Summary of Contents for Victory UltraSpec RFS Series
- Page 1 INSTALLATION AND OPERATING INSTRUCTIONS for all Hydrocarbon RFS and RFSA Refrigerator / Freezer Models 809-194A 07/23/2024 SEE BACK COVER FOR 3779 CHAMPION BLVD, WINSTON-SALEM, NC 27105 WARRANTY REGISTRATION Phone: (888) 845-9800 | Fax: (800) 253-5168 | Web:victoryrefrigeration.com...
-
Page 2: Table Of Contents
From the earliest stages of production design, to focused steps in fabrication and assembly, rigid standards of We thank you for your choice and confidence in Victory quality are maintained by our staff of skilled employees. Equipment. -
Page 3: Safety
R290 equipment. • Clean a dirty condenser with a sharp object. • Use ONLY Victory factory service parts. Use of non • Store gasoline, kerosene or any other flammable OEM parts can be dangerous because of the design material near the cabinet. - Page 4 User Manual for RFS & RSFA Refrigerator Freezer Victory SAFETY CAUTION: If it is necessary to move the Refrigerator after removal from the skid, CAUTION remove all doors and carefully push the unit at a point of no more than 36” from the bottom to avoid damage.
-
Page 5: Important Information
User Manual for RFS & RSFA Refrigerator Freezer Victory IMPORTANT INFORMATION This unit is intended to be used in a commercial application. That includes bars and restaurants. If installed in a residence some commercial service companies may not be able to service it on site. -
Page 6: Product Information
User Manual for RFS & RSFA Refrigerator Freezer Victory PRODUCT INFORMATION Cabinet Dimensions Half or Glass or Full Load Refrigerant Type / Charge Model Sections w x d x h (Inches) Full Door Solid Door Amps (g) / Charge (oz.) -
Page 7: Clearance And Placement Of Single Door Models
User Manual for RFS & RSFA Refrigerator Freezer Victory CLEARANCE AND PLACEMENT OF SINGLE DOOR MODELS 0" 12" LEFT/RIGHT SIDE MINIMUM MINIMUM CLEARANCE CLEARANCE 0" REAR MINIMUM CLEARANCE 0" 6" BOTTOM BOTTOM MINUMUM MINIMUM CLEARANCE CLEARANCE Placement Consider the following when selecting a location for your Refrigerator:... -
Page 8: Clearance And Placement Of Two Door Models
User Manual for RFS & RSFA Refrigerator Freezer Victory CLEARANCE AND PLACEMENT OF TWO DOOR MODELS REAR 6" BOTTOM MINIMUM CLEARANCE Placement Consider the following when selecting a location for your Refrigerator: Clearance: Two Door Models • 12 in. at the top •... -
Page 9: Unpacking And Set Up
User Manual for RFS & RSFA Refrigerator Freezer Victory UNPACKING AND SET UP Carefully inspect the shipping carton for damage. This is the only time that shipping damage may be claimed. If damage is suspected, open the carton immediately and, if there is damage, retain the carton and contact the shipper to make a claim. -
Page 10: Shelf Installation
9. Do NOT overload the shelves. The unit is designed to need to be squeezed slightly during installation. use all shelves that are supplied in an equally spaced manner. Contact Victory customer service if fewer 4. Install all remaining clips. shelves or a different configuration to ensure shelf overloading will not occur. -
Page 11: Electrical
4 to 6 mA. To avoid this issue piece of equipment in a location that requires GFCI circuit protection, Victory recommends using either an Eaton, SCF20, or HUBBELL Check that all clearances are in line with the Model Number GFRST83W 20A Heavy Duty Hospital aforementioned guidelines. -
Page 12: Using The Unit
User Manual for RFS & RSFA Refrigerator Freezer Victory USING THE UNIT Operation is simple, just keep it connected to the correct The freezer temperature was set at the factory at 0 F., but power supply and the refrigerator will maintain the it may be adjusted to a different temperature. -
Page 13: Sequence Of Operations - Refrigerator
User Manual for RFS & RSFA Refrigerator Freezer Victory SEQUENCE OF OPERATIONS - REFRIGERATOR COMPONENT OPERATION CONTROLLER ACTION OPERATION CONTROLLER ACTION COMPRESSOR Compressor turns The Compressor Compressor turns The Compressor on when the cabinet Contact is energized off when the cabinet... -
Page 14: Sequence Of Operations Freezer
User Manual for RFS & RSFA Refrigerator Freezer Victory SEQUENCE OF OPERATIONS FREEZER COMPONENT OPERATION CONTROLLER ACTION OPERATION CONTROLLER ACTION COMPRESSOR Compressor turns The Compressor Compressor turns The Compressor on when the cabinet Contact is energized off when the cabinet... -
Page 15: Control Panel Display
User Manual for RFS & RSFA Refrigerator Freezer Victory CONTROL PANEL DISPLAY Control Panel Indicators Icon Operation Meaning Compressor Permanently On Compressor On Blinking Delay, protection or start-up blocked Otherwise Defrost Permanently On Defrost active Blinking Activated manually or from Digital input... - Page 16 User Manual for RFS & RSFA Refrigerator Freezer Victory Relay/Probe Terminal Compressor 10,11 Out 1 Evaporator Fan 4, 5 Out 2 Defrost Element 7, 9 Out 3 Light (or alarm relay if electronic Lock model) 13, 14 Out 4 Air/control probe 18, 19 PB1 –...
