the
compartment
door.
@ The tape wil! be loaded
automatically.
. The
loading
dial
turns
and
stops
with
its
in-
dented
dot
aligned
with
the blue dot. The safety
catch
@ ~~ will
retract
automatically.
This
indi-
cates that tape loading is
completed.
REMOVING
THE
COMPACT
VIDEO
CASSETTE
1. Push the sliding latch @
in
the
direction
of
the
arrow.
e@The
tape
will
be
un-
loaded automatically.
5. Put the compact cassette
in its case for storage.
If the
battery
loading or unloading, the loading mechanism stops
midway.
In such a case, proceed as follows to load
or unload the tape manually.
is fully
discharged
during
tape
. Slide
the
battery
com-
partment
cover
in
the
direction of the arrow to
remove
and
take
the
battery
out
of the com-
partment.
. Using
a
coin,
turn
the
loading dial until it stops,
clockwise
for loading or
counterclockwise
for un-
loading.
Normally,
do
not
per-
form manual loading or
unloading.
Battery replacement
@
Install
an
"AA"/"R6"
size
battery
battery compartment observing polarity.
in
the
2. The
compartment
door
will
open
automatically
when the indented dot on
the
loading
dial
stops
aligned with the red dot.
The safety catch @ pro-
trudes
automatically
to
show
that
the
tape
has
been unloaded.
3. Using the smaller hole on
the
underside
of
the
adapter, push the cassette
up
from
below
and
re-
move
it.
aa
=
jCAUTION:
'Remove the cassette after |
tape
unloading
is
com- |
ipleted.
;
4. Close
door.
the
compartment
CAUTION
Check the tape condition after inserting the cassette
and tape loading is completed:
1) Check to see if there is any tape slack. (Do not
open the tape cover.)
2) If there is tape slack, remove
it by turning the
reel in the direction of the arrow.
CAUTION:
During tape
loading and
unloading,
do not touch
Tape
this reel for
Tape cover
safety and
tape pro-
tection.
Note
During special-effects
playback
(slow motion, still
frame, etc.) the picture
may vibrate or noise bars
may appear on the screen.
SPECIFICATIONS
Type
: VHS cassette adapter
Dimensions
: 188(W) x 25(H) x 104(D) mm
(7-7/16" x 1" x 4-1/8")
Weight
: 235 g (0.5 Ib.)
Accessory
: "AA'/"RE"
size battery x 1
Design and specifications subject to change without
notice.
