- Page 1 User Manual CL873 053C4819-EN...
-
Page 2: Table Of Contents
1.2 Wiring Diagram ..............02 consequences of its use. Spedal CL873 shall not be liable for any damage, injury, or legal liability caused by the direct or indirect use of this product. -
Page 3: Packaging & Product
1. Packaging & Product 1.1 Packing List ● Main Unit ● Bracket ● Tool Kit ● Power Cable ● Quick Release Cable ● Wired Remote(Optional) ● Camera(Optional) ● TPMS Service Pack(Optional) ※ The packaging content of this product may change without prior notice. -
Page 4: Wiring Diagram
Red wire: ACC power. 1.2 Wiring Diagram Yellow wire: connected to the positive pole of the power supply. Black wire: connected to the negative pole of the power supply or GND. Power Wired remote Front cam ※ ACC Power Supply : A power supply can be identified as being in the ACC state when the motorcycle’... -
Page 5: Installation
2. Installation 2.1 Bracket Installation ① Align the screw holes of the rectangle metal plate on the bracket with the screw holes on the back of the main unit. Tighten the screws. ② Secure the bracket onto the motorcycle handlebar and tighten the screws. -
Page 6: Wired Remote (Optional) Installation
2.2 Wired Remote (Optional) Installation ① Peel off the backing paper of the semi-circular adhesive sticker and stick it above the curve of the A-shaped metal plate. Remove the other side of the protective paper and fix the A-shaped metal plate near the motorcycle handlebar. -
Page 7: Camera (Optional) Installation
2.3 Camera (Optional) Installation 2.4 TF Card (Optional) Installation Transfer Speed R & W Speed Waterproof Rating Image Resolution Class 10 IP65 1920*1080 Maximum Capacity Field Of View 256GB 137° Open the bottom cover of the main unit and insert the TF card into ①... -
Page 8: Tire Pressure Sensor (Optional) Installation
2.5 Tire Pressure Sensor (Optional) Installation ① Enter the tire pressure binding interface and select the tire you want to bind. ② Install the tire pressure sensor on the corresponding tire. The installation steps are as follows: a. Remove the tire valve cap. b. -
Page 9: Features And Settings
3. Features and Settings 3.1 Home Screen Zone B 4.8V TF card status Bluetooth connection status WiFi status 4.8V Current voltage status Zone C CarPlay Auto WiFi Video Front tire pressure status Rear tire pressure status Bar B Audio Playback Setting Zone D Enter Apple CarPlay mode... -
Page 10: Apple Carplay
① Go to the "Settings" menu on your iPhone and enable Bluetooth and Wi-Fi. Click on on the main screen to enter the Apple CarPlay mode. CarPlay Auto WiFi Video Settings Open iPhone Bluetooth connection: Spedal-**** Setting Bluetooth Bluetooth Search ****** XXX-XXXXXX Connect ****************... - Page 11 ② Go to the "Bluetooth" menu and under the "OTHER DEVICES" list, ③ Wait for about 20-30 seconds, and your iPhone will display a select the Bluetooth named "Spedal-****". "Bluetooth Pairing Request" window. Select "Pair". Bluetooth < Settings Bluetooth Now discoverable as “X6”.
- Page 12 ④ Your iPhone will then prompt you with a "Use CarPlay with ⑤ Wait for a moment, and you will enter CarPlay mode. 'SmartScreen'?" window. Select "Use CarPlay". ※ Note: ● Please make sure your iPhone supports Apple CarPlay. For more details, please visit: https://www.apple.com/ios/car- play/ ●...
-
Page 13: Android Auto
Auto CarPlay WiFi Video Settings Open Android phone Connected devices Bluetooth connection: Settings Bluetooth Search settings Spedal-**** Search settings Pair new device Network and Internet On > Mobile,Wi-Fi,hotspot Prevlously connected devices Network and Internet Connected device > See all Bluetooth,pairing... -
Page 14: Connected Devices
② Tap on the "Bluetooth" menu to access the Bluetooth search ④ From the list of Available devices, select the Bluetooth named page. "Spedal-******". ③ Click on "Pair new device". Connected devices Pair new device Device name + Pair new device... - Page 15 ⑤ Wait for about 20 seconds, and your phone will display a "Pair ⑥ Wait for a moment, and you will enter Android Auto mode. with Spedal-******" window. Select "Pair". ※ Note: ● Please make sure your phone is running on Android 11 or above and supports 5GHz Wi-Fi and Google Play services.
-
Page 16: Dvr
3.4 DVR Click on on the main screen to enter the DVR mode. Start Recording Return to the main screen Stop Recording Enter Audio Output mode Unlock the current recording Record with audio Lock the current recording Record without audio Take a photo of the current frame... -
Page 17: Playback
3.5 Playback Click on on the main screen to enter the Playback mode. Exit xxxx-xxxxx.TS Video files xxxx-xxxxx_SOS.TS Lock video files xxxx-xxxxx.TS xxxx-xxxxx.JPG xxxx-xxxxx_SOS.TS Photo files xxxx-xxxxx.JPG 00:00:00/00:00:00 Play the current video Play the next video Playback progress / Total video duration 00:00:00/00:00:00 Full screen playback... -
Page 18: Setting
3.6 Setting Rear mirror Image Click on on the main screen to enter the setting mode. To set the rear camera to record mirrored footage, you can choose between the following options: Turn off or Turn on. Brightness AUTO Adjust the screen brightness, or set it to Auto dimming. Language Assistive touch To set the system display language, you can choose from the... -
Page 19: Tire Pressure Monitoring Settings
3.7 Tire Pressure Monitoring Settings Click on Zone C on the main screen to enter the Tire Pressure Monitoring Settings mode. ● Vehicle type 4.8V Set the vehicle type, which can be set as two wheeled, three wheeled, or four-wheel. ●... -
Page 20: Firmware Upgrade
3.8.1 OTA Upgrade ③ Power off the device and remove the TF card. ① Prepare a Windows-based computer and a card reader. ④ Open the computer and visit the Spedal official website's down- load page at https://spedal.cc/html/en/support/download/navi- ② After powering on the device, go to "Setting" - "Format" to cam.html. - Page 21 3.8.2 Burn TF Card Upgrade ● TF card burning ① Open the computer and visit the Spedal official website's down- load page at https://spedal.cc/html/en/support/download/navi- ● Preparation cam.html. Download the latest firmware according to the model. ① Prepare a computer and a card reader.
- Page 22 ● Main unit firmware upgrade ● Check firmware ① Insert the TF card into the main unit and power it on. ① Insert the TF card into the main unit and power it on. ② The main unit will start the upgrade automatically upon powering ②...
- Page 23 For any questions please contact support@spedaltech.com...
