The evaluation board is designed to ease customer evaluation of the PE25203. This section guides you through
configuring the hardware and the start-up procedures.
The evaluation board is shown in Figure 1.The board contains:
■
Input/output terminals
■
PCB headers
■
Sense points
OUTPUT
TERMINALS
http://www.murata.com/products/power
Copyright ©2023 Murata Manufacturing Co., Ltd. and pSemi Corporation, a Murata Company. All rights reserved.
DOC-111189-2 (10/2023)
Figure 1. PE25203 Evaluation Board Assembly
INPUT
TERMINALS
Page 4 of 32
