  • Page 2 ELITE SERIES OILLESS AIR COMPRESSER INSTALLATION AND SERVICE Manufacturers of Dental Vacuum and Air Systems MANUAL 2625 N. Argyle Ave. • Fresno, CA 93727 Revised 4-18 (559) 291-1650 • (800) 428-7139 • FAX (559) 348-9677...
  • Page 3 ELITE SERIES OILLESS AIR COMPRESSER INSTALLATION AND SERVICE MANUAL This manual is for the installation and service of Tech West’s Elite Series Oilless Air Compressors. CONTENTS Installation Location Requirements Figure 1: Wire and Breaker Sizes Elite Series Oilless Air Compressor Installation Steps...
  • Page 4 1. ELITE SERIES OILLESS AIR COMPRESSOR LOCATION REQUIREMENTS The Elite Series Oilless Air Compressor location should be level, accessible and well ventilated. If the Elite Series Oilless Air Compressor will be located in a confined space, provide adequate ventilation. Electrical Line voltage must be within the limits of Figure 1 below.
  • Page 5 2. INSTALLATION STEPS This dental compressor should only be installed by qualified personnel. Should any questions arise during the installation, call Tech West Technical Support between the hours of 7:00 a.m. to 4:00 p.m. (Pacific Standard Time). Place the compressor in a clean, dry, well ventilated area, on a solid, level surface. Consider sound level and insulate as needed.
  • Page 6 ELITE SERIES OILLESS AIR COMPRESSOR INSTALLATION 3. CONNECTIONS Figure 2 Dryer Purge Connection Electrical Connection to disconnect and electrical panel 220 v Air Out Connection to building supply line Alternate Air Connection to fresh air supply...
  • Page 7 ELITE SERIES OILLESS AIR COMPRESSOR INSTALLATION 4. SAFETY PRECAUTIONS • Keep fingers, foreign objects and clothing free from rotating parts and do not touch hot surfaces. • Never attempt to service an operating unit. • Isolate unit from system pressure and relieve backpressure before servicing.
  • Page 8 INSTALLATION 6. GENERAL SERVICE INFORMATION For parts and service on the Elite series compressor contact the nearest authorized Tech West distributor. To expedite appropriate service, be prepared to provide the unit model number, identification number, and serial number found on the nameplate located on the front of the unit motor.
  • Page 9 DUAL AND TRIPLE ELITE SERIES OILLESS AIR COMPRESSOR CONFIGURATION GAUGE AND CUT-OFF ASSEMBLY PART NO. DESCRIPTION UNIT ALUMINUM TANK MANIFOLD BV-250-FM BALL VALVE 1/4” FEMALE TO MALE FE-4-4 BRASS FLARE ELBOW 1/4” X 1/4” POVA-100 POP OFF VALVE 125 PSI ASME...
  • Page 10 REAR VIEW ASSEMBLY AND PARTS LIST PART NO. DESCRIPTION UNIT CFB-P COALESCING FILTER BRACKET CFAO-375-100 COALESCING FILTER ASSEMBLY EPCM ELITE PRECOOLER MOUNT DPC-2E DRYER PRECOOLER - DUAL ELITE EPCB ELITE PRECOOLER BRACKET ETA-2F ELITE TANK CROSS ANGLE DUAL - FRONT ETA-2R ELITE TANK CROSS ANGLE DUAL - REAR ELITE MOTOR MOUNT...
  • Page 11 NEW DESICCANT AIR DRYER ASSEMBLY INSIDE TANK ELEMENT...
  • Page 12 COALESCING FILTER ASSEMBLY PART NO. DESCRIPTION UNIT CFAO-375 COALESCING FILTER ASSEMBLY 3/8 CFEO-375 COALESCING FILTER ELEMENT 3/8 CFBP-375 COALESCING FILTER BOWL...
  • Page 13 DUAL ELITE OILLESS AIR COMPRESSOR WIRING DIAGRAM TOGGLE...
  • Page 14 TRIPLE ELITE OILLESS AIR COMPRESSOR WIRING DIAGRAM SWITCH...
  • Page 15 INSIDE DUAL ELITE OILLESS AIR COMPRESSOR PART NO. DESCRIPTION UNIT SBHA-13-375J STEEL BRAIDED HOSE ASSEMBLY 13” FPH-500R FLEX PVC HOSE REINFORCED 1/2” HA-17-250 HOSE ASSEMBLY 17” SBHA-17-375 STEEL BRAIDED HOSE ASSEMBLY 17” SBHA-10.5-375 STEEL BRAIDED HOSE ASSEMBLY 10.5” DSV-230 DRYER SOLENOID VALVE 230V SBHA-28-375 STEEL BRAIDED HOSE ASSEMBLY 28”...
  • Page 16 INSIDE TRIPLE ELITE OILLESS AIR COMPRESSOR PART NO. DESCRIPTION UNIT SBHA-13-375J STEEL BRAIDED HOSE ASSEMBLY 13” FPH-500R FLEX PVC HOSE REINFORCED 1/2” SBHA-17-375 STEEL BRAIDED HOSE ASSEMBLY 17” HA-17-250 1/4” HOSE ASSEMBLY 17” SBHA-10.5-375 STEEL BRAIDED HOSE ASSEMBLY 10.5” DSV-230 DRYER SOLENOID VALVE 230V CFAO-375 COALESCING FILTER ASSEMBLY 3/8”...
  • Page 19 Maintenance & Service / Notes...
