Summary of Contents for Titan Attachments JDRDBLGRPv2b
- Page 1 ROUND BALE GRIPPERS RDBLGRPv2b, 3PTRDBLGRPv2b, JDRDBLGRPv2b 191659, 191669, 191693 Operator’s Manual Read the Operator’s Manual entirely. When you see this symbol, the subsequent instructions and warnings are serious follow without exception. Your life and the lives of others depend on it!
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION THESE ARE STANDARD PRACTICES THAT MAY NOT APPLY TO THE PRODUCTS DESCRIBED IN THIS MANUAL. SAFETY AT ALL TIMES Thoroughly read and understand the instructions given in this manual before operation. Refer to the “Safety Label” section, read all instructions noted on them. Do not allow anyone to operate this attachment who has not fully read and comprehended this manual and who has not been properly trained in the safe operation of attachment. -
Page 3: For Your Protection
BE AWARE OF SAFETY ALERT WORDS – A signal word designates a degree or level of hazard seriousness. The signal words are: DANGER: Indicates imminently hazardous practices. A situation that, if not avoided, will result in death or severe injury. The signal word is limited to the most extreme situation, typically for machine components that, for functional purposes, cannot be guarded. -
Page 4: Transport Machinery Safely
Flashing warning lights and we recommend turn signals whenever driving on the public • road. TRANSPORT MACHINERY SAFELY Comply with state and local laws. • The maximum transport speed for implement is 20 mph, DO NOT EXCEED. Never travel at •... -
Page 5: Wear Protective Equipment
WEAR PROTECTIVE EQUIPMENT Wear protective clothing and equipment appropriate for the job. Avoid loose-fitting • clothing. Prolonged exposure to loud noise can cause hearing impairment or hearing loss. Wear • suitable hearing protection such as earmuffs or earplugs. Operating equipment safety requires the full attention of the operator. Avoid wearing •... -
Page 6: Safety Labels
SAFETY LABELS Your Bale Grabber comes equipped with all safety labels in place. They were designed to help you to safety operate your attachment. Read and follow their directions. Decal: Warning-Before operating Decal: Warning – High pressure fluid hazard Decal: Warning-Pinch point or crushing hazard This shows the grease position. -
Page 7: Using This Manual
APPLICATION The RDBLGRPv2b, 3PTRDBLGRPv2b, and JDRDBLGRPv2b bale grabbers make loading and unloading round bales up to 77” in diameter easy. They are designed with hydraulically operated grab arms to efficiently and quickly pickup, move, and stack round bales on their side or end. The grab arms are constructed of heavy tubular steel that wrap around a large area of the bale for grabbing the bale without damaging the plastic wrap. -
Page 8: Hydraulic Outlets
SKID STEER/TRACTOR REQUIREMENT This bale grabber is designed to attach to skid steers, track loaders, or tractor frontend loaders. The following requirements below must be met: HITCH TYPE RDBLGRPv2b……………………………………………………………………Skid steer quick attach (meets ISO 24410) 3PTRDBLGRPv2b……………………………………………………………. Tractor 3-Points hitch. Hydraulic pressure rating (Maximum) ………………………….3500 psi HYDRAULIC OUTLETS Skid steer/track loader………………………………………………….1 male &... -
Page 9: Section 1: Assembly And Setup
SECTION 1: ASSEMBLY AND SETUP Packing Description 1. Remove and check. Remove the packing, check goods without defect and omission. Figure 1-1: Your New Bale Grabber as It Is Shipped to You Figure 1-2: The Bale Grabber and Accessory in Package 2. - Page 10 The detailed description of bale grabber RDBLGRPv2b frame and fittings Figure 1-3: Bale Grabber RDBLGRPv2b Frame and fittings List The detailed description of bale grabber 3PTRDBLGRPv2b frame and fittings Figure 1-4: Bale Grabber WD70D Frame and fittings Table 1-4: Bale Grabber 3PTRDBLGRPv2b Frame and fittings List...
- Page 11 The detailed description of bale grabber JDRDBLGRPv2b frame and fittings Figure 1-5: Bale Grabber JDRDBLGRPv2b Frame and fittings Table 1-5: Bale Grabber JDRDBLGRPv2b Frame and fittings List...
- Page 12 The detailed description of hydraulic cylinder and fittings Figure 1-6: Hydraulic Cylinder and Fittings Table 1-6: Hydraulic Cylinder and Fittings List...
