LCD32P69N
1. A burning period of 45 minutes should be allowed before any operation.
2. Parts that fail to meet the technical requirements, even after debugging, should be
sent for repair with the duly completed process flow card.
3. Signal strength for relevant stations, unless otherwise stipulated, should be
65±3dBuv.
4. Activities of each process may adjust to the actual needs, provided the
requirements on specifications and tact are met.
5. Any analog data which is not specified in this article should be comply standard
status.
6. The way to enter the factory mode with user remote:
Press "Menu" key and select "sound balance" option, and input 0532.
The way to enter the factory mode with factory remote:
Press "M" key.
7. The way to quit the factory mode with user remote:
Press "POWER" key.
The way to quit the factory mode with factory remote:
Press "M" key.
8. The way to enter factory after OK is Pressing "Menu" key and select "sound
balance" option, and input 0532.when we enter factory ,we change U to M at
TOAFC menu.
底 图 总 号
日期
签名
更改标记
PDF created with pdfFactory Pro trial version
Technical
Notes
更改单号
签 名
数 量
code name
RSAG2.025.1051
color TV receiv r
title
Technical Notes
设 计
审 核
标准化
日 期
批 准
www.pdffactory.com
RSAG2.025.1051-GTS
Serial No.
final inspection
Process
Page 1 of 21
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hisense LCD32P69N
Summary of Contents for Hisense LCD32P69N
- Page 1 Technical RSAG2.025.1051-GTS code name RSAG2.025.1051 Serial No. LCD32P69N Notes color TV receiv r final inspection title Process Technical Notes 1. A burning period of 45 minutes should be allowed before any operation. 2. Parts that fail to meet the technical requirements, even after debugging, should be sent for repair with the duly completed process flow card.
- Page 2 Technical code name RSAG2.025.1051 Serial No. RSAG2.025.1051-GTS LCD32P69N Notes color TV receivr final inspection title P r o c e s s TV CHECK I. Instruments, pallets and tools 1. Factory Remote （HYDFSR-N-WB） II. Operation instructions 1. Pressing the “aging” key for two seconds to quit “aging” state. Press the factory’s “M”...
-
Page 3: Technical Notes
Technical code name RSAG2.025.1051 Serial No. RSAG2.025.1051-GTS LCD32P69N Notes title color TV receiver final inspection Process 3) Make sure the picture and white balance are defect free. Note: IF the white balance is deviative , enter factory mode and adjust the “... - Page 4 Technical code name RSAG2.025.1051 Serial No. RSAG2.025.1051-GTS LCD32P69N Notes color TV receiver final inspection title P r o c e s s 6. Receive the digital card signal via channel PZ01 to Make sure the picture resolution is no less than 300*400 lines (horizontal*vertical).
- Page 5 Technical code name RSAG2.025.1051 Serial No. RSAG2.025.1051-GTS LCD32P69N Notes color TV receiver final inspection title P r o c e s s 8、Receive RED signal via channel PI49. Press “I/II” key continuously and make sure the function of NICAM is normal.
- Page 6 Technical code name RSAG2.025.1051 Serial No. RSAG2.025.1051-GTS Notes LCD32P69N final inspection P r o c e s s title color TV receiver VGA CHECK I. Instruments, pallets and tools ） MIK-8256 1.Programmable signal generator（ 2. Factory Remote （HYDFSR-N-WB） II. Operation instructions 1.
- Page 7 Technical code name RSAG2.025.1051 Serial No. RSAG2.025.1051-GTS LCD32P69N Notes color TV receiver final inspection title P r o c e s s (time:13 Pattern：30) (TIME:13 PATTEN:96) ②IF the white balance is deviative, enter factory mode to adjust the RDRV、 GDRV、BDRV、RCUT、GCUT、BCUT to make the color normal.
- Page 8 Technical code name RSAG2.025.1051 Serial No. RSAG2.025.1051-GTS LCD32P69N Notes color TV receiver final inspection title P r o c e s s YPbPr INPUT CHECK I. Instruments, pallets and tools 1. Program signal generator（MIK-8256） 2. Factory Remote （HYDFSR-N-WB） II. Operation instructions 1.