-
Page 17: Electronic Controller Parameter Changes
User Manual for RFS & RSFA Refrigerator Freezer Victory ELECTRONIC CONTROLLER PARAMETER CHANGES Note: Key pad has a 3 second lock feature. Set key must be pressed for 3 seconds and released before keys will become active. Key pad will beep when unlocked and normal key pad operations performed. -
Page 18: Setting The Real Time Clock
User Manual for RFS & RSFA Refrigerator Freezer Victory SETTING THE REAL TIME CLOCK To set the real time clock, press and release the set button to enter the machine status menu. “Set will appear on the menu. Use the up and down button to scroll to the real time clock menu folder. “Rtc” will appear on the display. - Page 19 User Manual for RFS & RSFA Refrigerator Freezer Victory Rev. 07/24 Victory...
- Page 20 User Manual for RFS & RSFA Refrigerator Freezer Victory Code Description Description Relay Reset Parameters involved to Enable alarm Probe Pb1 failure Active Automatic Ont, Oft Probe Pb2 failure Active Automatic Ont, Oft Probe Pb3 failure Active Automatic Ont, Oft...
-
Page 21: Cleaning And Maintenance
User Manual for RFS & RSFA Refrigerator Freezer Victory CLEANING AND MAINTENANCE Cleaning Schedule: Cabinet Condenser coil Gaskets Routine maintenance Daily wipe down Monthly inspection, Daily inspection, check Annually cleaning as required that hinges are tight to Weekly interior the cabinet. -
Page 22: Condenser Cleaning
User Manual for RFS & RSFA Refrigerator Freezer Victory CONDENSER CLEANING Keeping the condenser coil clean is critical to efficient 4. Remove the panel stand from its clip and secure into operation. the notch in the front right corner of the raised panel 1. -
Page 23: Methods For Cleaning Stainless Steel
User Manual for RFS & RSFA Refrigerator Freezer Victory METHODS FOR CLEANING STAINLESS STEEL Cleaning Needed Cleaning Agent Method of Application Affect on Finish Satisfactory for use on all Areal 20, Lac-O-Nu, Lumin Wash Rub with cloth as directed finishes. -
Page 24: Help
User Manual for RFS & RSFA Refrigerator Freezer Victory HELP Trouble Diagnosis for the User Malfunction Possible Cause Likely Solution Connect to proper voltage circuit Replace Unit not plugged in. fuse or reset breaker. No cooling - unit is silent Fuse or circuit breaker tripped. -
Page 25: For The Service Tech - R290
User Manual for RFS & RSFA Refrigerator Freezer Victory FOR THE SERVICE TECH - R290 Refrigeration service should only be attempted by a trained trade professional certified to work on R290 systems. Here are some critical service items. Other Information: This list does not qualify anyone to service the unit. -
Page 26: For The Service Tech - Refrigerator Wiring Diagram
User Manual for RFS & RSFA Refrigerator Freezer Victory FOR THE SERVICE TECH - REFRIGERATOR WIRING DIAGRAM BLACK WHITE 115VAC 60 HZ EVAP FAN RELAY CONTROL CIRCUIT COMPRESSOR DETAIL CONDENSER FAN START RELAY S.C. COMP R.C. COMP RELAY HIGH PRESSURE... -
Page 27: For The Service Tech - Freezer Wiring Diagram
User Manual for RFS & RSFA Refrigerator Freezer Victory FOR THE SERVICE TECH - FREEZER WIRING DIAGRAM BLACK WHITE 115VAC 60 HZ BLACK EVAP FAN RELAY CONTROL CIRCUIT DEFROST HEATERS DEF RELAY HEATER SAFETY THERMAL SWITCH COMPRESSOR DETAIL CONDENSER FAN START RELAY S.C. -
Page 28: Limited Warranty
Victory LIMITED WARRANTY Warranty (Continental USA & Canada Only) Proof of purchase must be supplied to Victory to validate the warranty. This warranty is valid only SEVEN (7) YEAR PARTS, LABOR, AND COMPRESSOR if equipment is properly installed, and started-up as LIMITED WARRANTY outlined in the Owner’s Manual. -
Page 29: Limited Warranty (Continued)
Special installation/applications, including remote LIMITATION OF LIABILITY: locations, are limited in coverage by this warranty. Victory or its affiliates shall not be liable for any Any installation that requires extra work, and/ indirect, incidental, special or consequential or travel, to gain access to the unit for service is damages, or losses of a commercial nature arising the sole responsibility of the equipment purchaser. -
Page 30: Warranty Registration
User Manual for RFS & RSFA Refrigerator Freezer Victory Warranty Registration Register your product online at Victory.com/parts-service or fill out and mail the form below. Cabinet Model Number: _____________________________________________ Date Of Installation: _________________ Cabinet Serial Number: _____________________________________________ Location Of Product...
