Under Toe Board Weight Kit
Zero-Turn-Radius Riding Mower
Model No. 140-4958
Important:
If you are installing the Under Toe Board Weight Kit onto a machine that already has an
under toe board weight installed, use Part No. 321-10 (hex-head bolt 1/4 x 1-3/4 inches) to ensure that
there is adequate bolt length.
Installation
Loose Parts
Use the chart below to verify that all parts have been shipped.
Description
No parts required
Toe-board weight
Hex-head bolt (1/4 x 1-1/4 inches)
Flat washer
Locknut (1/4 inch)
Preparing the Machine
1.
Shut off the engine, remove the key, and wait for all moving parts to stop before leaving the operating
position.
2.
Disengage the PTO, move the motion-control levers to the N
parking brake.
Original Instructions (EN)
Qty.
–
Prepare the machine.
1
4
Install the kit.
4
4
EUTRAL
Form No. 3436-350 Rev A
Installation Instructions
Use
-
position, and engage the
LOCK
Printed in the USA
*3436-350* A
All Rights Reserved
