HMNF
Thank you for your purchase. Before discarding packaging material be sure you have located
Parts List
# 1
1pc
Right Side Frame
# 4
1pc
Metal Shelf Frame
# 7
1pc
Glass Top
Hardware List
No
Figure
A
B
Please do not tighten any bolt firmly before you put all of them in place.
Step 1) Put all parts on a soft surface to prevent scratches. Attach right (#1) and left (#2)
side frames to metal top frame (#3) by using bolt (B) as shown.
all the parts including the necessary hardware and tools
listed on the instruction sheet below.
# 2
1pc
Left Side Frame
# 5
1pc
Metal Back Frame
Description
Tapered Bolt 1/4" x
20 x 7/8"
Tapered Bolt 1/4"
x 20 x 1/2"
QTY
No
Figure
6
C
10
D
Assembly Instruction
1662-3
SOFA TABLE
SKU# 23816626
# 3
1pc
Metal Top Frame
# 6
1pc
Glass Shelf
Description
10mm Ø Glass Tips
4mm Hex Allen
Wrench
QTY
12
1
Advertisement
Related Manuals for ROOMS TO GO HMNF Nadine 23816626
Summary of Contents for ROOMS TO GO HMNF Nadine 23816626
- Page 1 Assembly Instruction 1662-3 SOFA TABLE HMNF SKU# 23816626 Thank you for your purchase. Before discarding packaging material be sure you have located all the parts including the necessary hardware and tools listed on the instruction sheet below. Parts List Right Side Frame Left Side Frame Metal Top Frame Metal Shelf Frame...
- Page 2 Step 2) Attach metal shelf frame (#4) to right /left side frames by using bolt (A) as shown. Step 3) Turn the table upside down then attach metal back panel (#5) to right / left side frames by using bolt (B) as shown then tighten all bolts firmly. Step 4) Put glass tips (C) onto metal top frame (#1) and metal shelf frame (#4) as shown then put glass shelf (#6) and glass top (7) on frame as shown carefully.
