliance Notice How to Use the Presets Este manual está disponible en español en nuestro sitio web en bassboss.com/support Krakatoa-MK3 User Manual... -
Page 3: Overview
In short, this design allows the loudspeaker to deliver consistent audio performance, with all frequencies arriving at the listener’s ears simultaneously, which improves intelligibility and impact as well as providing excellent imaging and sound staging. The Krakatoa-MK3 represents a significant advancement in loudspeaker technology, offering unparalleled sound quality and versatility for professional audio applications. -
Page 4: Quick Start Guide
Key Features: • Phase Aligned: Seamlessly integrates with other BASSBOSS speakers • Full Range Reproduction: Covers all audible frequencies from 25 Hz to 18,000 Hz • Versatility: Ideal for live sound reinforcement and high end audio systems • High Efficiency and Power Handling: Suitable for larger spaces without quality compromise •... -
Page 5: Combining Speakers
Combining Speakers BASSBOSS systems are easy to set up quickly. The best possible results are achieved consistently because of the integrated nature of the designs. All BASSBOSS loudspeakers are complete, integrated systems, featuring the cabinet, transducer, amplifier and a comprehensive suite of processing. Setup is particularly easy because the products integrate with each other. -
Page 6: Outboard Processing Warning
The internal processing can accomplish everything an external processor could accomplish without degrading the sound quality and without putting components at risk. Before considering using an outboard processor, contact BASSBOSS customer service with your use-case scenario for assistance in setting up the internal processing to achieve your goals. -
Page 7: Operation & Controls
BASSBOSS powered speakers. signals. The amplifier will simply amplify the clipped signal, which can do the same damage as clipping Presets help you fine-tune the balance between the an amplifier. -
Page 8: Indicator Leds
Comm Link Illuminates when the device is assigned an IP address by a router or is communicating with the software. Indicator LEDs, Right Side, Bottom to top Presets 1-8 The illuminated LED indicates the corresponding preset is loaded. Krakatoa-MK3 User Manual... -
Page 9: How To Use The Presets
All the presets in the Krakatoa are compatible with all the presets in the Kraken, Makara, ZV28, VS21 and all the other subs in the BASSBOSS line. When the subwoofer levels are to be run higher than tops levels, (which is almost always) the effective crossover moves higher in frequency. -
Page 10: Pre-Installed Onboard Presets
Preset 9 70Hz high-pass filter For more information and setup tips on how to get the best and most All Max SPL presets are compatible with all BASSBOSS out of your system check out the subwoofer models Knowledge BASS help.bassboss.com Additional presets are accessible through software. -
Page 11: Power Distribution
6. Is the signal flowing to the input full-range? Filters in the signal may remove the operating frequencies of the loudspeaker receiving them. 7. If you’re connected via LAN, check the level and filter settings in the software. bassboss.com 11... -
Page 12: Specifications
LEDs for Power on/ready, Signal, -12dB, -6dB, Limiter Active, Thermal, Protect and LAN Link Active. Eight LEDs indicating selected preset Signal Input Connector XLR-F Signal Output Connector XLR-M (Direct pass-through, unprocessed) LAN Connectors EtherCON RJ45 (x2) with 2-port Ethernet switch Krakatoa-MK3 User Manual... - Page 13 Birch plywood flat cart with 4 locking wheels and recesses to accept the Optional Dollies cabinet sliders. Transports 1 or 2 cabinets Hardware M10 Shoulder Eye Bolts, M10 Side-Pull anchors Cover Heavy-duty padded nylon transport cover Our proactive philosophy causes specifications to be subject to change whenever improvements are made. bassboss.com 13...
-
Page 14: Warranty
BASSBOSS personnel. Service will be performed upon the return of the failed unit, together with its original sales receipt or other proof of purchase, to BASSBOSS or an Authorized Service Facility. Purchaser is responsible for all costs of shipping and handling. Cosmetic damage is specifically excluded from this warranty. -
Page 15: Safety Information
The audio system must comply with current local standards and regulations regarding electrical systems. For installation purposes, BASSBOSS strongly recommends that this product be installed by a qualified, professional installer who can ensure correct installation and certify that it is installed in compliance with the regulations in force. -
Page 16: Important Notes
Manufacturer True Lee Loudspeakers | BASSBOSS 2028 E Ben White Blvd. #240-8220 Austin TX 78741 We declare, under our sole responsibility, that to the best of our knowledge to which this declaration relates, our products are in conformity with the applicable requirements. - Page 17 17...
- Page 18 Quintuple 18” 4-Way Krakatoa-MK3 Powered Loudspeaker Need more assistance? We’re here to help. help.bassboss.com...
