- Page 1 INSTRUCTION MANUAL SMART ENERGY METER & TIMER MTS21 MAJOR TECH (PTY) LTD South Africa Australia www.major-tech.com www.majortech.com.au sales@major-tech.com info@majortech.com.au...
- Page 2 1. GENERAL DESCRIPTION The MTS21 Smart energy meter & timer is specifically designed to measure active and reactive energy for single-phase two-wire systems and various parameters. This smart device is equipped with Wi-Fi connectivity, allowing users to utilize the “Major Tech Hub” Smart App for remote monitoring and control.
- Page 3 Tighten all screws securely during the installation process. 3. Download the free "Major Tech Hub" Smart App from either the Google Play Store or Apple Store. 4. Access your phone's settings and grant all necessary permissions to the "Major Tech Hub"...
- Page 4 6. CONNECTION DIAGRAM *7 and 8 Terminals = Factory testing terminals 7. LCD DISPLAY READING EXAMPLES. 8. PRODUCT PARAMETERS Function Range Rated Frequency 50/60 Hz Rated Current Power 9600W (Resistive Load) Rated Voltage 110V/220V Voltage range 85 - 260V Approvals IEC/SANS / ICASA / LOA kWh accuracy Class 1...
