Page 1: Table Of Contents
Setup Guide Setting Up the Machine Configuring the Network Setting Fax Settings Installing the Printer Driver Scan Settings... - Page 2 For safe and correct use, please be sure to read the Safety Information before using the machine.
-
Page 3: Setting Up The Machine
● If the machine is not functioning normally, unplug the power cord from the wall outlet, and then plug it in again. RICOH Support Station RICOH Support Station provides guidance for machine setup and network configuration on your smart devices. Check the supplied items. For information on the supplied items, see the User Guide on the website. - Page 5 ECC284 ECC286 ECC290...
- Page 6 M0ESPC0025 *1 The protective material with a red tag may fall off when you pull out the tray, but it will not affect operation of the machine. *2 Peel back the protective tape halfway at the lower-right. Configure the network setting. Go to page 5 "2.
-
Page 7: Configuring The Network Setting
Connect using a Ethernet cable USB cable Go to page 9 "Connecting the Machine via Ethernet or USB". RICOH Support Station Use a router (access point)? Go to page 1 "RICOH Support Station". Does the access point have Connect via Wi-Fi Direct a WPS button? See User Guide in our website. - Page 8 • Sending scanned images or documents from the machine to the smart device • Printing photographs and documents stored on a smart device After scanning the following QR code with your smart device, search for the "RICOH Smart Device Connector" application and download it from the site that appears.
- Page 9 Check the result. After "Please wait for 2 minutes" appears, press the WPS button on the router (access point) within two minutes. Connection has succeeded: "Connected to access point." is displayed. Connection has failed: "Failed to connect to access point." is displayed. Check the configuration for the router (access point), and then try the connection again.
- Page 10 Check the PIN code. Easy Setup Using a PIN Code Be sure not to press [Connect]. Write down the PIN code in case you might forget it. ● Make sure the Ethernet cable is not connected to the machine. ● In Steps 8 to 11, configure each setting within two minutes.
-
Page 11: Fax Settings
Connecting the Machine via Ethernet or USB ● For details about IPv4 or IPv6 settings manually, see User Guide. ● When connecting the machine via USB, USB cable is necessary to set up. Do not connect the cable until you are instructed to do so on the screen. -
Page 12: Installing The Printer Driver
4. Installing the Printer Driver Follow the instructions in the setup wizard. If you already completed the Wi-Fi setting, click [The machine's ● If you connect the computer by a USB cable, do not IP address has been already configured.]. connect the cable until you are instructed to do so on the screen. - Page 13 Trademark Android is a trademark of Google LLC. IOS is a trademark or registered trademark of Cisco in the U.S. and other countries and is used under license. Wi-Fi ® , Wi-Fi Direct ® and WPA are registered trademarks of Wi-Fi Alliance. macOS is trademarks of Apple Inc., registered in the U.S.
- Page 14 D0F3-8511A...
