- Page 1 INSTRUCTION MANUAL RV50 Forward Plate ENGINE: Honda GX160 PART NUMBER : 4812334799 RV50 Forward Plate...
- Page 2 RV50...
- Page 3 Table of Contents Table of Contents Foreword ........................ 1 Safety Instruction ....................2 Safety Information Label Locations ..............3 Technical Specifications ..................6 Dimension ......................7 Operating Instructions - Quick Guide .............. 9 Transport ......................11 Transport to work site ..............11 Instruction for lifting machine ............
- Page 4 Table of Contents RV50...
- Page 5 REDLINE Pune. We wish you successful work with your REDLINE machine. Dynapac Road Construction Equipment (India) Pvt. Ltd. Plot no 01, Gat no. 163-168, Alandi Markal road, Village: Fulgaon, Taluka: Haveli, Dist: Pune- 412216, India dynapac-redline.com...
- Page 6 Operation Manual - Safety Instruction Safety Instruction - Laws governing safety aspects on machinery may vary between countries, but the following guides will be useful to all operators: - Before starting, carefully read the machine maintenance and operating manual and follow all the instructions.
- Page 7 Operation Manual - Safety Information Label Locations Safety Information Label Locations RV100...
- Page 8 Operation Manual - Safety Information Label Locations Pictogram Meaning Read understand supplied operator’s manual before operating this machine. Wear ear protection Wear eye protection Wear boots RV50...
- Page 9 Operation Manual - Safety Information Label Locations Pictogram Meaning WARNING! Hand injure if caught in moving belt. Always replace belt guard. Check exciter housing oil level SAE 30W A nameplate listing the model number, serial number, is attached to each unit. please record the information found on this plate so it will be available should the nameplate become lost or damaged.
- Page 10 Operation Manual - Technical Specifications Technical Specifications Model’s cat. no RV 50 Honda Gasoline M10560 Weight Net Weight kg. Operating Weight kg. Compaction Data Vibr. Frequency Hz Centrifugal Force kN 10.79 Compaction Area m²/hour Operation Data Max. Forward speed m/min Capacities Oil for exciter housing liters SAE 30...
- Page 11 Operation Manual - Dimension Dimension Handle in the working position Handle in the folding position RV50...
- Page 12 Operation Manual - Optional Extra Optional Extra DESCRIPTION PART NO. QTY. Vulcalon plate RV50 MODEL HONDA GASOLINE Width Length 1 Length 2 Height 1 Height 2 Height 3 Weight RV50...
- Page 13 Operation Manual - Operating Instructions - Quick Guide Operating Instructions - Quick Guide Always read the full instructions in operating manual before first use. RV50...
- Page 14 Operation Manual - Operating Instructions - Quick Guide RV50...
- Page 15 Operation Manual - Transport Transport Transport to work site - To avoid burns or fire hazards, let engine cool before transporting machine or storing indoors. - Turn fuel valve to the off position and keep the engine level to prevent fuel from spilling. - Tie the machine to the vehicle to prevent sliding or tipping over.
- Page 16 Operation Manual - Important Advice Important Advice The manufacturer declines all responsibility for loss or damage resulting from misuse or any modification or alteration that does not conform to the manufacturer’s original specifications. At the workstation, the sound pressure level may exceed 85 db (A). In this case individual protection measures must be taken.
- Page 17 Operation Manual - Honda GX160 Honda GX160 RV50...
- Page 18 Operation Manual - Honda GX160 Part no. Part no. RV50...
- Page 19 Spare parts list...
- Page 20 RV50 Service, repair and wear part kits Kits-4812334799 Service, repair and wear part kits Service, repair and wear part kits 4812338050 Repair kit, shock-absorber 4812338051 Repair kit, transmission 4812338052 Repair kit, exciter unit 4812338059 Service kit Refurbishing kits 4812338053 Refurbishing kit - covering Field kits 4812338054 Comfort handle,middle 4812338055 Transport wheels...
- Page 21 Spare parts list Forward Plate RV50 Refer to Parts Online for the most up to date information. The printed information might be outdated. Tue Apr 16 05:48:43 UTC 2024...
- Page 22 Spare parts list Forward Plate RV50 RV50 Item Part No. Name SN INFO PNNA Frame with engine PNNA Plate Refer to Parts Online for the most up to date information. The printed information might be outdated. Tue Apr 16 05:48:40 UTC 2024...
- Page 23 Spare parts list Forward Plate RV50 Service, repair and wear part kits Kits-4812334799 Service, repair and wear part kits Item Part No. Name SN INFO Service, repair and Service, repair and wear part kits wear part kits 4812338050 Repair kit, shock-absorber Refer to Parts Online for the most up to date information.
