Installation

System

Studio kit/Studio SDI kit
KA-F5602U/KA-F5603U
Lens
[PROMPTER
OUTPUT]
connector
Monitor
Dolly TP-P205
● Please refer to KY-F560 instruction manual for details on the lens and lens remote control.
● The 26 Pin camera cable used should be less than 100 m.
● Power is supplied via the 26 Pin camera cable by the Remote Control Unit RM-P210 if it is
in-use. If the Remote Control Unit RM-P210 is not in-use, please use AC power adapter
AA-P250.
All manuals and user guides at all-guides.com
Viewfinder VF-P400
BREAKER
PROMPTER
RM
OUTPUT DC INPUT
[DC INPUT] connector
RM multi-pin connector
Headset
KA-310U
Tripod
TP-P300
AC power adapter AA-P250
Color video camera
KY-F560
COLOR VIDEO CAMERA KY-F560
SDI output (only KA-F5603U)
[INTERCOM] connector
26Pin camera cable
VC-P110 (5 m)
VC-P112 (20 m)
VC-P113 (50 m)
VC-P114 (100 m)
TALLY CALL MENU/SHUTTER GAIN
FULL AUTO F1 F3
SHUTTER
STEP
HIGH
SHUTTER VARIABLE
PUSH-ON PUSH-ON
BARS F2 F4 MENU
LOW
GAIN
INTERCOM DOWN UP DOWN UP
LEVEL
Remote control unit RM-P210
VC-710 (5 m)
4P
4P
Headset KA-310U
SDI input
SDI compatible
video equipment
REMOTE CONTROL UNIT RM-P210
WHITE MASTER BLACK IRIS POWER
PAINT AUTO
W.BAL
B I
MID A AUTO
R B MANU
PRESET
O
CLOSE OPEN
13
