- Page 1 DVT36 DVT39 DVT43 Owner's Manual Pictured: DVT36 FOR QUESTIONS AND CONCERNS, CONTACT US AT FOR QUESTIONS AND CONCERNS, CONTACT US AT www.allpartsinc.com Call Us: 1-269-685-4123 Text Us: 1-269-447-0412...
-
Page 2: For Your Safety
• If you cannot reach your gas supplier call the by a qualified installer, service agency or fire department. your gas supplier. The Vermont Castings Majestic Products Company 10000446 INSTALLER: DO NOT DISCARD THIS MANUAL· LEAVE IT FOR HOMEOWNER 11/01 Rev. 2... -
Page 3: Table Of Contents
TABLE OF CONTENTS PLEASE READ THE INSTALLATION & OPERA TING INSTRUCTIONS BEFORE USING APPLIANCE. Thank you and congratulations on your purchase of a Majestic fireplace IMPORTANT: Read all instructions and warnings carefully before starting installation. Failure to follow these instructions may result in a possible fire hazard and will void the warranty . - Page 4 1 . This appliance gives off high temperatures and should be located out of high traffic areas and away from It is not unusual for your MAJESTIC gas fireplace furniture and draperies. to give off some odour the first time it is burned.
-
Page 5: Fireplace Dimensions
FIREPLACE DIMENSIONS • FRAMING AND FINISHING J K L ' ' ' 4� I+-- - A ---+i --+, <( · - - ►, ►• <(• -- - - MODEL DVT43 MODEL DVT36 MODEL DVT39 36 " 39 " 43 " 914mm 991mm 1092mm... -
Page 6: Mantels
Top Louvre Ref. Mantel Ref. Mantel From Mantel Leg from Depth Fireplace Side MANTELS FRAMING AND FINISHING Choose unit location. Depending on the width of the mantel it may be installed Place unit into position and secure to floor with higher or lower from the top of the unit opening. -
Page 7: Final Finis Ing
3/8"UN10N FINAL FINISHING The installation of your Majestic Fireplace Non-combustible materials such as brick and tile can be must conform with local codes, or in the extended over the face of the unit. If a Trim Kit is going to... -
Page 8: Remote Switc Installation
REMOTE SWITCH INSTALLATION 1. Thread wire through the electrical knockout located on either side of unit. Do not cut wire or insulation on metal edges. Ensure that wire is protected. Run the other end to a conveniently located wall receptacle box. 2. -
Page 9: General Venting Information
24" from the the side wall, or vertical through the roof. front of the termination hood. Only Majestic venting components specifically Do not locate termination hood where excessive snow or approved and labelled for this fireplace may be ice build up may occur. -
Page 10: Termination Clearances
Termination Clearances Termination clearances for buildings with combustible and noncombustible exteriors. Inside Corner Recessed Location Outside Corner Combustible 6"(152mm) Combustible 6"(152mm) Noncombustible 2"(50mm) Noncombustible �s 2"(50mm) ◄-. �� Balcony• Balcony- with no side wall with perpendicular side wall Maximum depth of 48" (1219mm) for recessed location. -
Page 11: General Information On Assembling Vent Pipes
& fireplace to the face of the outer wall. It is possible to use CFM Majestic 4" & 7" direct vent Horizontal plane means no vertical rise crimped pipe and elbows in your system, with the new exists on this portion of the vent assembly. - Page 12 For some installations, it may be desireable If a 90 degree elbow is used in the horizon to have some amount of the horizontal vent tal vent run (level height maintained) the run immediately after the fireplace. A verti maximum horizontal vent length is reduced cal rise must be used but can be located by 36 inches.
-
Page 13: How To Use The Vent Graph
VERTICAL SIDEWALL INSTALLATION HOW TO USE THE VENT GRAPH *iiiil 1. Determine the height of the centre of the horizontal vent pipe exiting through the outer wall. Using this dimension on the Sidewall Vent Graph (Fig. 17), Locate vent opening on the wall. It may be necessary to first locate the point it intersects with the slanted graph position the fireplace and measure to obtain hole location. - Page 14 Hiiii (Fig. 23) Use the appropriate length of pipe section - telescopic or fixed - and install. The 20" (508mm) section of pipe which goes through the wall is packaged with the 7DVSK/7TDVSK kit, and can be cut to suit if necessary. �iiHM /;\ Sealing vent pipe and firestop gaps with hi- �...
-
Page 15: Below Grade Installations
BELOW GRADE INSTALLATIONS When it is not possible to meet the required vent terminal clearances of 12 inches (305mm) above grade level a model #7DVSKS/7TDVSKS vent kit is required. It allows installation depth of down to 7 inches (178mm) below grade level. -
Page 16: Vertical Through The Roof Applications
FOUNDATION RECESS WATERTIGHT SEAL AROUND _ ---�-4 WALL PIPE SCREWS 40 EET (12.2m} ' 0.. S::-:- TYPICAL 70VCS APPLICATION Fig. 29 SHEET METAL Fig. 26 SCREWS If the foundation is recessed, use recess brackets (not supplied) for securing lower portion of the snorkel. Fasten brackets to wall first and then secure to snorkel with self drilling #8 x 1/2 sheet metal screws. - Page 17 VERTICAL THRU THE ROOF INSTALLATION 1. Locate your fireplace. 2. Plumb to centre of the (4") collar from ceiling above and mark position. 3. Cut opening equal to 9-3/8" x 9-3/8" (240 mm x 240 mm). 4. Proceed to plumb for additional openings through the roof.
