- Page 1 Installation, Operation, and Maintenance Guide SeltzaHub/ SeltzaTap/ SeltzaTap Compact Revised 27.11.2024...
- Page 2 Table of contents SeltzaHub What’s included Technical Specifications SeltzaTap Technical Specifications SeltzaTap Compact Technical Specifications SeltzaHub Installation overview Installation preparation SeltzaTap Installation SeltzaHub Installation Operation SeltzaTap Operation SeltzaTap Compact Operation SeltzaTap Maintenance SeltzaHub Troubleshooting Warranty Installation, Operation, and Maintenance Guide...
- Page 3 SELTZAHUB What’s included? SeltzaHub Seltza regulator Regulator adapter T-Stop valve TR21-4 threads for CGA-320 threads Power Cord @ 3ft x 1/4’ Valve kit for Water inlet and C02 Installation, Operation, and Maintenance Guide...
- Page 4 6 litre/ hour Refrigerant Type and Charge R600a Cooling temperature 3-12°C CO2 inlet pressure 65-75 psi Water inlet pressure 20 – 60 psi SeltzaHub only weight 13.0kg (28.7 lbs) SeltzaHub weight with packaging 14.9kg (32.1 lbs) Installation, Operation, and Maintenance Guide...
- Page 5 5/16” tubing 90cm 50mm 175mm 90 cm long 5/16 inch of PE tubing Countertop hole and Blue tubing = Chilled Seltza (Sparkling) thickness requirements White Tubing = Chilled Still Clear Tubing = Ambient Still 35mm Max Countertop thickness Faucet hole diameter is 1 3/4"...
- Page 6 172mm Countertop hole and 5/16” tubing thickness requirements 90cm 90 cm long 5/16 inch of PE tubing Blue tubing = Chilled Seltza (Sparkling) 35mm White Tubing = Chilled Still Max Countertop thickness Faucet hole diameter is 1 3/4" (45mm) in Countertop is Clear Tubing = Ambient Still 1 3/8"...
- Page 7 SELTZAHUB Installation Overall view of installation SeltzaTap Regulator Seltza water T-stop Cold water valve Ambient water (existing valves) CO2 cylinder (not included) Filter (optional) 1/4” Installation, Operation, and Maintenance Guide...
- Page 8 Installation Preparation Factory Testing Each SeltzaHub and Seltza Tap is factory tested prior to packaging. For this reason, you may notice dampress / wetness when installing. How To Use Quick Connect Fittings Cut the tube square and push Fitting grips before it seals.
- Page 9 SELTZATAP Installation of Seltza Tap Turn off hot and cold Disconnect existing hot Remove faucet nut from existing faucet. water from existing and cold water lines from May have two screws or just be a nut. valves under the sink.
- Page 10 SELTZATAP Installation of Seltza Tap Install T-Stop Valve in existing cold water line. May require an adapter. Connect cold water faucet Connect hot water faucet hose to the T-Stop valve. to the hot water piping. May require an adapter. May require an adapter...
- Page 11 SELTZAHUB SELTZAHUB Installation of Seltza Hub Note:Disregard the steps already completed from Seltza Tap instalation. Turn off cold Disconnect existing Install T-Stop Valve in existing water from existing cold water lines from cold water line. valve under the sink. existing valve.
- Page 12 5/16’ b) Turn on Main water valve. Check for leaks c) Turn on T-Stop valve Check for leaks d) Turn on Each valve on the side of SeltzaHub and wait for 5 seconds. Check each valve for leaks. Ambient water...
- Page 13 60+ minutes to allow content to settle before initialising. Connect 5/16” tube in the back of the 420gram Regulator adapter SeltzaHub to CO2 inlet. CGA-320 5, 10, or 20lbs TURN ON WATER PLUG IN AND TURN mins.
- Page 14 (2) Power-off the Hub (3) Turn off water undersink (4) Option to drain the water from tank by running the left-hand faucet handle Upon Return: Follow start-up instructions (See steps 13 to 19 of SeltzaHub Installation) Installation, Operation, and Maintenance Guide...
- Page 15 Right hand lever Hot and cold water for cleaning and dishes. Water coming out of second nozzle. Left hand lever Chilled Seltza water Spray function Chilled Still water Hose is removable Ambient Still water (will be the temperature of the main building...
- Page 16 SELTZATAP COMPACT SeltzaTap Compact Operation Right hand lever Left hand lever Hot and cold water for Chilled Seltza water cleaning and dishes. Chilled Still water Ambient Still water (will be the temperature of the main building supply water) Installation, Operation,...
- Page 17 5. Install the new cartridge, ensuring the tabs lineup as per the picture below. 6. Replace the handle, reinserting the set screw and cap. 7. Turn the water to the faucet back on at the SeltzaHub valves Handle Faucet body Ensure tabs lineup 2.5mm...
- Page 18 SELTZATAP SeltzaTap Maintenance Changing Cartridges Regular water (Right Hand Cartridge) Turn off hot and cold 1. Turn the water off to the faucet at the Hot and Cold valves below sink. (As shown.) water from existing valves under the sink. 2.
- Page 19 If there are any unusual NOISE, shutdown the Noise Contact Seltza customer support. SeltzaHub, close the water inlet and gas inlets. This marking indicates that this product should Correct Disposal of this product: not be disposed with other household wastes.
- Page 20 Applicable to all above, is that the warranties need to be approved by Seltza to ensure product was not incorrectly used, installed or claimed. False and incorrect claims will be pursued at Seltza discretion, includ- ing chargeable inspection and labour costs incurred.
