CHAPTER -1: EXPLANATION OF PRODUCT
12
11
10
9
1. Worktop
2. Upper basket with racks
3. Upper spray arm
4. Lower basket
5. Lower spray arm
6. Filters
Turbo Drying Unit:
This system provides better drying
performance for your dishes.
7. Rating plate
8. Control Panel
9. Detergent and rinse-aid dispenser
10. Salt dispenser
11. Upper basket track latch
12. Upper Cutlery Basket
13
EN-4
1
2
3
4
5
Ceiling Spray Arm:
It provides better washing for
the dishes at upper basket.
6
7
8
14