- Page 9 Technical code name RSAG2.025.1051 Serial No. RSAG2.025.1051-GTS LCD32P69N Notes color TV receiver final inspection title P r o c e s s 3. (1)IF the picture abnormal, Receive the SMPTE signals(TIME:81 PATTERN： 96) from the signal generator. Enter to M mode, press “TILT” key to do color optimization.
- Page 10 Technical RSAG2.025.1051-GTS code name RSAG2.025.1051 Serial No. LCD32P69N Notes color TV receiver final inspection title P r o c e s s 4.Receive FINAL TEST(TIME:81 PATTEN:96) (1)Make sure the horizontal center and horizontal amplitude: Horizontal center deviation should remain within 2mm with the screen center line.
- Page 11 Technical RSAG2.025.1051-GTS code name RSAG2.025.1051 Serial No. LCD32P69N Notes color TV receiver final inspection title P r o c e s s HDMI CHECK I. Instruments, pallets and tools 1.Programmable signal generator（BSG-360A） 2. User Remote （EN-21662） 3. SPDIF decoder II. Operation instructions 1.
-
Page 12: Headphone Check
RSAG2.025.1051 S e r i a l N o . Technical RSAG2.025.1051-GTS LCD32P69N Notes color TV receiver final inspection title P r o c e s s AV INPUT、OUTPUT 、S-VIDEO HEADPHONE CHECK I. Instruments, pallets and tools 1. Programmable signal generator（BSG-360A）... - Page 13 Serial No. Technical RSAG2.025.1051 RSAG2.025.1051-GTS LCD32P69N Notes color TV receiver final inspection title P r o c e s s 3. Receive signal channel PZ35, and make sure the picture and the sound are normal, Connect AV signal cable to AV OUTPUT, Make sure the waveform below displayed on the oscilloscope is normal.
- Page 14 Technical RSAG2.025.1051-GTS code name RSAG2.025.1051 Serial No. LCD32P69N Notes P r o c e s s final inspection title Color TV receiver SCART INPUT AND OUTPUT、CANAL+ CHECK I. Instruments, pallets and tools 1. AV signal generator 2. User Remote （EN-21662）...
- Page 15 Technical RSAG2.025.1051-GTS code name RSAG2.025.1051 Serial No. LCD32P69N Notes color TV receiver final inspection title P r o c e s s Note: SCART1 support the CVBS and RGB format. SCART2 support the CVBS and YC format. 底 图 总 号...
-
Page 16: Component Arrangement
Technical RSAG2.025.1051-GTS code name RSAG2.025.1051 Serial No. LCD32P69N Notes color TV receiver final inspection title P r o c e s s ! Component arrangement I. Instruments, pallets and tools 1. Sharp-nosed pliers (160mm) 2. Diagonal pliers 3. Cross-headed screwdriver 4. -
Page 17: Back Cover Installation
Technical RSAG2.025.1051-GTS code name RSAG2.025.1051 Serial No. LCD32P69N Notes color TV receiver final inspection title P r o c e s s Back cover installation As per "Final Assembly" manual 底 图 总 号 设 计 审 核 日期 签名... - Page 18 Technical RSAG2.025.1051-GTS code name RSAG2.025.1051 Serial No. LCD32P69N Notes color TV receiver final inspection title P r o c e s s ! Secure Overall Inspection I. Instruments, pallets and tools 1. Secure overall tester (AN9640) 2. Standard checkout tester II.
- Page 19 Technical RSAG2.025.1051-GTS code name RSAG2.025.1051 Serial No. LCD32P69N Notes color TV receiver final inspection title P r o c e s s Manual function check of on-set buttons Operation instructions 1. Channel up/down button Press the buttons and make sure the buttons function properly. Picture and sound should remain normal when operating.
- Page 20 Serial No. Technical RSAG2.025.1051 RSAG2.025.1051-GTS LCD32P69N Notes color TV receiver final inspection title P r o c e s s Overall Inspection I. Instruments, pallets and tools 1. User Remote （EN-21662） 2. Signal reducer (QF3110C) 3. Rubber hammer 4.
- Page 21 Technical RSAG2.025.1051-GTS code name RSAG2.025.1051 Serial No. LCD32P69N Notes color TV receiver final inspection title P r o c e s s Visual Inspection As per "Final Assembly" manual 底 图 总 号 设 计 审 核 日期 签名 标准化...
