Specifications

RM Multi-pin connector
PROMPTER output
SDI output
Operating temperature range : –5 °C to 40 °C (Humidity below 80 %)
Allowable storage temperature : –20 °C to 60 °C
Power supply voltage
Power consumption
Dimensions
Mass
Accessories
Dimensions (Unit: mm)
INCOM MIC
ON CARBON
OFF DYNAMIC
INTERCOM
INCOM LEVEL CALL
MIN MAX
Specifications and appearance of this unit are subject to change for further improvement
without prior notice.
All manuals and user guides at all-guides.com
: Composite video signal output
(Either Y/Cb/Cr, RGB or YC separate output signal could be
selected)
: PROMPTER video signal output (composite signal)
: Serial digital video signal (SMPTE259M-compliant)
0.8 V(p-p), 75 ¸ Unbalanced (only for KY-F5603U)
: DC12 V
: KA-F5602U Max. 17 W (KY-F560, VF-P400, lens in-use)
KA-F5603U Max. 18 W (KY-F560, VF-P400, lens in-use)
: (W) 156 mm x (H) 168.3 mm x (D) 185.1 mm (Exclude
protruded part.)
: Approx. 1.8 kg
: Screw
Instructions .......................................... x 1
146.6
VF
185.1
204.3
.......................................... x 1
16.5
25 95
156
23
