Summary of Contents for Aquasana SimplySoft WH-SF40
- Page 1 WH-SF40 AND WH-SF60 Whole House SimplySoft ® Water Softener 40,000 Grains & 60,000 Grains Owner’s Manual...
- Page 2 Experience the luxury of soft water. Your new Aquasana SimplySoft Water ® Softener was expertly engineered to reduce hard water minerals, ensuring soft, scale-free water throughout your home. Our SimplySoft softeners help you save up to $497 annually* by improving ®...
- Page 3 BOX CONTENTS & SYSTEM CONFIGURATION If you have added components to your Whole House SimplySoft Water Softener, note the correct sequencing below. ® The following components may vary based on the purchased configuration. SimplySoft® Pressure Tank Pre-Filter Control Valve Post-Filter Transformer Plastic Wrench Brine Tank...
- Page 4 BOX CONTENTS & SYSTEM CONFIGURATION Box contents may be packaged in multiple boxes. Before beginning installation, please ensure all parts listed are present. If any part is missing or damaged, do not attempt to install the system. Before beginning installation, ensure you have a copy of your most recent water test results for your home’s water hardness.
- Page 5 PRECAUTIONS/SAFEGUARDS • For all installations: Due to the varieties of home design, not all configurations can be addressed in this guide. Anticipate the need for additional parts and pieces including but not limited to pex tubing, clamps, and mounting screws to install unit properly (available at a local home improvement store or through your plumbing contractor).
- Page 6 INSTALLATION STEPS Select Location Consider the following when selecting where to install the system: 1. Outside taps used to water lawns and gardens should be isolated from the water line required to supply untreated water to the inlet of the water softener.
- Page 7 INSTALLATION STEPS Assemble Brine Tank (cont. from previous page) 4. Ensure the attached tube stiffener is inserted into the brine tube. Then, take the brine tube and insert the nut and plastic sleeve as shown below. Insert the tube in the brine well elbow and hand-tighten the nut. Pull the opposite end of the brine tube through the hole on the brine tank to prepare for installation.
- Page 8 INSTALLATION STEPS Prepare Pressure Tank (cont. from previous page) 3. Remove the tape from the top of the riser tube. Carefully position the control valve and basket over the riser tube, inserting riser into the internal o-ring. Turn the control valve to the right into the threads of the tank until secure.
- Page 9 PVC, or PEX tubing. Configure System System configuration may vary. Instructions provided are for base Aquasana install kit. 1. Fit pre-filter, pressure tank, brine tank, and any optional add-ons into the system as this time.
- Page 10 INSTALLATION STEPS Connect the Drain Line 1. Attach the ½" drain hose to the drain line fitting with provided clamp. Tighten with screwdriver. 2. Run the drain line to the existing softener drain. Measure tubing and cut excess as needed. 3.
- Page 11 INSTALLATION STEPS Connect the Transformer 1. Connect the transformer to the system by plugging the 12 volt transformer into a 120 VAC 60 Hz outlet. Then, WARNING connect the power supply to the control valve power DO NOT use supply. an outlet that is controlled by 2.
- Page 12 INSTALLATION STEPS Purge Air from the System (cont. from previous page) 4. If the power was disconnected in step 3, reconnect the power. Manually turn the control knob to the right to the refill position, labeled REFILL. Allow the system to refill at least twice by rotating the control knob back around to REFILL until there is approximately 1"...
- Page 13 INSTALLATION STEPS Program the Control Valve NOTE: You must have your ZIP code's water hardness level (in gpg) from your city's most recent water report or have your water tested in order to program the control valve. You are required to program the time of day, the number of people living in the home, and the correct hardness setting.
- Page 14 INSTALLATION STEPS Program the Control Valve (cont. from previous page) Key Pad Configuration: SETTINGS - This function is to enter the basic set up information required at the time of installation. SELECT - This function is to accept the values if changed and advance to the next SETTINGS page in the menu.
- Page 15 SYSTEM MAINTENANCE Manually Regenerate To regenerate immediately, turn the center knob clockwise to BA. Alternatively, a regeneration can be started WA (Backwash) position. using the buttons on the control panel. 1. Press and hold SELECT for 3 seconds. 2. Use UP or Down arrow to select to start the regeneration the coming night (DELAY) or immediately (IMMEDIAT).
- Page 16 2. Manually regenerate the softener immediately. Repeat regeneration if taste, odor, or discoloration is detected in the discharge. 3. Next, run the cold, soft water tap nearest the softener. Click here to purchase Aquasana Water Softener Cleaner, view cleaner instructions, and learn more. < Back Next >...
- Page 17 SYSTEM MAINTENANCE Service the Control Valve Before servicing, you will need to: SERVICE BYPASS 1. Shut the water supply to the system off and put the softener in the BYPASS position. 2. Relieve the water pressure in the softener. Do so by turning the control into the BACKWASH momentarily.
- Page 18 SYSTEM MAINTENANCE MANUAL WATER BYPASS In case of an emergency or to perform softener maintenance, isolate your system from the main water supply using the bypass valve, located at the back of the control valve. In normal operation, the bypass is set to OPEN with the ON/OFF knobs in line with the INLET and OUTLET pipes.
- Page 19 TROUBLESHOOTING GUIDE Issue Resolution Call Customer Service at 866-662-6885 option 1, and then option Component is missing or 2, and then option 1. Please have order number, model number, arrived damaged and pictures of damaged packaging and/or damaged unit. • Ensure tight connection – do not overtighten as that could cause cracks and further leaking.
- Page 20 4.5 lbs 20,443 grains Aquasana, Inc. 6310 Midway Road · Haltom City, Texas 76117 · 866.662.6885 An Efficiency-rated water softener is a Demand-initiated regeneration softener that also complies with specific performance specifications intended to minimize the amount of regenerant brine and water used in its operation. Efficiency-rated water soft- eners shall have a rated salt efficiency of no less than 3,350 grains of total hardness exchange per pound of salt (based on NaCl equivalency) (477 grams of total hardness exchange per kilogram of salt), and shall not deliver more salt than its listed rating.
- Page 21 • The water softener is not installed, operated and maintained nying the product and found on Aquasana.com and not subject to in accordance with the printed Manufacturer’s instructions, including if the water softener has any additional aftermarket freezing or vacuum.
- Page 22 Replacements shipped to Free to join and cancel you right when you need anytime – no long-term them – at no extra cost. commitment required. CONTACT US TO LEARN MORE 866-275-2319 waterforlife@aquasana.com * E xclusionsapply.LimitedWarrantydetailsareavailableataquasana.com.BenefitsareforthetermofWaterforLifemembership. < Back To Table of Contents...
- Page 23 LOVE IT? NEED HELP? Please let us know with Give us a call at 866-662-6885 and a review on Aquasana or your retailer’s website. tell us what’s going on. Aquasana, Inc. 6310 Midway Road Haltom City, Texas 76117 866.662.6885 USA 877.332.7873 Canada...
