- Page 1 Dental Chair Model: AJ18 User Manual * Picture for Reference Only...
- Page 3 COPYRIGHT ADS makes no warranty of any kind with regard to this material , including but not limited to, the implied warranties of merchantability and fitness for a particular purpose. ADS shall not be held liable for any errors contained herein or any consequential or other damages concerning furnishing, performance or use of this material.
- Page 4 User Manual CONTENT INTRODUCTION ������������������������������������������������������������������������������������������������������������ 5 1.1 Product Information ........................ 5 1.2 Symbols Explanation ....................... 5 DENTAL CHAIR COMPONENTS ���������������������������������������������������������������������������������������� 6 SPECIFICATIONS ����������������������������������������������������������������������������������������������������������� 6 3.1 Views and Dimensions ......................6 3.2 Technical Specifications ......................7 INSTALLATION PREPARATION ���������������������������������������������������������������������������������������� 8 4.1 Precautions..........................8 4.2 Tools and Instruments ......................
- Page 5 User Manual 1 INTRODUCTION The AJ18 dental chair incorporates a brand new design concept, striking a good balance in terms of ease of use, simplicity, and comfort. Product Information Name: Dental chair Model: AJ18 Working conditions: • Ambient temperature: 41℉-104℉...
- Page 6 User Manual 2 DENTAL CHAIR COMPONENTS The AJ18 dental chair consists of the components listed in the table. Headrest Backrest Armrest Touchpad Footswitch Seat Upholstery/Toeboard Junction Box 3 SPECIFICATIONS Views and Dimensions Unit: Inch 57.3 25.6 24.1 27.5 11.1 36.3 21.6...
- Page 7 User Manual 73.2 18.5 47.4 32.6 Technical Specifications Nominal Voltage 350 VA Patient Load 550 lb Max. Height from the Ground 32 IN Min. Height from the Ground 16.5 IN Range of Backrest Motion 10°- 60° Headrest Extension Length 0-5.9 IN Operating Temperature 41℉-104℉...
- Page 8 All electrical components and connections need to be installed by an authorized technician. • The fuse and accessories must be recognized by the authorized ADS dealer. • This chair must not operate in the environment of high temperature, high humidity, vibration flammability, unbalance, dusty, or strong electromagnetic.
- Page 9 User Manual 5 INSTALLATION Position the Chair 6. Locate the proper grab points. To position the dental chair: 7. Lift and place the chair in position of the treatment 1. Unpack the shipping boxes. room. 2. Remove all items and cardboard from around the chair.
- Page 10 User Manual Install Back Upholstery 5. Fix the power wire using the cable ties on the back upholstery armature. Prerequisite 6. Place the key holes in the back upholstery over the Before installing the back upholstery for the dental chair with the comfort kit: fastener posts on the back upholstery armature.
- Page 11 User Manual Install Headrest 2. Use four hexagon screws to attach the seat upholstery support frame to the chair frame. To Install the headrest: 1. Place the glide bar into the slot at the top of the back upholstery. 2. Push it down into place. ×2 3.
- Page 12 User Manual (Conditional) Install a Dental 4. Secure fixing holes at the bottom of the upholstery onto the press studs of the chair frame. Light Note: This section ONLY applies to the dental chair equipped with a dental light. ×2 To install the dental light: 1.
- Page 13 User Manual 3. Attach a trim ring to the upper end of the rigid arm, 5. Route the light cable from the light post into the then attach the intermediate post to the rigid arm, intermediate post, with the result that the light and finally attach a bushing to the upper end of the cable comes out at the other end of the rigid arm.
- Page 14 User Manual (Optional) Install a Delivery 7. Connect the light head cable terminal to the light arm cable terminal. Insert the light head into the System light flexarm. Securely tighten the screw. Finally The supported delivery systems are follows: slide the trim ring down into place. •...
- Page 15 User Manual 6 BASIC OPERATIONS Adjust the Chair 6.1.3 Adjust Headrest To adjust the headrest: 6.1.1 Power On the Chair • To adjust the headrest. The power switch of the equipment is in the position 1. Press and hold the switch behind the headrest. shown in the figure.
- Page 16 User Manual 6.1.4 Rotate the Chair The chair can be rotated 30° to the left or right. To rotate the chair: 1. Pull the lever to the Open position. 2. Rotate the chair to the desired position. 3. Lock the chair by pulling the level to the Close position.
- Page 17 User Manual Touchpad Introduction Touch pad centralizes the chair positioning operations. If the indicator light stays on, the system is on and ready for use. Initial position Setting Rinse position Preset position 1 Preset position 2 Preset position 3 Backrest up Backrest down Base up Base down...
- Page 18 User Manual Customize a Preset Position • Set to the rinse position. Press and release : the backrest is raised to To customize a preset position button (soft key), do the highest position. following on the touchpad or the footswitch: Press and release again: the backrest is restored 1.
- Page 19 User Manual (Optional) Use the Comfort Kit Touchpad The comfort kit provides heating and massage functions. And these functions are controlled by the comfort kit touchpad. Note: this section ONLY applies to dental chair equipped with a comfort kit. Heating for Backrest and Seat Massage for Backrest and Seat Prerequisite The central indicator light must stay on, which indicates that the system is on and ready for use.
- Page 20 User Manual 7 UPHOLSTERY CLEANING AND DISINFECTION The upholstery provides users with unparalleled comfort, excellent aesthetics, and reliable quality. The upholstery comes with a one-year warranty covering defective materials and workmanship. Following these instructions can help to ensure a longer life for the upholstery.
- Page 21 User Manual 8 WIRING DIAGRAM Wiring Diagram for the Dental Chair without Comfort Kit Seat Position Backrest Position Feedback Feedback Potentiometer BU Limit Switch Potentiometer 白 Yellow Black BU Limit Switch DN Limit Switch Black Safety Switch Black Safety Switch Black Hydraulic Magnetic Valves Group 220 V...
- Page 22 User Manual Wiring Diagram for the Dental Chair with Comfort Kit Seat Position Backrest Position Feedback Feedback Potentiometer Potentiometer BU Limit Switch Vibration Heating Module Vibration Heating Module 白 Yellow Black Ⅰ Ⅱ Ⅲ Ⅰ Ⅱ Ⅲ BU Limit Switch DN Limit Switch Black Safety switch...
- Page 24 ADS Dental System Add: 1590 S Milliken Ave., unit A, Ontario, CA 91761 E-mail: sales@adsequip.com Tel: (626)620 0456 Technical Support: 800-488-9708 www.adsdental.com / www.adsequip.com ● P/N: 8503093 ● Rev. C ● Issue Date: 2024/9/27...
