Domus EMIT-25-TRIO Installation Manual

EMIT-25-TRIO
Specifications
Voltage: 12/24V DC Classification:
Power: 1W
IP Rating: IP67
Requires 12 or 24V DC LED Constant Voltage Driver (Wired in parallel).
Steps to remove honeycomb or frosted diffuser
Installation with cannister
Note:
-The lamp must be installed by professional electrician
-Ensure the power supply is switched off before fitting this product
Class III
Beam Angle: 19° - 36° - 60°
CCT: 3000K-4000K-5500K
(Changeable)
22mm
29-31 Richland St. Kingsgrove. Sydney NSW 2208 Australia
enquiries@domuslighting.com.au | www.domuslighting.com.au
Dimmable:
Operating Temp: -20°C~40°C
Cutout:
-Do not touch the lamp when in use
-Keep away from hot steam and corrosive gas
Phone: 02 9554 9600
Installation Manual
Date: October 10, 2024 3:52 PM
No
Ø19MM Without Cannister
Ø22MM With Cannister
