stayer MIG280 DP Use Manual

Hide thumbs

Advertisement

Table of Contents

EASY USE GUIDE
GUIDA DI FACILE UTILIZZO
GUIDE FACILE À UTILISER
Mod.
MIG280 DP
www.stayer.es

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MIG280 DP and is the answer not in the manual?

Questions and answers

Related Manuals for stayer MIG280 DP

Summary of Contents for stayer MIG280 DP

  • Page 1 EASY USE GUIDE GUIDA DI FACILE UTILIZZO GUIDE FACILE À UTILISER Mod. MIG280 DP www.stayer.es...

  • Page 2: Control Panel

    MIG 280 DP Version: 00.01 EASY GUIDE MIG 280 DP CONTROL PANEL: LED Indicators: Power: Turns red only while the equipment is welding. Failure: Turns red in case the equipment is in an abnormal situation, it may be due to overheating or failure in the input voltage.
  • Page 3 MIG 280 DP Version: 00.01 Welding modes: B1 button: Selects the different welding modes of the equipment. The red LED will indicate the selected mode 1. MMA: Electrode welding 2. MANUAL:Traditional MIG/MAG welding 3. Puls MIG: Pulsed MIG/MAG welding 4. 2 Puls MIG: MIG/MAG welding with double pulse 5.
  • Page 4 MIG 280 DP Version: 00.01 4T: 4 stages (Welding modes 2, 3 and 4). The MIG /MAG welding is activated when the trigger is pressed (T1). It is necessary to keep it pressed until the welding arc begins, once the arc starts, the trigger must be released (T2) to obtain a continuous welding.
  • Page 5 MIG 280 DP Version: 00.01 SPOT: Spot welding (Welding mode 3). In this function, the spot-welding time and amperage are configured. The trigger must be pressed and held until the end of the welding process. While the trigger is pressed, the welding is carried out at the pre-selected amperage in the MIG/MAG settings and will last until the time configured in the "Spot"...
  • Page 6 MIG 280 DP Version: 00.01 s: The LED is activated when the right display shows the value in seconds of the parameters of time that can be configured. This option will be available in welding modes 2, 3 and 4. %: The LED is activated when the value of the percentage of the high level of the DOUBLE PULSED MIG weld wave is shown on the right display.
  • Page 7 MIG 280 DP Version: 00.01 In the MMA welding mode (mode 1), between 0 and 200 amps can be selected, providing an initial overcurrent, facilitating the priming of the electric arc, and making easier to start the weld. Inductance: Selectable between 1 and 10 within all MIG/MAG modes (welding modes 2, 3 and 4) via R1.
  • Page 8 MIG 280 DP Version: 00.01 Configurable parameter in all MIG welding modes (modes 2, 3, and 4). Burn back "V": It is the "backburning" voltage present at the output when giving the order to finish the welding. This voltage is present during the selected burn back time, causing the wire not to stick to the contact tip.
  • Page 9 MIG 280 DP Version: 00.01 Synergic MIG Configurations Within the MIG/MAG modes, the options for selecting wire material and thickness are enabled. By means of B3 the thickness of the wire is changed (welding modes 2, 3 and 4), being able to select 0.8, 1.0 and 1.2.

  • Page 10: Welding Modes

    MIG 280 DP Version: 00.01 WELDING MODES 1. Welding with MMA coated electrode Within the MMA welding mode (1)," a screen like the one above appears. Follow the following steps: Select the MMA option (1) with B1. Regulate the output current between the values 10A and 280A with R2. Regulate the "Hot Start"...
  • Page 11 MIG 280 DP Version: 00.01 Connection’s diagram: Rutile Electrode Ground Clamp Ground Clamp Basic/Cellulosic/StainLess Steel/Aluminum Electrode...
  • Page 12 MIG 280 DP Version: 00.01 2. TIG welding The MIG 280 DP has the possibility of welding TIG with carbon or stainless-steel contribution. Select the welding mode 1 MMA with B1. Within the MMA welding mode (1), a screen like the one above appears. Follow the following steps: a) Select the MMA option (1) with B1.
  • Page 13 MIG 280 DP Version: 00.01 Connection’s diagram: TIG Torch Argon or Helium Gas Ground Clamp...
  • Page 14 MIG 280 DP Version: 00.01 3. MANUAL MIG welding Within the MANUAL MIG welding mode (2), a screen like the one above appears, we must follow the following steps: Select the MANUAL option (2) with B1. Select the thickness of the wire with B3 between 0.8, 1.0 and 1.2 mm. Select the drive mode with the B2 button, between 2T and 4T.

  • Page 15: Mig Torch

    MIG 280 DP Version: 00.01 To use the MANUAL MIG welding mode it is necessary to connect the appropriate torch that is included in the equipment, there is one for steel and one for aluminum. A gas cylinder must be connected. A coil of wire must be mounted to use in MIG/MAG. The required connections are as follows: •...
  • Page 16 MIG 280 DP Version: 00.01 4. PULSED MIG welding Within the PULSED MIG welding mode (3), a screen like the one above appears. Follow the following steps: Select the Puls MIG option (3) with B1. Select the thickness of the wire with B3 between 0.8, 1.0 and 1.2 mm. Select the material of the wire with B4 between Fe, AlSi/+ATC, AlMg/+ATC, CrNi, Cu.
  • Page 17 MIG 280 DP Version: 00.01 m) Adjust the Burn Back(s) with R1, select a value between 0.01 and 0.5 seconds. The time appears on the right display. Adjust the Burn Back (v) with R1, select a value between 10 and 25 volts. The voltage appears on the right display.
  • Page 18 MIG 280 DP Version: 00.01 5. MIG Double Pulsed Welding Within the DOUBLE PULSED MIG welding mode (4), a screen like the one above appears. Follow the following steps: Select option2 Puls MIG (4) with B1. Select the thickness of the wire with B3 between 0.8, 1.0 and 1.2 mm. Select the yarn material with B4 between Fe, AlSi/+ATC, AlMg/+ATC, CrNi, Cu.
  • Page 19 MIG 280 DP Version: 00.01 Adjust A-max with R2 the welding amps are configured (high value of current in double pulsed), selectable between 10A and 280A. With R1 the output volts are configured, selectable between 14V and 30V. The amps appear on the left display and the voltage on the right display.
  • Page 20 MIG 280 DP Version: 00.01 Connection’s diagram: Connect gas at MIG Torch the back of the equipment Ground Clamp...
  • Page 21 MIG 280 DP Version: 00.01 6. Factory settings in PULSED and DOUBLE PULSED MIG With the Fab welding mode. (5) adjustment of PULSED and DOUBLE PULSED MIG welding parameters are configured. To access these settings, while the 2 Puls Mig welding mode is selected, B1 must be pressed for 3 seconds and a screen like the one above appears.
  • Page 22 MIG 280 DP Version: 00.01 Acronyms: MIG (Metal Inert Gas): Welding of wire with inert gas such as Helium or Argon MAG (Metal Active Gas): Welding of wire with active gas such as CO or CO +Argon MMA (Manual Metal Arc): Arc welding with coated electrode. AWS (American Welding Society): Defines an establishes numbering system that indicates specifications of materials for welding.
