Pelsis INSECT-O-CUTOR halo 2x30 Instructions

EN
SAFETY INFORMATION
Please read these instructions carefully and store in a safe place for
future reference.
• This appliance is to be kept out of the reach of children.
• This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved.
• Cleaning and user maintenance shall not be made by children without
supervision.
• Children should be supervised to ensure they do not play with the
appliance.
• Warning: If the supply cord is damaged, it must be replaced with a special
cord or assembly available from the manufacturer or its service agent.
GUARANTEE
Halo 2x30 has a three year guarantee and if maintained as recommended in
these instructions should continue to work for many years. Use of
non-approved consumables may invalidate the guarantee (excludes
consumables - Tubes and glueboards). The guarantee does not cover
breakdown due to misuse, incorrect operation or use in an incorrect
application.
CONTENTS OF PACKAGE
- 1 x Halo ykiller
- 2 x Glupac glueboard
®
- 1 x Mains cable
- 2 x Removable aluminium debris tray
- 4 x High powered UV tubes (Fitted)
- 2 x Suspension xing keyrings
- 2 x Mains cable retaining pins
- 1 x Servicing key fob
WARNING - THIS APPLIANCE MUST BE EARTHED (CLASS 1)
POSITIONING AND GUIDANCE FOR USING HALO
Not suitable for applications where potentially explosive environments may
exist.
Halo should ideally be Installed at or lower than 2 meters to the ground,
preferably in the darkest place within the area to be protected. ENSURE
THERE IS A MINIMUM OF 550mm BETWEEN ONE SIDE OF HALO AND THE
ADJACENT SURFACE, TO PROVIDE ENOUGH SPACE TO INSERT THE
GLUEBOARD. Do not position the unit close to windows, skylights or other
sources of light, or where it may be obscured by furniture, doors or other
obstacles. Ideally, Halo should be visible from every part of the area to be
protected.
Halo should ideally be in operation for 24 hours a day, ensuring your premises
are kept free of ying insects. Insects are most attracted to Halo at night when
there is no competition from daylight or other light sources.
INSTALLATION
To ensure Halo reaches you in perfect condition, a protective lm covers the
aluminium door. Remove this lm before use.
Fix the suspension keyrings (supplied in the xing kit) onto the suspension
hooks on Halo. Then attach two lengths of appropriate strength chain to the
suspension reyrings, ensuring that they have been cut to the appropriate
length so that Halo will hang at or lower than 2 meters to the ground. Use
appropriate xing method to attach Halo and the suspension chains to the
suspending surface.
Once Halo is installed in position, t the Glupac
described in the glueboard replacement section of this document.
Insert the mains cable into Halo, and run the length of the cable up one side of
the product, xing in position with the two mains cable retaining pins. Finally,
connect the plug into an appropriate power supply.
To maximise the e ectiveness of Halo in catching ying insects, the top of the
product has light apertures to increase the UV irradiance emitted from the
product. However, these apertures can be covered to protect the glueboard
from debris and prolong its life, by simply sliding the re ective aluminium
cover forward.
CLEANING
CLEANING SHOULD BE CARRIED OUT AFTER ENSURING THAT THE UNIT IS
DISCONNECTED FROM THE MAINS SUPPLY.
It is recommended that cleaning is carried out regularly when the glueboard is
replaced. Once the glueboard is removed, the unit should be thoroughly
wiped down with a damp cloth, removing any build up of dirt. Ensure the unit
is completely dry before reconnecting it to the power supply.
glueboard in place as
®
Light Apertures
Mains Cable Retaining Pins
