Installation Instructions
for Dryers
Original Instructions
Keep These Instructions for Future Reference.
CAUTION: Read the instructions before using the machine.
(If this machine changes ownership, this manual must accompany machine.)
Part No. D512061R10
www.speedqueen.com
August 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADE3SRGS173TW01 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Alliance Laundry Systems ADE3SRGS173TW01

  • Page 1 Installation Instructions for Dryers Original Instructions Keep These Instructions for Future Reference. CAUTION: Read the instructions before using the machine. (If this machine changes ownership, this manual must accompany machine.) Part No. D512061R10 www.speedqueen.com August 2017...
  • Page 3 A "T-Handle" type gas shut-off valve must be installed in the gas supply line to this appliance. • This appliance must not be installed in a bedroom or bath- room. © Copyright, Alliance Laundry Systems LLC - Part No. D512061R10 DO NOT COPY or TRANSMIT...
  • Page 4: Table Of Contents

    Installer Checklist.................23 © Copyright 2017, Alliance Laundry Systems LLC All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher.
  • Page 5: Dimensions

    28 in. [711 mm] 23.5 in. [597 mm] NOTE: Exhaust openings are 4 inch [102 mm] metal * With leveling legs turned into base. ducting. © Copyright, Alliance Laundry Systems LLC - Part No. D512061R10 DO NOT COPY or TRANSMIT...
  • Page 6 28 in. [711 mm] 23.5 in. [597 mm] NOTE: Exhaust openings are 4 inch [102 mm] metal * With leveling legs turned into base. ducting. © Copyright, Alliance Laundry Systems LLC - Part No. D512061R10 DO NOT COPY or TRANSMIT...
  • Page 7: Installation

    An accessories bag has been shipped inside your dryer. It in- cludes: • Installation Instructions • User’s Guide • Dryer Rack Reply Card (Select Models Only) • Warranty Bond © Copyright, Alliance Laundry Systems LLC - Part No. D512061R10 DO NOT COPY or TRANSMIT...
  • Page 8 Installation D669I_SVG 1. Dryer Base 2. Level 3. Leveling Leg Figure 2 © Copyright, Alliance Laundry Systems LLC - Part No. D512061R10 DO NOT COPY or TRANSMIT...
  • Page 9 Front View (Closet Door) 2 (G) DRY2637N_SVG 1. Closet Door 2. Centered Air Openings (G) (2 Openings minimum) 3. Outer Wall of Enclosure Figure 3 © Copyright, Alliance Laundry Systems LLC - Part No. D512061R10 DO NOT COPY or TRANSMIT...
  • Page 10: Connect Dryer Exhaust System

    To reduce the risk from substances in the fuel W604 or from fuel combustion, make sure this appliance is installed, operated, and maintained according to the instructions in this manual. W115 © Copyright, Alliance Laundry Systems LLC - Part No. D512061R10 DO NOT COPY or TRANSMIT...
  • Page 11: Exhaust Direction

    • In mobile home installations, dryer exhaust duct must be se- cured to mobile home structure. © Copyright, Alliance Laundry Systems LLC - Part No. D512061R10 DO NOT COPY or TRANSMIT...
  • Page 12 NOTE: The maximum length of a 4 in. [102 mm] diame- ter flexible metal duct must not exceed 7.87 ft. [2.4 m], as required to meet UL2158, clause 7.3.2.A. © Copyright, Alliance Laundry Systems LLC - Part No. D512061R10 DO NOT COPY or TRANSMIT...
  • Page 13: Gas Dryers - Connect Gas Supply Pipe

    For proper operation at altitudes above 3000 feet [915 m] the nat- ural gas valve spud orifice size must be reduced to ensure com- plete combustion. Refer to Table 3 . © Copyright, Alliance Laundry Systems LLC - Part No. D512061R10 DO NOT COPY or TRANSMIT...
  • Page 14: Connect Electrical Plug (Electric Dryer Only)

    The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances. © Copyright, Alliance Laundry Systems LLC - Part No. D512061R10 DO NOT COPY or TRANSMIT...
  • Page 15: Connecting Power Cord With Three-Wire Plug

    Longer than 15 ft. (4.5 m) – use 8 AWG Wire Length Wire Less than 15 ft. [4.5 m] Listed No. 10 AWG Copper wire only Table 5  continues... © Copyright, Alliance Laundry Systems LLC - Part No. D512061R10 DO NOT COPY or TRANSMIT...
  • Page 16 15. Direct Connection 16. Power Cord Connection Figure 6 1. Disconnect power to dryer. 2. Remove access cover from rear of dryer. D695I_SVG Figure 7 © Copyright, Alliance Laundry Systems LLC - Part No. D512061R10 DO NOT COPY or TRANSMIT...
  • Page 17: Connecting Power Cord With Four-Wire Plug

    Connecting Power Cord with Four-Wire Plug NOTE: Four-wire cord is required for new branch-cir- cuit installations, mobile homes or where codes do not permit grounding through neutral. © Copyright, Alliance Laundry Systems LLC - Part No. D512061R10 DO NOT COPY or TRANSMIT...
  • Page 18: Reverse Door, If Desired

    10. Reinstall access cover and screw. Reverse Door, if Desired The door on this dryer is completely reversible. To reverse door proceed as follows: 1. Remove four hinge attaching screws. © Copyright, Alliance Laundry Systems LLC - Part No. D512061R10 DO NOT COPY or TRANSMIT...
  • Page 19 4. Rotate door panel 180 degrees as shown. 8. Using screwdriver, remove two door plugs, and reinstall on opposite side of door opening. D273P_SVG Figure 18 © Copyright, Alliance Laundry Systems LLC - Part No. D512061R10 DO NOT COPY or TRANSMIT...
  • Page 20: Wipe Out Inside Of Dryer

    This dryer must be grounded. In the event of malfunction or necting power cord. breakdown, grounding will reduce the risk of electric shock by providing a path of least resistance for electric current. The dryer © Copyright, Alliance Laundry Systems LLC - Part No. D512061R10 DO NOT COPY or TRANSMIT...
  • Page 21: Recheck Steps

    IMPORTANT: This operation is to be conducted by qualified personnel only. 1. To view the burner flame, remove the lower front panel of the dryer. © Copyright, Alliance Laundry Systems LLC - Part No. D512061R10 DO NOT COPY or TRANSMIT...
  • Page 22 3. 1/8 in. [3.1 mm] Pipe Plug (For checking manifold pressure) 4. Shut-off Valve Open Position 5. Shut-off Valve Closed Position 6. Shut-off Valve Handle Figure 27 © Copyright, Alliance Laundry Systems LLC - Part No. D512061R10 DO NOT COPY or TRANSMIT...
  • Page 23: Installer Checklist

    Check Heat Source • Connect Electrical Cord. D702I_SVG1 CHECK CHECK D699I_SVG1 Reverse Door, if De- sired. CHECK D675I_SVG1 Refer to the manual for more detailed information © Copyright, Alliance Laundry Systems LLC - Part No. D512061R10 DO NOT COPY or TRANSMIT...
