Paramount Fitness ClearO3 Installation Manual

Water treatment system
Hide thumbs Also See for ClearO3:
Table of Contents

Advertisement

Quick Links

Download this manual
004-027-8818-00 RevD
PUB091924
ClearO3
Water Treatment System
Installation Manual
Contents
Safety Instructions..................1
Installation.............................3
Bulb Replacement.................13
Troubleshooting....................15
Replacement Parts.................15
Paramount
8175 W. Buckeye Rd.,
Phoenix, AZ 85043
Phone: (480) 893-7607
www.1Paramount.com
USE ONLY PARAMOUNT GENUINE REPLACEMENT PARTS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ClearO3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Paramount Fitness ClearO3

Summary of Contents for Paramount Fitness ClearO3

  • Page 1: Table Of Contents

    004-027-8818-00 RevD PUB091924 ClearO3 Water Treatment System Installation Manual Contents Safety Instructions....1 Installation......3 Bulb Replacement....13 Troubleshooting....15 Replacement Parts....15 Paramount 8175 W. Buckeye Rd., Phoenix, AZ 85043 Phone: (480) 893-7607 www.1Paramount.com USE ONLY PARAMOUNT GENUINE REPLACEMENT PARTS...

  • Page 2: Safety Instructions

    Important Safety Instructions READ AND FOLLOW ALL INSTRUCTIONS This Owner’s Manual contains specific precautions and symbols to identify safety related infor- mation as described below. Please read them carefully and follow these precautions as indicated! DANGER - Indicates a hazardous situation which, if not avoided, will result in death or serious injury.
  • Page 3 Piping Ozone to the Injector Manifold................9 Plumbing Clear03 with Ultra UV and Offline Chlorine Feeder Using Venturi Injector Method...10 Plumbing ClearO3 and Ultra UV with Ozone Introduced at Pump and Inline Chlorinator..11 Plumbing ClearO3 and Ultra UV with Ozone Introduced at Pump and Offline Chlorinator..11 Setting Air Flow.......................12...

  • Page 4: Installation

    (12) inches. Do not tighten screws all the way. (Fig. 1) Fig. 3 Hang the ClearO3 from the two top brack- ets by sliding the keyhole slots over the screws. Mark the location for the two bottom brackets.

  • Page 5: Making Electrical Connections

    - The ClearO3 must run with the filter pump as the filter pump creates the air draw through the unit needed to create ozone. Do not set the ClearO3 to run when the filter pump is off and not pulling air through the unit.

  • Page 6: Alternate Electrical Connection For Multi-Speed Pump

    Paramount has available an add-on paddle flow switch (Paramount part# 004-402-0010-00 or Grid Controls part # 57-F1-225-00W). The power is run through this switch and then to the ClearO3. The flow switch is plumbed in the main line of the pool return. When it senses flow the ClearO3 is turned on.

  • Page 7: Making Plumbing Connections

    The ClearO3 should be wired to run with the filter pump which creates the air draw through the unit needed to create ozone. Do not set the ClearO3 to run when the filter pump is off. Making Plumbing Connections WARNING - Turn off power to the filtration system pump at the main source before making any plumbing connections or changes.

  • Page 8: Piping Ozone To A Pre-Pump Standpipe

    Pump strainer pot installation: (Fig. 6) Fig. 7 Check pump elevation above water Pump level. Refer to (Chart 1) for proper check valve selection. The 0.5 lb valve comes standard with Clear O3 and Fig. 6 others are available to order sepa- rately.

  • Page 9: Piping Ozone To The Suction Side Of A Pump Installed Below Water Level

    (Fig. 11) Lay the 3/8 tubing along desired route to the compression fitting on the combination needle valve flow meter on the ClearO3 unit. Connect the tubing to the compression fit- ting. (Fig. 12) Use the provided wires ties to tie the loose tubing to the conduit or plumbing.

  • Page 10: Piping Ozone To The Injector Manifold

    The Clear03 ozone suction line will hook directly up to the bottom of the Clear03 and the other end to the injector with the check valve provided with the Clear03. No flow meter is needed or provided. NOTE: The ClearO3 unit must be mounted at least 1' above pool water level to prevent water from contacting electrical equipment.

  • Page 11: Plumbing Clear03 With Ultra Uv And Offline Chlorine Feeder Using Venturi Injector Method

    Chart 2 - Check Valves Center line of injector Check Valve Rating Part Numbers manifold to water level 1' or lower 0.5 lb 005-402-1250-00 1' - 2' (30cm - 60cm) 1.0 lb 005-402-2505-00 2' - 3' (60cm - 90cm) 1.5 lb 005-402-2502-00 3' - 5' (90cm - 150cm) 2.0 lb...

  • Page 12: Plumbing Clearo3 And Ultra Uv With Ozone Introduced At Pump And Inline Chlorinator

    Plumbing the ClearO3 and Ultra UV with Ozone Introduced at the Pump and an Inline Chlorinator When installing a Clear O3 and an Ultra UV in the same pool system, where the Ozone is piped into the pump strainer pot or into a standpipe before the pump suction, it is recommended that an air bleed be installed to remove excess air from the filter and return it to the pool piping downstream of the inline chlorinator, which should be the last component in the system.

  • Page 13: Setting Air Flow

    Setting Air Flow Fig. 16 Clean filter and pump basket before setting airflow. Turn the knob on the needle valve/flow meter clockwise to close valve completely. Turn the power on to the pump. Turn the knob on the needle valve/flow meter counter clockwise until the ball reads in the middle of the two lines on the flow meter.

  • Page 14: Bulb Replacement

    Mounting Instructions Turn the power off to the pump. Remove the pressure gauge from the filter. Install the nipple into one end of the brass tee. Install the pressure gauge by threading into the other end of the brass tee supplied. Install the tubing compression fitting by threading into the side of the brass tee.

  • Page 15: Replacing Uv Bulb

    Replacing UV Bulb DO NOT TOUCH THE GLASS, HANDLE BY CERAMIC ENDS OF BULB! Turn the power off to filtration system pump at circuit Remove side cap. Grasp light bulb plug and pull light out breaker. Remove three screws in left end side cap labeled about one inch.

  • Page 16: Troubleshooting

    Filter empties and pump loses prime Replace check valve fitting at strainer pot Check power to the ClearO3. If you have power and the Light bulb does not light bulb still doesn't light up, turn off the power and replace the bulb.
  • Page 17 (optional) (optional) (optional) (optional) USE ONLY PARAMOUNT GENUINE REPLACEMENT PARTS...
  • Page 18 THIS PAGE IS INTENTIONALLY LEFT BLANK USE ONLY PARAMOUNT GENUINE REPLACEMENT PARTS...
  • Page 19 THIS PAGE IS INTENTIONALLY LEFT BLANK USE ONLY PARAMOUNT GENUINE REPLACEMENT PARTS...

  • Page 20: Use Only Hayward Genuine Replacement Parts

    For further information or consumer technical support, visit our website at www.1Paramount.com Hayward is a registered trademark of Hayward Industries, Inc. © 2024 Hayward Industries, Inc. All other trademarks not owned by Hayward are the property of their respective owners. Hayward is not in any way affiliated with or endorsed by those third parties.