-
Page 13: Installation
INSTALLATION The installation section will guide you to finish the final assembly of your new bale grabber easily. The installation wizard is applicable to RDBLGRPv2b, 3PTRDBLGRPv2b and, JDRDBLGRPv2b models. 1. TOOL REQUIRED 27-30 Spanner, Long-nose plier 2. ASSEMBLY Cut all zip ties and disassemble shipping crate. - Page 14 Note - Loosen 2pcs of the hollow bolts to release the pressure in the cylinder. That will make the cylinder flexible and easy to install. Figure 1-7: Installing Wheel Frame and Fittings Item 1: Grab arm weldment L (1pc); Item 2: Cylinder pivot pin (2pc); Item 3: Bale grabber frame weldment (1pc);...
-
Page 15: Section 2: Operating
SECTION 2: OPERATING OPERATOR’S RESPONSIBILITIES Hazard control and accident prevention are dependent upon the awareness, concern, prudence, and proper training involved in the operation, transport, storage, and maintenance of the bale grabber. Therefore, it is absolutely essential that no one operates the bale grabber unless they have read, fully understood, and are totally familiar with the Operator’s Manual. - Page 16 1. Check for and remove any debris in the front loader and Bale Grabber hitch point areas before hooking-up to the attachment. 2. Drive slowly up to the attachment’s hitch plate (#3) while making sure the loader’s quick attach hitch is parallel with the attachment’s top angle bars (#5). 3.
- Page 17 5. Complete hydraulic hook up. The JDRDBLGRPv2b Bale Grabber is designed for attaching to John Deer front loader Refer to Figure 2-3: Figure 2-3: Hook-up JDRDBLGRPv2b Bale Grabber 1. Check for and remove any debris in the John Deer front loader and Bale Grabber hitch point areas before hooking-up to the attachment.
-
Page 18: Equipment Clearances
EQUIPMENT CLEARANCES It is important to check clearances before putting the Bale Grabber into operation. Make sure hydraulic hoses are long enough and will not become pinched or entangled in the equipment. Also, make sure the Bale Grabber does not make contact with the power machine frame and tires by carefully going through its full range of motion. - Page 19 Figure 2-4: Incorrect Large Bale Containment 1. Be sure to read and understand all safety alerts under the “safety information” section. 2. Make sure the bale does not exceed rated lift capacity of the power machine lifting the bale. 3. Check for overhead obstructions. 4.
- Page 20 D. Raise the bale off the ground while tilting the hitch back until the bale is vertical and slightly off the ground. Figure 2-5: Correct Large Bale Containment Figure 2-6: Incorrect Large Bale Containment Transport Round Bales 1. Check to make sure the Bale Grabber has a good grip on the bale. If it does not, release the bale and recapture it in a more secure location.
- Page 21 7. Leave enough clearance when turning so that the Bale Grabber and/or round bale do not contact obstacles such as buildings, trees, fences, etc. 8. When traveling over a ramp or incline, keep the heavy end on the “uphill” side of the power machine.
-
Page 22: Section 3: Maintenance & Lubrication
SECTION 3: MAINTENANCE & LUBRICATION MAINTENANCE Proper servicing and adjustments are key to the long life of any attachment. With careful inspection and routine maintenance, you can avoid costly downtime and repair. Check all hardware after several hours of operation and regularly thereafter, to ensure they are tight and secured. LONG-TERM STORAGE Clear, inspect, service, and make necessary repairs to the attachment when storing it for long periods and at the end of the season. -
Page 23: Section 4: Specification & Capacities
SECTION 4: SPECIFICATION & CAPACITIES... -
Page 25: Section 5: Troubleshooting
SECTION 5: TROUBLESHOOTING... -
Page 26: Section 6: Appendix
SECTION 6: APPENDIX Bolt Torque The tables shown below give correct torque values for various bolts and cap screws. Tighten all bolts to the torques specified unless otherwise noted. Check tightness of bolts periodically, using bolt torque chart as a guide. - Page 27 PARTS DIAGRAM/EXPLODED VIEW BALE GRABBER RDBLGRPV2B PART LIST...
- Page 28 BALE GRABBER RDBLGRPV2B PART LIST...
- Page 29 BALE GRABBER 3PTRDBLGRPV2B PART LIST...
- Page 30 BALE GRABBER 3PTRDBLGRPV2B PART LIST...
- Page 31 BALE GRABBER JDRDBLGRPv2b PART LIST...
- Page 32 ACKNOWLEDGEMENT OF RISK AND RELEASE OF LIABILITY The use of any equipment, including this one, involves the potential risk of injury. Apart from any warranty claim that might be presented for a claimed defect in material or workmanship of the product, you accept and assume full responsibility for any and all injuries, damages (both economic and non- economic), and losses of any type, which may occur, and you fully and forever release and discharge Titan, its insurers, employees, officers, directors, associates, and agents from any and all claims,...
- Page 33 NEED HELP? CONTACT US FIRST. 1-800-605-7595 info@palletworks.com www.palletforks.com © 2024 Titan Brands...
