- Page 1 Assembly and operating instructions 1 |28...
- Page 2 Foreword Foreword We are pleased that you have chosen our product. By purchasing a CARAVITA product, you have opted for quality, made from the best materials and designed to the highest standards. Read the instructions in this document carefully to set up the product safely. Always observe the safety instructions listed and do not perform any unauthorised modifications to the product.
- Page 3 Table of Contents Table of Contents Foreword ......................... 2 Introduction ........................4 Safety Information ............................4 Notes on the target group and use of the instructions .................. 4 Explanation of signal words ........................... 4 Basic safety instructions Product information ......................6 Intended use ................................
- Page 4 It is important for the safety of persons to follow the instructions. Failure to observe the instructions may result in personal injury and/or damage to property when using the product. Failure to comply shall release Caravita from liability. Warnings are labelled with this or a similar symbol in the instructions.
- Page 5 ◼ In strong winds and thunderstorms, retract the sunshade or do not set it up. ◼ Do not climb on the sunshade. ◼ Do not leave children near the sunshade without supervision. ◼ Do not use the sunshade without a suitable stand. ◼...
- Page 6 Additional loads on the product due to suspended objects or cable tensioning can lead to damage or falling and are therefore not permitted. Caravita is not liable for any damage resulting from this. Intended use also includes observing these instructions and complying with the maintenance specifications contained therein.
- Page 7 Assembly 4 Assembly CAUTION Risk of injury due to tipping during assembly Tipping or dropping the product can result in serious injuries. ◼ 2 people are required to assemble and set up the product. ◼ Mount the product on a level surface. NOTE When installing several sunshades, a distance of at least 25 cm must be maintained between the individual sunshades.
- Page 8 Check scope of delivery according to delivery note! Check parts for intactness! Compare the situation on site with the order data! Interrupt assembly and contact CARAVITA if parts are damaged or if the specifications do not correspond to the order! 8 |28...
- Page 9 Assembly 4 x bracket, single or levelling (optional) 8 x bolt M8x80 1 x pole with stainless steel pedal (optional) and crank 7 8 x nut M8 gear 4 x sunshade roof 16 x cover cap for nuts and screws 4 x strap 1 x Allen key 1 x crank...
- Page 10 Assembly Pole alignment Amalfi DUO 1 INFO Note on aligning the threaded holes: ◼ The threaded holes of the base sleeve point towards the side edges of the sunshade roof, as shown. Fig. 3: Alignment of the threaded holes DUO 1 Pole alignment Amalfi DUO 2 and Amalfi Quadro INFO Notes on positioning the base sleeve:...
- Page 11 Assembly Assemble the pole on the base Minor deviations from the illustrations are possible. Place the pole with the flange on the base sleeve or mobile stand 1 person fastens the pole with the 4 screws including washers, while the 2nd person holds the pole in place. The sunshade gains a slight hold.
- Page 12 Assembly Assemble the bracket The pole is assembled in the base sleeve or in the mobile stand. 1 Insert the supplied M8x80 screws through the holes and tighten them securely. 2 Place the protective caps over the nuts and screw heads. Attach the sunshade roof The jib and pole are assembled to be stable.
- Page 13 Assembly 4 Lower the sunshade roof. The bayonet adapter snaps into place. 5 Turn the crank slightly anti-clockwise. INFO If the crank is turned too much, the steel cable can become entangled in the gearbox housing. The steel cable is loosened. 6 Release the carabiner from the cable anchorage on the gearbox.
- Page 14 Putting into use Putting into use WARNING Risk of injury due to improper use of the sunshade. Improper use can result in personal injury. ◼ Do not reach into openings on the product during commissioning. ◼ Do not hang any foreign objects on the sunshade that are not expressly mentioned in the instructions. ◼...
- Page 15 Operation Operation CAUTION Risk of crushing due to carelessness when operating! Persons in the travelling area may be injured. Keep travelling area clear of people! Keep children away from the controls! Remove the protective case. ◼ Using the telescopic push bar, see chapter Using the telescopic push bar (optional),...
- Page 16 Operation 2 Pull the struts slightly outwards. The struts are loosened. 3 Insert the crank into the device on the pole. 4 Turn the crank clockwise until the fabric is slightly taut. The sunshade roof opens. 5 Turn the crank handle as far as it will go. INFO If the crank is turned beyond the stop, the gearbox may be damaged.
- Page 17 Operation Levelling the sunshade roof (optional) The sunshade roof can be levelled. The mechanism is not intended for tilting the roof. The roof pitch is regulated using two adjusting screws, which are located behind the panels at the upper end of the bracket. The sunshade roof is hooked in.
- Page 18 Operation Close sunshade roof CAUTION Risk of injury due to tipping Carelessness can cause the sunshade to tip over with its heavy weight. ◼ The base must be designed with sufficient ballast to prevent the closed sunshade from tipping over in strong winds.
- Page 19 Operation 4 Secure the closed sunshade roof with the strap. 5 Place the pulled-out fabric segments around the pole on one side and secure with the strap. 19 |28...
- Page 20 Operation 6.4 Using the telescopic push rod (optional) Attach the key ring to the zip of the protective case. Open the knurled screw on the telescopic push rod. Pull the telescopic push rod to the required length. Tighten the knurled screw on the telescopic push rod. 20 |28...
- Page 21 Operation Insert the telescopic push rod into the pocket of the protective case. Lift the protective case over the sunshade using the telescopic push rod. 3 Close zip. 4 Loosen the eyebolt of the telescopic push rod in the key ring on the zip of the protective case.
- Page 22 Operation Remove the sunshade roof The sunshade roof is closed and secured with the strap. 1 Detach the rope from the sunshade roof using the snap hook. 2 Attach the cable to the eyebolt of the gearbox housing. 3 Wind the rope. INFO The crank can only be turned when the cable is under tension.
- Page 23 Operation 4 Lift the sunshade roof and turn it 90° anti-clockwise. 90° 5 Remove the sunshade roof from the lift using the bayonet adapters. INFO The rope must be tensioned. 6 Attach the cable to the eyebolt of the gearbox housing. 7 Wind the rope.
- Page 24 Disassembly Disassembly During the season, the bracket with the pole can remain installed outdoors without hesitation. At the end of the season or when required, the pole and bracket are dismantled and stored. Disassembly is carried out in the reverse order to assembly. INFO It is recommended not to leave the pole without the bracket in the base or base sleeve.
- Page 25 Material damage due to abrasion of the sunshade fabric Permanent flapping in the wind can damage the sunshade fabric by rubbing against the struts. No claims for damages can be asserted against CARAVITA for this. ◼ Always secure the closed sunshade roof with the strap.
- Page 26 If the sunshade malfunctions and cannot be rectified with the help of the following instructions, please contact us via our CARAVITA service hotline. You will find the contact details on the first and last page of these instructions. The following malfunctions can occur when using the sunshade:...
- Page 27 Warranty conditions Warranty conditions The following warranty conditions apply: www.caravita.de/garantie Other notes Please observe the general safety instructions www.caravita.de/hinweise 27 |28...
- Page 28 28 | 28...
