Technical Support and E-Warranty Certificate
www.vevor.com/support
12 VOLT POTABLE WATER PUMP
MODEL: NMDP42-G30-55-12 / NMDP42-G35-55-12
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and does not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
Advertisement
Table of Contents
Related Manuals for VEVOR NMDP42-G30-55-12
Summary of Contents for VEVOR NMDP42-G30-55-12
- Page 1 Technical Support and E-Warranty Certificate www.vevor.com/support 12 VOLT POTABLE WATER PUMP MODEL: NMDP42-G30-55-12 / NMDP42-G35-55-12 We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and does not necessarily mean to cover all categories of tools offered by us.
- Page 2 This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if there are any technology or software updates on our product.
-
Page 3: Correct Disposal
Warning-To reduce the risk of injury, user must read instructions manual carefully. CORRECT DISPOSAL This product is subject to the provision of European Directive 2012/19/EU. The symbol showing a wheelie bin crossed through indicates that the product requires separate refuse collection in the European Union. -
Page 4: Installation
An incredible feature list, high-quality components, plus amazing performance. The four-chamber high-volume design, driven by a heavy-duty motor produces flow rates of 3.0GPM or 3.5 GPM, capable of self-priming up to 6 vertical feet, and can run dry, making it the price-to-performance leader. This pump also offers a variety of easy-connect fittings and filters. - Page 5 1 electrical cut off switch 1 fuse 1 screwdriver 1 strong cutting implement for tubing (if desired)Teflon tape or sealant Setup 1. The pump may be mounted in any position. If mounted vertically, the pump head should be in the down position to avoid leakage into the motor casing in the event of a malfunction.
- Page 6 15. The pump circuit should not include any other electrical loads. 16. As the water supply pump is non-essential, reference the wire Chart under the electrical information. Be sure to have the correct wire sizing for the length of wire you are using. 17.After installation, check the voltage at the pump motor.
-
Page 7: Exploded Views
EXPLODED VIEWS Description Quantity Pump Head Assembly Valve Assembly Diaphragm Assembly Motor Assembly Pressure Switch Diaphragm of Pressure Switch Pump Head Diaphragm Rubber Feet Motor - 6 -... - Page 8 PRODUCT SIZE TROUBLESHOOTING PULSATING FLOW- PUMP CYCLES ON AND OFF ·Check lines for kinks. ·Plumbing lines or fittings may be too small. ·Clean faucets and filters. ·Check fitting tightness for air leaks. FAILURE TO PRIME BUT MOTOR OPERATES-NO PUMP DISCHARGE ·Restricted intake or discharge line.
- Page 9 PUMP FAILS TO TURN OFF AFTER ALL FIXTURES ARE CLOSED · Punctured diaphragm. · Discharge line leak. · Defective pressure switch. · Insufficient voltage. · Clogged valves in the pump head. LOW FLOW AND PRESSURE · Air leak at the pump intake. ·...
- Page 10 About the Bypass Valve The pump uses a spring-loaded bypass valve to maintain smooth performance as water demands rise and fall. When a faucet is turned on the pump is providing full water flow, so the bypass valve is closed. But when there is little to no water demand, the bypass valve opens to allow water to flow back from the outlet side to the inlet side, keeping a steady flow of water within the pump with almost no cycling.
- Page 11 ABOUT THE BYPASS Please consult a professional technician in case the bypass needs adjustment. Improper adjustment of the bypass may damage the pump. The bypass comes preset for optimal operation of the pump. If your application calls for a different setting for the bypass, you may change it yourself. Carefully tighten the screw to increase or loosen the screw to decrease the minimum operating pressure of the bypass.
- Page 12 Technical Support and E-Warranty Certificate www.vevor.com/support...
