- Page 1 O P E R A T I N G M A N U A L S T A I N I N G S Y S T E M S t a i n t e c M i n i MINIMALIST AND CONSTRAINT-FREE DEVICE D ES I GN &...
- Page 2 Manual_Staintec_Mini_2025-01-001.00_EN.docx...
- Page 3 The information, numerical data and notes contained in this document represent the current state of scientific knowledge and state-of-the-art technol- ogy as we understand it following thorough investigation in this field. SLEE medical GmbH is under no obligation to update the present manual periodi- cally and on an ongoing basis according to the latest technical developments, nor to provide our customers with additional copies, updates etc.
- Page 4 Manual_Staintec_Mini_2025-01-001.00_EN.docx...
-
Page 5: Table Of Contents
CONTENTS INTRODUCTION ______________________________________________________ 7 Intended use Authorized operators Device type Safety instructions for working with the Staintec Mini and reagents OVERVIEW DEVICE ___________________________________________________ 9 COMPONENTS ______________________________________________________ 10 SPECIFICATIONS _____________________________________________________ 11 SETTING UP THE DEVICE _____________________________________________ 12 Installation System set-up General use USING STAINTECMINI.APK SOFTWARE ________________________________ 14... - Page 6 Manual_Staintec_Mini_2025-01-001.00_EN.docx...
-
Page 7: Introduction
Authorized operators The Staintec Mini must be used only by those persons who have been authorized by the owner. In his working area, the operator is responsible with regard to third persons. The owner must give the operator access to this instruction manual and make sure that the operator has read and understood its contents. -
Page 8: Safety Instructions For Working With The Staintec Mini And Reagents
Staintec Mini is an electrical device and must be used under normal conditions of use. It is intended for profes- sional use. • Staintec Mini must only be powered by the power supply provided (24 V, 1.5 amps, 5.5 x 2.1 x 11 mm cylindrical connector, central positive terminal). •... -
Page 9: Overview Device
OVERVIEW DEVICE Manual_Staintec_Mini_2025-01-001.00_EN.docx... -
Page 10: Components
COMPONENTS The Slee staining system Staintec Mini is provided with the following standard components: Staintec Mini system 24 V power supply (different adapters available) User manual Tablet Tablet holder Stain cuvettes (7 pcs.) Slide mount USB / micro-USB cable 1 m silicone hose (2 pcs.) StaintecMini.apk software is already installed on the tablet. -
Page 11: Specifications
SPECIFICATIONS Nominal Voltage 100 – 240 V AC Nominal frequency 50 / 60 Hz Dimensions (w x d x h) 250 x 250 x 300 mm Weight unpacked (without accessories) 3.4 kg Manual_Staintec_Mini_2025-01-001.00_EN.docx... -
Page 12: Setting Up The Device
Please set up the device as shown below: System set-up 1. Turn on the tablet and then connect the tablet to the Staintec Mini using the included USB cable. 2. Connect the power supply to the device and then to the power outlet. -
Page 13: General Use
General use To insert or remove a slide: Press on the ears. Maximum liquid level (indicated in red). Attention: Overflow risk! The arm dunks the slides into the cuvettes. Manual_Staintec_Mini_2025-01-001.00_EN.docx... -
Page 14: Using Staintecmini.apk Software
USING STAINTECMINI.APK SOFTWARE Creating or altering a stain Press the "Create" or "Update" button. Select "New" from the scroll-down menu if you wish to create a new protocol or select the protocol to be altered. Enter the protocol title and the stain cuvettes (a keypad ap- pears as soon as you press on the key-in zone), then press "Save and next". -
Page 15: Staining
Staining Launch the Staintec Mini software. Select the desired stain from the scroll-down menu (1). Place the dyes on Staintec Mini in the order indi- cated in the list (5). Press "COLOR" (2). Settings To adjust the immersion positions: Press “Start”... -
Page 16: Set Language
Set language Turn the tablet on, select “Settings” in the menu. Slide the page up to go to the end of the menu. Select “System”. Manual_Staintec_Mini_2025-01-001.00_EN.docx... - Page 17 Select “Languages & input”. Select “Languages”. Slide the desired language to position no 1. Exit the “Settings” page to save your choice. Manual_Staintec_Mini_2025-01-001.00_EN.docx...
-
Page 18: Programming Protocols
Programming Protocols Run the “Staintec Mini” application. If the desired language is English, then select the drop-down menu of the tab at launch “HES”. Select “New”, then “Create or update a protocol”, e.g. Priming. Reselect the new program (e.g. Priming) from the drop-down menu. -
Page 19: Errors
Errors Problem Possible cause Solution The machine does not react when you Equipment is not connected, Disconnect and reconnect the cable: a message press on "Color". or the cable is faulty. should appear (e.g. "machine connected"). The stain overflows. There is too much stain in the Comply with the maximum level indicated with cuvettes. -
Page 20: Service
SERVICE The device should only be serviced by technicians authorized by SLEE medical GmbH. If technical service or spare parts are necessary, please contact your local SLEE medical GmbH distributor. Please have the following information available: • complete contact details, •... - Page 21 Notes Manual_Staintec_Mini_2025-01-001.00_EN.docx...
- Page 22 Notes Manual_Staintec_Mini_2025-01-001.00_EN.docx...
- Page 23 Manual_Staintec_Mini_2025-01-001.00_EN.docx...
- Page 24 SLEE medical GmbH • Am Neuberg 14 55268 Nieder-Olm • Germany www.slee.de T: +49 (0) 6136 76997-0 E: mail@slee.de www.slee.de YouTube LinkedIn Instagram Manual_Staintec_Mini_2025-01-001.00_EN...