-
Page 18: Crimped Ends Venting Components
CRIMPED ENDS VENTING COMPONENTS Starter Kit -Model 7DVSK - Sidewall Venting Starter Kit - Model 7DVSKV - Vertical Venting for 7DVSKV-A order 1/12 to 6/12 roof pitch for 7DVSKV-B order 7/12 to 12/12 roof pitch for 7DVSKV-F order flat roof Starter Kit - Model 7DVSKS -Snorkel Kit for Below Grade Installation °... -
Page 19: Twist Lock Venting Components
TWIST LOCK VENTING COMPONENTS Starter Kit -Model ?TDVSK - Sidewall Venting Starter Kit - Model 7TDVSKV - Vertical Venting for ?TDVSKV-A order 1/12 to 6/12 roof pitch for ?TDVSKV-B order 7/12 to 12/12 roof pitch for 7TDVSKV-F order flat roof Starter Kit - Model ?TDVSKS -Snorkel Kit for Below Grade Installation °... - Page 20 VERTICAL THRU THE ROOF INSTALLATION 1. Locate your fireplace. 2. Plumb to centre of the (4") collar from ceiling above and mark position. 3. Cut opening equal to 9-3/8" x 9-3/8" (240 mm x 240 mm). l'"'""''"' ,,,;:;::::::::,.._,- - SCREWS (#5) - 4.
- Page 21 1. Plan the gravity duct run first. Use the graph below to ensure that the installation meets The CFM Majestic Products Company recommendations. There is a maximum number of three elbows in a run, but the run must never go in a downward direction as this can trap heat in the gravity vent system.
-
Page 22: General Glass Informati N
1. Shut off gas. Only glass approved for use in The CFM 2. Let the unit cool if it has been operating. Majestic Products Company products may 3. Remove top louvre. (See Louvre Removal) be used for replacement. 4. Open the lower louvre assembly. -
Page 23: Ember Material P Acement
8. Only for DVT43 - Place top centre left log (D14) onto MAINTENANCE notches. Ensure log is secure. 9. Place top right log (B11, C12 or D13) onto locator 1. It is important to keep the burner and the burner notches. -
Page 24: Flame Adjustment
FLAME ADJUSTMENT For units equipped with Hi/Lo valves, flame adjustment is accomplished by rotating the Hi/Lo adjustment knob located near the centre of the gas control. (Fig. 40) Turn Turn clockwise counterclockwise Fig. 43 to lower to increase flame height. flame height. -
Page 25: For Your Safety Read Before Lighting
LIGHTING AND OPERATING INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING � If you do not follow these instructions exactly, afire or explosion may result causing property damage, personal injury or loss oflife. This fireplace has a pilot which must be lit manually. Use onlyyour hand to push in orturn the gas control When lighting the pilotfollowthese instructions exactly. -
Page 26: Trouble Shooting The Gas Control System
TROUBLE SHOOTING THE GAS CONTROL SYSTEM SIT NOVA 820 MILLIVOLT VALVE Note: Before trouble shooting the gas control system, be sure external gas shut off is in the "On" position. WARNING: BEFORE DOING ANY GAS CONTROL SERVICE WORK, REMOVE GLASS FRONT. SYMPTOM POSSIBLE CAUSES CORRECTIVE ACTION... - Page 27 REPLACEMENT PARTS LIST - DVT SERIES ' ', .,__ ·.-', •, ' ·:;; DVT36 DV T4 3 DESCRIPTION DVT39 Log Set Complete 10000282 10000397 10000448 ' , fa. Log Ember Front B6 ·. Log Front Left . · Log FroritRigh! ..C.
- Page 28 REPL ACEM ENT PART S - DVT SERI ES FOR UNITS EQUIPPED WITH SIT 820 MILLIVOLT GAS VALVE 11 a/b ldi====1 4a/b ,,--____,, 6 a/b � �� 8 a/b 7 a/b � 10 17 8 a/b #1 Complete Log Set DVT 43 #1 Complete Log Set DVT39 #1 Complete Log Set DVT36 �"...
-
Page 29: Fan Kit - Fk24
OPTIONS WIRING INSTRUCTIONS - A FAN KIT - FK24 Fan Specifications: 115 Volt 60 HZ 56W. Hard (Direct) Wire Hook-Up (Option A): This fan does not need regular maintenance, however First connect ground wire to ground stud located on the periodic cleaning is required. -
Page 30: Wiring Instructions - B - Electrica
WIRING INSTRUCTIONS - B CERAMIC REFRACTORY INSTALLATION DVT36CR Optional for DVT36 DVT39CR Optional for DVT39 Any electrical re-wiring of this fan must DVT 43CR Standard with DVT 43 be done by a qualified electrician. Turn off all power before hook-up. 1. -
Page 31: Bay Window Installation
BAY WINDOW INSTALLATION FOR DVT36/ DVT39 DO NOT REMOVE EXISTING GLASS � WITH FRAME. 1. Remove existing bottom louvre and hinges from fire- place. (Set aside the two (2) self tapping screws). Remove existing top louvre from fireplace. 3. Assemble Bay Window Kit according to instructions. 4.
