Output relay

Group
Digital Output

Ethernet setting

Group
IP
Mask
Gateway
Register
Address
(Hex) Value Name
1070 Digital output function F31
1071 Delay
1072 Reserved
1073 Digital output Operate
Principle
1074~1080 Reserve
Register
Address
(Hex) Value Name
1081 Ethernet IP address
setting byte1~2
1082 Ethernet IP address
setting byte3~4
1083 Ethernet subnet mask
setting byte1~2
1084 Ethernet subnet mask
setting byte3~4
1085 Ethernet gateway
address setting byte1~2
1086 Ethernet gateway
address setting byte3~4
1087 Network port timeout
counter
1088 Network port alarm
enable
1089 Modbus TCP keep alive
time
108A Network port1 alarm
enable
108B Network port2 alarm
enable
Data Type/
Format Step
1
Unsigned integer 1
F32 1
Data Type/
Format Step
Unsigned integer
Unsigned integer
Unsigned integer
Unsigned integer
Unsigned integer
Unsigned integer
Unsigned integer
Unsigned integer
Value Range
(Default
Unit setting)
0-15 (0)
0.1s 0-12000 (0)
0-1 (0)
Value Range (Default
Unit setting)
0~65535 (49320)
E.g.
49320=0xC0A8→192.168
0~65535 (374)
E.g. 374=0x0176→1.118
0~65535 (65535)
E.g.
65535=0xFFFF→255.255
0~65535 (65280)
E.g.
65280=0xFF00→255.0
0~65535 (49320)
E.g.
49320=0xC0A8→192.168
0~65535 (257)
E.g. 257=0x0101→1.1
0.1s 0~65535
0~1
s 0~300
0~1
0~1
