- Page 1 Product Installation & User Manual Rangaire: Installation Manual...
-
Page 3: Table Of Contents
24" Gas Cooktop RCG241S | 30" Gas Cooktop RCG301S | 34" Gas Cooktop RCG341S INSTALLATION PREPARATION ..............1 ELECTRICAL REQUIREMENTS . - Page 4 Congratulations on the purchase of your new cooktop. We recommend that you read this instruction / installation Manual in order to fully understand how to install and operate it correctly. Read all the safety instructions carefully before use and keep this Instruction / Installation Manual for future reference. Rangaire: Installation Manual...
-
Page 5: Important Safety Instructions
Follow the gas supplier's instructions. • If you cannot reach your gas supplier, call the fire department. • Installation and service must be performed by a qualified installer, service agency or the gas supplier PLEASE READ ALL INSTRUCTIONS COMPLETELY AND CAREFULLY Rangaire: Installation Manual... -
Page 6: Before You Begin
To eliminate reaching over surface burners, cabinet storage above burner should be avoided. • Do not install the unit near an outside door or where a draft may affect its use. PLEASE READ ALL INSTRUCTIONS COMPLETELY AND CAREFULLY Rangaire: Installation Manual... - Page 7 This conversion must be performed by a qualified installer or gas supplier in accordance with the manufacturer’s instructions and all codes and requirements of the authority having jurisdiction. Failure to follow instructions could result in serious injury or property damage. The qualified agency performing this work assumes responsibility for the conversion. Rangaire: Installation Manual...
-
Page 8: Installation Preparation
Rubber Gasket INSTALLATION PREPARATION LP Kits 4 pcs for 24" model Shut-Off Valve Flexible Connector Flare Union Adapters (2) 5 pcs for 30" model Note: Purchase new line, do not use previously used flexible gas connector. Rangaire: Installation Manual... -
Page 9: In The Commonwealth Of Massachusetts
Latest Edition. You can get a copy by writing: National Fire Protection Association Battery march Park Quincy, MA 02269 In Canada, your cooktop must be wired and fused to meet the requirements of the Canadian Electrical Code. READ AND SAVE THESE INSTRUCTIONS Rangaire: Installation Manual... -
Page 10: Advance Planning
Consideration must be given to electrical and gas supply locations. Installation Above Cabinet Drawers • When installing the cooktop above a base cabinet with drawers, it may be necessary to use a shorter depth (front to back) drawer to allow clearance for the gas connection Rangaire: Installation Manual... -
Page 11: Dimensions And Clearance
Make sure the sides of the opening are parallel and the rear and front cuts are exactly perpendicular to the sides. • Make sure the wall coverings, countertop and cabinets around the cooktop can withstand heat (up to 200°F) generated by the cooktop. Rangaire: Installation Manual... - Page 12 This cooktop features pilotless electric ignition for energy savings and reliability. It operates on a 120 volt, 60 Hz power supply. A separate circuit, protected by a 15 amp time delay fuse or circuit breaker is required. A properly-grounded 3-prong receptacle should be located within reach of the cooktop’s four-foot power cord. Rangaire: Installation Manual...
- Page 13 • Do Not, Under Any Circumstances, Cut or Remove The Third (Ground) Prong From The Power Cord. • Do not use an extension cord. Rangaire: Installation Manual...
-
Page 14: Power Supply Locations
1/2” or 3/4” ID flexible metal appliance connector, three to five feet long. NOTE Purchase new flexible line. DO NOT USE OLD, PREVIOUSLY USED FLEXIBLE CONNECTOR. Rangaire: Installation Manual... -
Page 15: Installation Instructions
Check clearances at the front, back, and sides. Secure the cooktop from underneath with the mounting brackets and screws supplied Install the cooktop burners and caps, then gently place the surface grates on the cooktop. Rangaire: Installation Manual... - Page 16 No Obstructions Below Cooktop Manifold Entrance Pressure Regulator C. Flare Union Adapter Flexible Connector Flare Union Adapter Manual Gas Shutoff Valve All Connection must be wrench-tightened Rangaire: Installation Manual...
- Page 17 • Isolate the cooktop from the gas supply piping system by closing its individual shut-off valve during any pressure testing of the gas supply system at test pressures equal to or less than 1/2 psig (3.5 kPa) Rangaire: Installation Manual...
-
Page 18: Assemble Burners, Check Ignition
Burner cap properly seated Burner cap not properly seated. IMPORTANT: If the igniter electrodes continue to spark after all the burners are lit, check that each burner component is assembled and properly seated. Auxiliary Burner Semi-Rapid Rapid Burner Triple Ring Burner Burner Rangaire: Installation Manual... - Page 19 The flame should be no less than 1/4” on the lowest setting and no greater than 1-1/2” on highest setting. If you attempt to measure the flame, please use caution. Burns could result. Burners should be checked frequently. Rangaire: Installation Manual...
-
Page 20: Operation Checklist
When ordering parts, always include the serial number, model number and a code letter to ensure proper replacement parts. Check again to be sure all installation procedures have been completed. Rangaire: Installation Manual... -
Page 21: Adjust Burner Flames
If converting back to the original gas, please remove the sticker so others know the appliance is set to use its original gas. • Rangaire: Installation Manual... - Page 22 ADJUST THE REGULATOR IMPORTANT: Disconnect all electrical power at the main circuit breaker or fuse box. Shut off the gas supply to the range by closing the manual shut-off valve. 1. Unscrew the regulator cap with the wrench. Rangaire: Installation Manual...
- Page 23 3. Turn the retainer pin upside down and replace it into the regulator cap. It is now positioned for use with LP gas. 4. Screw and tighten the regulator cap back into the regulator with the wrench. Regulator Cap Rangaire: Installation Manual...
- Page 24 HOW TO USE STEP CHANGE BURNER ORIFICES IMPORTANT: Carefully read and observe each orifice label for correct location. See the Burner Chart in this section. 24" Model 30" and 34" model Rangaire: Installation Manual...
- Page 25 Remove the burner grates, burner caps and burner heads. Using a 7 mm nut driver, remove the burner orifices. Auxiliary Burner Orifice Size Triple Ring Burner Semi-Rapid (091 - Denotes Burner 0.91mm) Rapid Burner Rangaire: Installation Manual...
- Page 26 3. Install the proper orifices in the exact locations as noted in the previous graphic 4. Replace the burner bases, heads, caps and top grates. Make sure burner caps are properly seated on the burner head. Properly Seated Not Properly Seated Rangaire: Installation Manual...
-
Page 27: Care And Maintenance
Ignitor and Flame detector (for older models) are positioned into the 2 slots of the burner head. (Refer to Figure 14.) 3. The burner cap is simply positioned over the top of the burner head. (Refer to Figure 14.) Rangaire: Installation Manual... -
Page 28: Care And Cleaning
Stainless Steel - Clean stainless steel with hot, soapy water and a dishcloth. Rinse with clean water and a cloth. Do not use cleaners with high concentrations of chlorides or chlorines. Do not use harsh scrubbing cleaners. Only use kitchen cleaners that are especially made for cleaning stainless steel. Rangaire: Installation Manual...
