Panasonic Technics SU-CH7 Service Manual page 27

SU-CH7
Ref . No. Par t No.
Par t Nam e & Descr i pt i on Rem ar ks
CN500C RJS1A1705 SOCKET( 5P)
CN500D RJS1A1705 SOCKET( 5P)
CP201 RJT057W 010- 1 CONNECTOR( l OP)
CP202 RJ T0 5 7 W 0 4 - 1 CONNECTOR( 4P)
CP203 RJT0571) 10- 1 CONNECTOR( l OP)
CP601
RJT003KD10M 1 CONNECTOR( l OP)
CP602 RJT003K008M 1 CONNECTOR( 8P)
CP603 RJT003K010M 1 CONNECTOR( l OP)
CP604- 606 SJT30549BB1 CONNECTOR( 5P)
CP801, 802 RI T005W 007S C0NNECT0R( 7P)
CP901 RJ T0 5 7 D0 4 - 1 CONNECTOR( 4P)
CP902 SJT3213 CONNECTOR( 2P)
CP351 RJT057W ) 04- 1 CONNECTOR( 4P)
FUSE HOLDER( S)
FC1, 2
EYF52BC FUSE HOLDER
A
FC3, 4 SJT388 FUSE HOLDER A ( GC)
FC5- 8 EYF52BC FUSE HOLDER
A
RELAY
RLY700 SSY134 REUY
A
