Package Contents
Open the shipping carton of the switch and carefully unpack its contents. Please consult
the packing list to make sure all items are present and undamaged. If any item is missing
or damaged, please contact your local reseller for replacement.
• One DSS-200G-10MP switch
• One AC power cord
• One Quick Installation Guide
Note: the model you have purchased may appear slightly different from those shown in the
illustrations.
Device Interfaces
Port
10/100/1000Base-T PoE ports
1000Base-X SFP ports
RJ-45 Alarm port
LEDs
LED
Power
Alert
PoE Mode/Link Mode Solid amber
Link/Activity/Speed
(per port 1-8)
Link/Activity/Speed
(per port 9-10)
PoE OK/PoE Fail
(per PoE port)
Description
8 10/100/1000Base-T PoE ports (10/100/1000 Mbps connection
speed).
2 1000Base-X SFP ports (100/1000 Mbps connection speed).
RJ-45 Alarm port for connecting external alarm devices.
Status Description
Solid green The switch is powered on.
Light off The switch is powered off.
Solid red The alarm is triggered. Switch will send out traps and logs when
error event.
LEDs for ports 1-8 are in PoE Mode (PoE OK/PoE Fail).
Solid green LEDs for ports 1-8 are in Link Mode (Link/Activity/Speed).
Solid green There is a secure 1000 Mbps connection at the port.
Blinking green There is reception or transmission occuring at the port.
Solid amber There is a secure 10/100 Mbps connection at the port.
Blinking amber There is reception or transmission occuring at the port.
Light off No link.
Solid green There is a secure 1000 Mbps connection at the port.
Blinking green There is reception or transmission occuring at the port.
Solid amber There is a secure 100 Mbps connection at the port.
Blinking amber There is reception or transmission occuring at the port.
Light off No link.
Solid green PD device insert and power feeding.
Solid amber PD device insert but failure occurs.
Light off No PD device insert.
