HMNF
Thank you for your purchase. Before discarding packaging material be sure you have
located all the parts including the necessary hardware and tools listed on the instruction
sheet below.
Parts List
# 1
1pc
Metal Top Frame
# 4
1pc
Glass Top
Hardware List
No
Figure
A
B
Please do not tighten any bolt firmly before you put all of them in place.
Step 1) Put all parts on a soft surface to prevent scratches. Attach metal legs (#2) to metal
top frame (#1) by using bolt (B) as shown.
# 2
8pcs
Metal Leg
Description
Tapered Bolt 1/4" x
20 x 7/8"
Tapered Bolt 1/4" x
20 x 1/2"
QTY
No
Figure
8
C
16
D
Assembly Instruction
1662-2
END TABLE
SKU# 23016620
# 3
1pc
Metal Bottom Frame
Description
10mm Ø Glass Tips
4mm Hex Allen
Wrench
QT
Y
4
1
Advertisement
Related Manuals for ROOMS TO GO Nadine 23016620
Summary of Contents for ROOMS TO GO Nadine 23016620
- Page 1 Assembly Instruction 1662-2 END TABLE HMNF SKU# 23016620 Thank you for your purchase. Before discarding packaging material be sure you have located all the parts including the necessary hardware and tools listed on the instruction sheet below. Parts List 8pcs Metal Top Frame Metal Leg Metal Bottom Frame...
- Page 2 Step 2) Attach metal bottom frame (#3) to metal legs (#2) by using bolt (A) as shown then tighten all bolts firmly. Step 3) Turn the table upside down, put glass tips (C) onto metal top frame (#1) then put glass top (#4) on frame as shown carefully.
