Living Spaces ALTON BDMIDDWDAC Assembly Instruction

CAUTION: PLEASE READ ALL INSTRUCTION BEFORE STARTING THE ASSEMBLY OF THIS PRODUCT. THESE ARE HEAVY.
IN ORDER TO PREVENT PERSONAL INJURY AND ENSURE THAT THIS PRODUCT IS NOT DAMAGED DURING THE
ASSEMBLY PROCESS. IT IS STRONGLY RECOMMENDED THAT YOU ENLIST THE ASSISTANCE OF ONE OR MORE
PEOPLE.
CUIDADO: FAVOR DE LEER TODAS LAS INSTRUCCIONES MANTES DE ENSAMBLAR SU PRODUCTTO. ESTAS PIEZAS SON PESADAS.
PARA PREVENIR HERIDAS PERSONALES Y ASEGURAR QUE SU PRODUCTOI NO SEA DAN ADO MIENTRAS ES
ANSAMBLADO, SE RECOMIENDA LA ASISTENCIA DE UNA O MAUS PERSONAS.
WARNING.....PROTECTIVE GLIDE IS PLACED UNDER LEGS OF FURNITURE TO RESIST SCRATCHES TO FLOOR
SURFACE. SOME FLOOR SURFACES CAN BE EXTRA SENSITIVE TO MARKING. IF YOU ARE NOT SURE CONSULT WITH
YOUR DEALER.
AVERTISSEMENT...LES PIEDS DES MEUBLES SONT MUNIS DE PAINTS DESTINÉS À PROTÉGER LE PLANCHER.
CENTAINS REVÊTEMENTS DE SOL PEUVENT ÊTRE TRÈS FRAGILES. EN CAS DE DOUTE, CONSULTER LA MARCHAND.
NO.
A
B
C
D
E
Step 1
4
11 12
1
2
10
9 3
8
4
7
5
6
X 2 0.10 X 1
Parts list
Side Frame (L)
Side Frame (R)
Cabinet (Upper)
Cabinet (Lower)
Crossbar
MIDTOWN WALL DESK
A
5
2
X 1
Assembly Instruction For
ALTON CHERRY II WALL DESK
ITEM: BDMIDDWDAC SKU#: 336691
Q'TY NO.
1
1Pc
2
1Pc
3
1Pc
4
1Pc
5
1Pc
6
7
Page 1 of 3
Hardware List
Ø1/4" * 35mm Bolt (Nice Lock)
Ø5/16" x Ø13mm Spring washer
Ø5/16" x Ø19mm Flat washer
Ø1/4" x 15mm Bolt
Screw (Ø4*50mm)
Metal bas
Allen Key (M4*59mm)
Stick led light in the middle
Tipping restraint
The screw driver is not included
B
5
2
Q'TY
8
8
4
2
1
1
1
4
Assembly completed
Made in Vietnam
