Bradley Elvari 2B1 Series Installation And Maintenance Manual

Folded paper towel dispenser

Scan or click code to view

Installation Guide (English)

Read the instructions in this manual before beginning installation.

Save these instructions and refer to them for operation and maintenance information.

For questions regarding the operation, installation, or maintenance of this product, visit bradleycorp.com or call 800.BRADLEY (800.272.3539).

Product warranties and parts information may also be found under "Resources" on our website at bradleycorp.com.

P20-253 Rev. B: ECO 25-15-003

Page 1 of 5

1/30/25

Installation and

Maintenance Guide

Scan or click code to view

Installation Guide (French)

Elvari™ Folded Paper

Table of Contents

Safety Information .............................................................2

Dimensions .................................................................... 2-3

Installing the Towel Dispenser ...........................................4

Maintenance and Cleaning ................................................5

Scan or click code to view

Installation Guide (Spanish)

Menomonee Falls, WI 53052 USA

800 BRADLEY (800 272 3539)

Towel Dispenser

2B1 Series

P.O. Box 309

+1 262 251 6000

bradleycorp.com

Table of Contents

Need help?

Do you have a question about the Elvari 2B1 Series and is the answer not in the manual?

Page 1 Save these instructions and refer to them for operation and maintenance information. For questions regarding the operation, installation, or maintenance of this product, visit bradleycorp.com or call 800.BRADLEY (800.272.3539). Product warranties and parts information may also be found under “Resources” on our website at bradleycorp.com.
Page 2: Safety Information
1-1/16" (27) 2-3/4" (70) 5" Maximum ADA (127) Dispense Height 9-13/16" 4-1/2" 56-1/4" (1429) (249) (114) Floor ADA minimum dispense height is 15" (381) above counters or obstructions. See ADA mark for location. 1/30/25 Bradley • P20-253 Rev. B: ECO 25-15-003...
Page 3: Dimensions
Dispense Height 4-5/16" (219) 24-1/16" 70-1/2" (1791) (110) (611) 4-5/16" (110) 2-5/16" (59) 3-5/8" (92) Floor ADA minimum dispense height is 15" (381) above counters or obstructions. See ADA mark for location. Bradley • P20-253 Rev. B: ECO 25-15-003 1/30/25...
Page 4: Installing The Towel Dispenser
Open the dispenser cover. 1. Place the magnetic key on the Bradley logo and slightly push to disengage the lock. One screw for each slotted 2.
Page 5: Maintenance And Cleaning
Refilling the Dispenser Open the door using the magnetic key. Place key on Bradley logo and push slightly to disengage the lock. For model 2B1-113600, the cover will stop shortly after disengaging the lock and pulling back. To open fully, push the cover slightly forward and disengage the retaining hooks inside of the cover (left and right sides).
