- Page 1 User’s manual – A S Sandblast cabin 90 L REBO Sandblast cabin 90 L AR-HE-SK90LN Please follow all security measures in this user’s manual to ensure a secure use. Thank you for trusting in AREBOS.
-
Page 2: Table Of Contents
User’s manual – A S Sandblast cabin 90 L REBO List of content 1. Security Instructions ........3 1.1 Explanation of the symbols ......................3 1.2 Allgemeine Sicherheitshinweise ....................4 1.3 Specific safety instructions ......................4 2. Intended Use ..........6 3. -
Page 3: Security Instructions
User’s manual – A S Sandblast cabin 90 L REBO 1. Security Instructions 1.1 Explanation of the symbols This product must not be disposed of with household waste! By means of a CE marking, it can be recognized that a product complies with the legal requirements of European legal standards and therefore may be traded within the European Community. -
Page 4: Allgemeine Sicherheitshinweise
User’s manual – A S Sandblast cabin 90 L REBO Warning! Smoking prohibited! 1.2 Allgemeine Sicherheitshinweise • Please read the instructions before using the device. Failure to follow these instructions may result in injury to the user or voiding the warranty of the sandblast cabin. •... - Page 5 User’s manual – A S Sandblast cabin 90 L REBO • Check the device for completeness, function and tightness before commissioning! • This tool complies with all relevant safety regulations. Repairs may only be carried out by qualified electricians in authorized service centers using the original spare parts. If disregarded, there is a risk of accidents.
-
Page 6: Intended Use
Attention: The Canadian Electrical Code prohibits the use of three-pole adapters. Abrasive materials are very slippery and should be cleaned as quickly as possible to prevent possible injury. 3. Technical Specifications Model AR-HE-SK90LN Capacity 90 L Max. working pressure 80 PSI/ 5,52 bar... -
Page 7: Assembly
User’s manual – A S Sandblast cabin 90 L REBO Weight 28.7 Ibs (13 kg) Color 4. Assembly 4.1. Connect the side panels to the front and back panels using 5 x 10 mm screws and 8 mm nuts, as well as a Phillips type screwdriver and a 8 mm wrench, as shown in Figures 1 and 2. - Page 8 User’s manual – A S Sandblast cabin 90 L REBO Figure 3: Attaching the brackets 4.2. Next, the base of the sand-blasting cabinet is attached to the frame built in Step 4.1. To do this, align the base, as seen in Figure 4. Figure 4: Aligning the base 4.3.
- Page 9 User’s manual – A S Sandblast cabin 90 L REBO Figure 5: 6 x 12 mm screw with a washer and nut 4.4. Now, using a Phillips type screwdriver and a 10 mm wrench, tighten the respective three middle screws with the 10 mm nut shown in Figure 5. Figure 6: Tightening of the nut at the base of the sand-blasting cabinet 4.5.
- Page 10 User’s manual – A S Sandblast cabin 90 L REBO Figure 7: Aligning a leg 4.6. Light installation 4.6.1. Next, attach the light bracket to the back panel on the inside of the sand-blasting cabinet using a 5 x 5 mm screw and a 8 mm nut (Figures 8 and 9). Figure 8: Light bracket...
- Page 11 User’s manual – A S Sandblast cabin 90 L REBO Figure 9: Attaching the light bracket 4.6.2. Fasten the light by pressing it into the previously installed bracket until it snaps in. See Figure Figure 10: Fitting the fluorescent tube 4.6.3.
- Page 12 User’s manual – A S Sandblast cabin 90 L REBO Figure 11: Dismantling the switch box 4.6.4 Slide the plastic seal over the light cable, as seen in Figure 12. Figure 12: Installing the seal 4.6.5. Thread the cable with the seal through the opening of the switch box, as seen in Figure 13, and attach it from the outside using the plastic nut, which is shown in Figure 14.
- Page 13 User’s manual – A S Sandblast cabin 90 L REBO Figure 13: Attaching the light cable Figure 14: Tightening the plastic bolt 4.6.6. Connect the light cable to the switch box, which was dismantled in Step 4.6.3. To do this, connect the blue cable from the light cable over the blue cable on the switch box.
