Citronic FLITE-600 User Manual

Powered mixer with dsp & 2 uhf mics
Hide thumbs
1
2
3
4
5
6
7
8
9

Advertisement

Table of Contents

FLITE-600
Item ref:
170.600UK
User Manual
Powered Mixer with DSP & 2 UHF Mics
Version 1.0
Caution: Please read this manual carefully before operating
Damage caused by misuse is not covered by the warranty

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FLITE-600 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Citronic FLITE-600

Summary of Contents for Citronic FLITE-600

  • Page 1 FLITE-600 Item ref: 170.600UK User Manual Powered Mixer with DSP & 2 UHF Mics Version 1.0 Caution: Please read this manual carefully before operating Damage caused by misuse is not covered by the warranty...
  • Page 2 Introduction Thank you for choosing a FLITE-600 powered mixer as part of your professional sound system. This product has been developed to provide a wide range of facilities for professional and reliable sound reinforcement. Please read and keep this manual to achieve the best results from your purchase and avoid damage through misuse.

  • Page 3: Console Layout

    34. MAIN OUT L+R level faders The FLITE-600 has 4 mono input channels which can accept a balanced microphone input or switchable line/instrument input. Channel 4 is used for the inbuilt dual UHF microphones but can be operated in the same way and channels 1, 2, and 3 if wireless microphones are not being used.
  • Page 4 Channels 1-4 each have a 60mm level fader for quick and easy adjustment of mix levels (16) UHF wireless microphones The FLITE-600 has a section above the mixing console for an onboard dual wireless microphone system. The system has 2 channels, A and B, which are governed by 2 rotary VOLUME controls (4, 5).

  • Page 5: Output Section

    Setting Up If a wired microphone is to be used with the FLITE-600, connect to input channel 1, 2, or 3 via XLR cable. If the onboard UHF microphones are not being used, then input 4 is also available. For condenser microphones or D.I.

  • Page 6: Operation

    MP3 Player/Recorder The FLITE-600 has a built-in USB mp3 audio player/recorder, with playback level governed by the MP3 volume control (22). The USB port (23) directly below the PHONES OUT jack can accept a USB flash drive that is formatted to FAT32 to play back audio tracks that are stored as .mp3 or .wma files on the flash drive.

  • Page 7: Dsp Effects

    Bluetooth To connect a smart phone for wireless playback of stored tracks through the FLITE-600, press the BT PAIR button (31), which will flash blue to indicate that it is in pairing mode. Open the Bluetooth menu on the smart phone and search for the device ID “Citronic” and select to pair.

  • Page 8: Specifications

    Specifications Power supply 220-240Vac, 50Hz (IEC) Fuse T4AL Inputs : Mic/Line 4 x combo XLR/jack Inputs : Line 1 x L/mono+R 6.3mm jack Phantom power +48V switchable (XLR inputs only) Dynamic range 102dB (mixer channels) EQ: low ±15dB @ 80Hz EQ: high ±15dB @ 12kHz Bluetooth version...
  • Page 9 DSP Effects Presets & Parameters Name Para 1 Para 2 Name Para 1 Para 2 KTV Echo 3 Dly Time Decay Time Mono Delay 60 Repeat Delay Time KTV Echo 2 Dly Time Decay Time Mono Delay 100 Repeat Delay Time KTV Echo 1 Repeat Decay Time...
