Bosch C30 charger I Operating instructions
4.4

Overheating protection

If the device becomes too hot during the charging process, the output power and out-
put current are automatically reduced to prevent damage to the device.
4.5 Standby and reverse polarity protection
Mode
Standby
Reverse polarity protection

5 Mode selection

1. Select the desired mode by pressing the mode selection button.
2. The LED for the desired mode will light up.
3. If no further action is subsequently taken, the charging process will start after 5
seconds.
Mode
Mode 1
Car mode
Mode 2
12 V motorcycle
mode
Mode 3
Cold/AGM mode
Mode 4
regeneration
mode
1
Mode 5
6 V motorcycle
mode
Note:
For regeneration mode, make sure that all connections between the battery and the
vehicle electrical system are disconnected.
Indicator
Output Indicator Operation
14.4 V /
3.8 A
14.4 V /
0.8 A
14.7 V /
3.8 A
16.5 V /
1.5 A
7.2 V /
0.8 A
Explanation
Lights up during power on and in the event of faults
Lights up when the terminal clamps are reversed
Press the button once to
select mode 1
◾ LED 11 lights up
Press the button twice to
select mode 2
◾ LED 10 lights up
Press the button three
times to select mode 3
◾ LED 9 lights up
Press the button four times
to select mode 4,
◾ LED 8 & LED
11 will light up
Press the mode button
to switch to mode 5
◾ LED 7 will light up
Battery types supported
12 V lead-acid, EFB, AGM
and most GEL batteries.
Capacity of > 14 Ah in
normal condition
12 V lead-acid, EFB, AGM
and most GEL batteries.
Capacity of ≤ 14 Ah in
normal condition
Cold state (0-4 °C) of 12 V
lead-acid, EFB and most
GEL batteries. And for
many 12 V AGM batteries
in normal condition.
Capacity of > 14 Ah
Suitable for the re-
generation of 12 V
batteries after short-term
extreme discharge.
Capacity of
> 14 Ah
6 V lead-acid, AGM, EFB,
and most GEL batteries.
Capacity of ≤ 14 Ah in
normal condition
