PRONAR WWT620D / WWT624D

EDITION 2B-05-2019

PRONAR Sp. z o.o.

17-210 NAREW, UL. MICKIEWICZA 101A, PODLASKIE PROVINCE

tel.:

fax:

OPERATOR'S MANUAL

MULTI-FUNCTION ARM

TRANSLATION OF THE ORIGINAL INSTRUCTIONS

+48 085 681 63 29

+48 085 681 63 81

+48 085 681 63 83

PUBLICATION NO 21N-0000000001-UM

+48 085 681 64 29

+48 085 681 63 82

+48 085 682 71 10

www.pronar.pl

Need help?

Do you have a question about the WWT620D and is the answer not in the manual?

Questions and answers

Summary of Contents for PRONAR WWT620D

Page 1 +48 085 681 63 81 +48 085 681 63 82 fax: +48 085 681 63 83 +48 085 682 71 10 www.pronar.pl OPERATOR'S MANUAL MULTI-FUNCTION ARM PRONAR WWT620D / WWT624D TRANSLATION OF THE ORIGINAL INSTRUCTIONS EDITION 2B-05-2019 PUBLICATION NO 21N-0000000001-UM...
Page 3 MULTI-FUNCTION ARM PRONAR WWT620D / WWT624D MACHINE IDENTIFICATION SYMBOL /TYPE: SERIAL NUMBER:...
Page 4 The manual describes the basic safety rules and operation of multifunction arm PRONAR WWT620D / WWT624D. If the information stated in the Operator's Manual needs clarification then the user should refer for assistance to the sale point where the machine was purchased or to the Manufacturer.
Page 5 SYMBOLS APPEARING IN THIS OPERATOR'S MANUAL Information, descriptions of danger and precautions and also recommendations and prohibitions associated with user safety instructions are marked: and also preceded by the word "DANGER". Failure to observe the instructions may endanger the machine operator's or other person's health or life. Particularly important information and instructions, the observance of which is essential, are distinguished in the text by the sign: and also preceded by the word "ATTENTION".
