TY-JS-22413-001
Industrial Chiller
User Manual
Thanks for your purchase of our product. To avoid the
wrong operation, please keep the manual available and read the
installation manual completely before operating the machine.
This manual is not a quality guarantee. Our company reserves
the right to the interpretation of the correction of misprint and
improperly described information and product improvement. The
revised content will be edited into the reprinted user manual
without prior notice.
GUANGZHOU TEYU ELECTROMECHANICAL CO., LTD.
Ad d: No .50, Zh o n gch u an g Road , Zh o n gcu n to wn , Pan yu Dist ri ct,
Guan g zh o u, Ch in a
Zip code: 511495
Emai l ad d ress: marketi n g @t eyu .co m. cn
Tel ： +86-20- 89301885 89301886
Fax ： +86-20- 84309967
original version
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for S&A RMUP-500
Summary of Contents for S&A RMUP-500
- Page 1 TY-JS-22413-001 Industrial Chiller User Manual Thanks for your purchase of our product. To avoid the wrong operation, please keep the manual available and read the installation manual completely before operating the machine. This manual is not a quality guarantee. Our company reserves the right to the interpretation of the correction of misprint and improperly described information and product improvement.
- Page 2 TY-JS-22413-001 RMUP-500 Industrial Chiller User Manual...
- Page 3 TY-JS-22413-001 CONTENTS Notice-----------------------------------------------------------------------------------------4 I. Overview----------------------------------------------------------------------------------7 II. Model Illustration--------------------------------------------------------------------- 7 III. Product Outlines & Parts----------------------------------------------------------8 IV. Installation------------------------------------------------------------------------------9 V. Operating States &Parameters Adjustment--------------------------------- 11 VI. Alarm & Output Terminal----------------------------------------------------------12 VII. Maintenance-------------------------------------------------------------------------- 13 VIII. MODBUS RS-485 communication function------------------------------- 14 IX. Simple Troubleshooting-----------------------------------------------------------15...
- Page 4 TY-JS-22413-001 Notice This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory, or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved.
- Page 5 TY-JS-22413-001 The human body or the heat-labile articles must keep Danger away from this high temperature area. Otherwise, it will Hot Surface cause personal injury or property loss. DANGER Failure to take safety measures will result in death or serious personal injury.
- Page 6 TY-JS-22413-001 a) The equipment must be installed on a horizontal surface. Otherwise, the refrigeration system will fail; b) It is forbidden to place objects within 1meters around the Installation air inlet and 1.5 meters around the air outlet. If the air inlet and the air outlet are blocked, the cooling ability that the equipment should have cannot be realized.
- Page 7 TY-JS-22413-001 glycol. I. Overview This product is an industrial cooling device designed and manufactured for laser cutting, laser welding, laser marking, laser engraving and other equipment that uses laser processing. It can provide a temperature-stable cooling medium for the above application scenarios.
- Page 8 TY-JS-22413-001 III. Product Outlines & Parts Water Supply Inlet Temperature Controller Power Switch Water Level Gauge Air Inlet(Filter Gauze) Drain Power Socket Signal Output/Inout Port Water Outlet Water Inlet Air Outlet Alarm Output Terminal Note: The above-mentioned product outlines and part names are only for one of the models. The outlines and parts installation may be slightly different in different models.
- Page 9 TY-JS-22413-001 IV. Installation 1. Open the package and check whether the machine is in good condition and whether the accessories are complete and in good condition . 2. Please ensure that the working voltage of the chiller is stable and normal.
- Page 10 TY-JS-22413-001 (2) After starting the machine for the first time, check if the water pipes leaks immediately. (3) After turning on the power, if the water temperature is lower than the set temperature, it is normal that the cooling fan and other devices of the machine do not work. The temperature controller will automatically control the working status of compressors, solenoid valves, cooling fans and other components according to the set parameters.
- Page 11 TY-JS-22413-001 (3) Check the liquid level of the water tank; (4) Confirm that the electrical wiring of the equipment is connected correctly; (5) Confirm whether the equipment is grounded. V. Operating States &Parameters Adjustment Default setting of T-801B new model intelligent temperature controller is Intelligent temperature mode, water temperature is setting 25 ℃...
- Page 12 TY-JS-22413-001 temperature difference Function Following code temperature -20.0~20.0 ℃ difference Start/stop mode 1-Power on start； Upper temp. limit 25.0~80.0 ℃ alarm Lower temp. limit -25.0~20.0 ℃ alarm Lower flow rate limit 0~90.0 L/Min protection 0-normally open type; Flow Switch type 1-normally closed type 0-normally open type;...
- Page 13 TY-JS-22413-001 2. Working condition table of alarm signal Display Input port Output port Buzzer working status H1、H2 H1、H3 Circulation pump works properly Disconnection Breakover Media temperature sensor failure Sounds Breakover Disconnection Ambient temperature sensor Sounds Breakover Disconnection failure Flow rate protection Sounds Breakover Disconnection...
- Page 14 TY-JS-22413-001 VIII. MODBUS RS-485 communication function This system adopts MODBUS-RTU communication slave mode, baud rate 9600, no parity, 8 data bits, 1 stop bit, and supports MODBUS-RTU command. Parameter Function Value Description Remarks Attributes address code range (decimal) (decimal) Bit0: alarm Bit1: electric Output...
- Page 15 TY-JS-22413-001 temperature Function code Media traffic Ambient temperature IX. Simple Troubleshooting Phenomenon Reason Solution Check and ensure the power Power cord is not plugged in interface and the power plug are place. well plugged. No power after turned on Replace fuse tube that in the Fuse burnt-out.