- Page 24 Spare parts list Forward Plate RV50 Item Part No. Name SN INFO 4812338051 Repair kit, transmission 4812338052 Repair kit, exciter unit 4812338059 Service kit Refurbishing kit Refurbishing kit 4812338053 Refurbishing kit - covering Field kit Field kit 4812338055 Transport wheels 4812338054 Comfort handle PNNA...
- Page 25 Spare parts list Forward Plate RV50 Service, repair and wear part kits 4812338050 Repair kit, shock-absorber Item Part No. Name SN INFO 4812338050 Repair kit, shock-absorber 4812336067 Shockmount 4812086231 Hex. Head screw 4812086225 Lock washer 4812086226 Washer 4812336081 Rubber Mounting 4812336080 Washer 4812086301...
- Page 26 Spare parts list Forward Plate RV50 Service, repair and wear part kits 4812338051 Repair kit, transmission Item Part No. Name SN INFO 4812338051 Repair kit, transmission 4812336094 V-Belt 4812086293 Hex. Head screw 4812086292 Washer 4812336093 Centrifugal clutch pulley PNNA 4812336076 Pulley 4812086292 Washer...
- Page 27 Spare parts list Forward Plate RV50 Service, repair and wear part kits 4812338052 Repair kit, exciter unit Item Part No. Name SN INFO 4812338052 Repair kit, exciter unit 4812336070 Ball bearing 4812336072 Oil Plug 4812336074 Oil seal Refer to Parts Online for the most up to date information. The printed information might be outdated. Tue Apr 16 05:48:40 UTC 2024...
- Page 28 Spare parts list Forward Plate RV50 Service, repair and wear part kits 4812338059 Service kit Item Part No. Name SN INFO 4812338059 Service kit 4812086412 Element air cleaner 4812086311 Spark Plug 4812338056 Fuel tube 4812338057 Joint fuel tank 4812086410 Oil Drain washer 4812086411 Starter rope 4812338058...
- Page 29 Spare parts list Forward Plate RV50 Refurbishing kits 4812338053 Refurbishing kit - covering Item Part No. Name SN INFO 4812338053 Refurbishing kit - covering 4812336095 Plastic Belt guard 4812336080 Washer 4812086301 Lock washer 4812086293 Hex. Head screw Refer to Parts Online for the most up to date information. The printed information might be outdated. Tue Apr 16 05:48:41 UTC 2024...
- Page 30 Spare parts list Forward Plate RV50 Field kits 4812338054 Comfort handle,middle Item Part No. Name SN INFO 4812338054 Comfort handle 4812336082 Bottom Handle 4812336083 Nylon bush 4812336080 Washer 4812086291 Self locking nut 4812086237 Hex. nut 4812086236 Locking pin with thread 4812086301 Lock washer 4812086293...
- Page 31 Spare parts list Forward Plate RV50 Field kits 4812338055 Transport wheels Item Part No. Name SN INFO 4812338055 Transport wheels 4812336097 Washer 4812086292 Washer 4812336098 Plastic wheel 4812336099 Hex. Head screw Refer to Parts Online for the most up to date information. The printed information might be outdated. Tue Apr 16 05:48:41 UTC 2024...
- Page 32 Spare parts list Forward Plate RV50 Frame with engine Frame with engine Item Part No. Name SN INFO 4812336079 Engine box 4812336080 Washer 4812086301 Lock washer 4812086293 Hex. Head screw 4812336081 Rubber Mounting 4812336082 Bottom Handle 4812336083 Nylon bush 4812086291 Self locking nut 4812086237 Hex.
- Page 33 Spare parts list Forward Plate RV50 Item Part No. Name SN INFO 4812336092 Hex. Head screw 4812336093 Centrifugal clutch pulley 4812086292 Washer 4812336094 V-Belt 4812336095 Plastic Belt guard 4812336096 Washer 4812086225 Lock washer 4812086231 Hex. Head screw 4812336097 Washer 4812336098 Plastic wheel 4812336099 Hex.
- Page 34 Spare parts list Forward Plate RV50 Base Plate with Exciter unit Plate Item Part No. Name SN INFO 4812336063 Baseplate 4812086231 Hex. Head screw 4812086225 Lock washer 4812086226 Washer 4812336067 Shockmount 4812336068 Hex. Head screw 4812334870 Spring Lock Washer 4812336069 Rear cover 4812336070 Ball bearing...
- Page 35 RV50...