- Page 14 User’s manual – A S Sandblast cabin 90 L REBO Figure 15: Connecting the cables in the switch box 4.7. Foam filter installation 4.7.1. To assemble the foam filter, the red ring (see Figure 16) must be pulled over the filter and three 5 x 20 mm screws must be inserted into the right side of the sand-blasting cabinet.
- Page 15 User’s manual – A S Sandblast cabin 90 L REBO Figure 17: Attaching the foam filter 4.8. Gun installation 4.8.1. The thick tube must be attached to the front of the gun using a tube clamp. See Figure 18. Figure 18: Attaching the thick tube to the sand-blasting gun...
- Page 16 User’s manual – A S Sandblast cabin 90 L REBO 4.8.2. Using a tube clamp, attach the other end of the thick tube to the thin side of the red metal pipe, which will lie at the base of the sand-blasting cabinet in order to suck in sand. See Figure 19. Figure 19: Attaching the thick tube to the metal pipe 4.8.3.
- Page 17 User’s manual – A S Sandblast cabin 90 L REBO Figure 21: Compressed air inlet outside 4.8.4. Now, attach the thin tube to the inside of the compressed air inlet and the compressed air gun. Place the small tube clamps on both ends of the tube and tighten these. See Figure 22. Figure 22: Attaching the thin tube to the compressed air inlet on the inside of the sand-blasting cabinet...
- Page 18 User’s manual – A S Sandblast cabin 90 L REBO 4.9. Attach the gloves to the inside of the sand-blasting cabinet through the two cutouts at the front. To do this, pull the sleeve of the glove over the rim of the cutout and attach the sleeve using a large tube clamp.
- Page 19 User’s manual – A S Sandblast cabin 90 L REBO 4.11. Attaching the lid 4.11.1. Use three metal screws, respectively, to attach the two hinges of the lid. See Figure 25. Figure 25: Attaching the hinges 4.11.2. Attach the lid chain on the right, above the filter, using a 6 x 12 mm screw and a 10 mm nut. See Figure 26.
- Page 20 User’s manual – A S Sandblast cabin 90 L REBO 4.12. Attach the levers to close the sand-blasting cabinet to the right side and the left side of the sand-blasting cabinet, using a 4 x 20 mm screw and a 8 mm nut. See Figure 27. Figure 27: Attaching the levers to close the sand-blasting cabinet 4.13.
- Page 21 User’s manual – A S Sandblast cabin 90 L REBO 4.13.2. Place the metal grid on the base of the sand-blasting cabinet. Ensure that the gloves and gun are placed on top of the metal grid. See Figure 29. Figure 29: Correct position of the metal grid 4.13.3.
-
Page 22: Commissioning
User’s manual – A S Sandblast cabin 90 L REBO 4.13.4. In the final step, the cleaned edges are sealed with sealing paste. Allow adequate ventilation when drying. Figure 31: Sealing paste Further installation instructions • Set up the sand-blasting system close to a 240 V/50 Hz (115 V/ 60 Hz) power supply. Make sure that the socket is suitable for a 3-pronged plug, so grounding can be ensured. -
Page 23: Cleaning And Maintenance
User’s manual – A S Sandblast cabin 90 L REBO too concentrated to avoid an unwanted hammering effect. 6. Cleaning and Maintenance 6.1 Basic maintenance procedure • Note: Disconnect the power connection and air supply before any maintenance work! • Clean the dust collector and filters regularly. -
Page 24: Storage
User’s manual – A S Sandblast cabin 90 L REBO 6.5 Storage • For prolonged storage, the machine should be thoroughly cleaned. • Store the device in a clean, dry place. 7. Troubleshooting PROBLEM REASON SOLUTION - Air vent clogged or airflow - Clean the rear air vent blocked. -
Page 25: Disposal Instruction
User’s manual – A S Sandblast cabin 90 L REBO 8. Disposal Instruction 8.1 Disposal of the packaging • Please make reference to the guidelines and standards for appropriate disposal of the packaging valid in your region. In part, the package may consist of plastic bags - watch this respect, with special care to ensure that this is not out of the reach of children. -
Page 26: Eu Declaration Of Conformity
Hereby declare that the product named below, seen its design and construction as well as according to our sales, has been complied with the relevant and basic health and safety EU-requirements. Name of the product: AREBOS Sandblast cabin 90 L Article Nr.: 4260627422920 Model Nr.: AR-HE-SK90LN...
